2024/12/09 08:16
CoCo-80X and CoCo-90X Calibration
The CoCo loads factory calibration data during start up, eliminating the need for daily calibration
checks. Although the CoCo does not require daily field calibration, CI recommends an annual
calibration and performance verification by local CI service centers.
In order to perform calibration, you will need an accurate multimeter that is capable of measuring DC
and AC up to 1kHz.
To execute the System Calibration, first press the Setup hard button, then select System
Calibration.
Crystal Instruments Help - https://help.go-ci.com/
1/8
CoCo-80X and CoCo-90X Calibration
Advertisement
Related Manuals for Crystal Instruments CoCo-80X
Summary of Contents for Crystal Instruments CoCo-80X
- Page 1 2024/12/09 08:16 CoCo-80X and CoCo-90X Calibration CoCo-80X and CoCo-90X Calibration The CoCo loads factory calibration data during start up, eliminating the need for daily calibration checks. Although the CoCo does not require daily field calibration, CI recommends an annual calibration and performance verification by local CI service centers.
- Page 2 Last update: 2024/05/17 14:45 coco:calibrate https://help.go-ci.com/coco:calibrate To perform manual calibration, select Input and output calibration and adjustment and press Next. https://help.go-ci.com/ Printed on 2024/12/09 08:16...
- Page 3 2024/12/09 08:16 CoCo-80X and CoCo-90X Calibration The CoCo will now display some information regarding the calibration process. Press Next to begin. Crystal Instruments Help - https://help.go-ci.com/...
- Page 4 Last update: 2024/05/17 14:45 coco:calibrate https://help.go-ci.com/coco:calibrate Connect the CoCo output to the multimeter. The CoCo will then give instructions on how to perform the calibration. The operator will need to enter the multimeter readings into the CoCo. https://help.go-ci.com/ Printed on 2024/12/09 08:16...
- Page 5 2024/12/09 08:16 CoCo-80X and CoCo-90X Calibration Keep following the on-screen instructions. Both AC and DC measurements will be taken. After all measurements have been entered, the CoCo will validate the input channels. After this a window will Crystal Instruments Help - https://help.go-ci.com/...
- Page 6 Last update: 2024/05/17 14:45 coco:calibrate https://help.go-ci.com/coco:calibrate appear to insert calibration details such as the operator and calibration date. Finally, the CoCo will show the calibration report and what the results were after calibration. If there https://help.go-ci.com/ Printed on 2024/12/09 08:16...
- Page 7 2024/12/09 08:16 CoCo-80X and CoCo-90X Calibration are any Failed results, the calibration process will need to be repeated until they all PASS. Once all entries have passed, press Apply on the report screen to apply the adjustments. The Crystal Instruments Help - https://help.go-ci.com/...
- Page 8 NOTE: If a copy of the calibration report is needed, the Front-End Calibration Tool (FECT) will need to be purchased in order to obtain this report. From: https://help.go-ci.com/ - Crystal Instruments Help Permanent link: https://help.go-ci.com/coco:calibrate Last update: 2024/05/17 14:45 https://help.go-ci.com/...
