Description

Operation and Maintenance Manual for Oilgear Subsea Control POD Regulators

The information disclosed in this document is proprietary and confidential to Oilgear and/or its licensors and by accessing

this document you agree not to distribute or reproduce this document without Oilgear's prior written consent. Oilgear

retains all Intellectual Property for all designs and concepts developed by Oilgear which may be disclosed herein. Oilgear

and/or its licensors, as appropriate, reserve all patent, copyright and other proprietary rights contained in this document,

including all design, manufacturing, reproduction, use and sales rights thereto, except to the extent said rights are

expressly granted to others.

Relevant Models

Document Number

PERATION AND

UBSEA

HSR-20-N-01, MSR-20-N-01, MSR-08-N-01

EB#614S01

B E S T U N D E R P R E S S U R E

www.oilgear.com

EGUALTORS FOR

Rev. Date

9/6/2024

AINTENANCE

AND

ONTROL

The Oilgear Company

1424 International Drive

Traverse City, MI 49686

Phone: 231-929-1660

Rev.

ANUAL

POD

Table of Contents

Need help?

Do you have a question about the HSR-20-N-01 and is the answer not in the manual?

Questions and answers

Summary of Contents for OilGear HSR-20-N-01

Page 1 Operation and Maintenance Manual for Oilgear Subsea Control POD Regulators The information disclosed in this document is proprietary and confidential to Oilgear and/or its licensors and by accessing this document you agree not to distribute or reproduce this document without Oilgear’s prior written consent. Oilgear The Oilgear Company retains all Intellectual Property for all designs and concepts developed by Oilgear which may be disclosed herein.
Page 2: Table Of Contents
Hydraulic Connections ..........................6 Maintenance and Repair............................7 Maintenance Schedule ..........................7 Torque Specifications ..........................9 MSR-20-N-01 Regulator Maintenance ...................... 10 HSR-20-N-01 Regulator Maintenance ....................... 17 MSR-08-N-01 Regulator Maintenance ...................... 24 Troubleshooting ..............................31 General Troubleshooting Guidelines ......................31 Regulator Troubleshooting ........................31 Drawings ................................
Page 3: General Information
ENERAL NFORMATION This document is intended to provide a basic overview, operational description, recommended service intervals, and recommended spare parts for the Oilgear Subsea Pressure Regulators designed for use on 5 and 6 gen control PODs. Model numbers HSR-20-N-01, MSR-20-N-01, and MSR-08-N-01.
Page 4: Controlling Documents
Regulated Port Manifold – Seal Sub (5/8” OD) Vent Port 1/2” NPT (1/2”-14 NPTF) Controlling Documents The documents listed below are relevant to the design, installation and operation of the Oilgear POD regulators: Relevant Drawings and Documents Document Number Description EB#614S01...
Page 5: Safety And Personnel
The person(s) working with the regulator should be capable of working with basic hand tools and identifying mechanical components of a hydraulic system. Contact Oilgear for any further training or documentation regarding any issues related to Oilgear supplied equipment.
Page 6: Operational Descriptions
2.1.5 Component Life Expectancy Based on the listed operational requirements, Oilgear recommends a seal replacement period of every 5 years. Internal valve parts should be inspected or replaced as needed. Depending on use and operating conditions, preventative maintenance of valve kit components should be considered. Main external components should be evaluated by the user and not subject to any specific maintenance schedule.
Page 7: Maintenance And Repair
Part Number Description Relevant Model MSR-20-N-01 Regulator Replacement Valve Kit SSR-20-N-01VK HSR-20-N-01 (Includes supply valve cartridges and vent valve cartridges) Regulator Replacement Valve Kit MSR-08-N-01VK MSR-08-N-01 (Includes supply valve cartridges and vent valve cartridges) B E S T U N D E R P R E S S U R E Page 7 of 35 www.oilgear.com...
Page 8 5-Year Overhaul Oilgear recommends a 5-year interval between rebuild/seal overhaul of the regulator based on normal operation and seal life. The 5-year overhaul may be performed on the rig, or the regulator may be sent to an Oilgear facility for recertification.
Page 9: Torque Specifications
EO-Niromont. Do not use typical anti-seize lubricants containing metal or particulate on wetted components as it may introduce contamination into the valve or system. B E S T U N D E R P R E S S U R E Page 9 of 35 www.oilgear.com © 2024...
Page 10: Msr-20-N-01 Regulator Maintenance
4.3.1 Assembly Drawings – MSR-20-N-01 Figure 4-1: MSR-20-N-01 Assembly Isometric View B E S T U N D E R P R E S S U R E Page 10 of 35 www.oilgear.com © 2024...
Page 11 Operation and Maintenance Manual – Subsea Regulators for 5 and 6 Gen POD 9/6/2024 Figure 4-2: MSR-20-N-01 Assembly Exploded View B E S T U N D E R P R E S S U R E Page 11 of 35 www.oilgear.com © 2024...
Page 12 S0785 SPRING, MSR-MAIN SENSING   SSR-20-SV-01 REGULATOR SUPPLY VALVE   SSR-20-VV-02 REGULATOR VENT VALVE B E S T U N D E R P R E S S U R E Page 12 of 35 www.oilgear.com © 2024...
Page 13 8. Assembly for this stage is complete. Perform any air bleed procedures and test the regulator for appropriate performance and leakage prior to deployment. B E S T U N D E R P R E S S U R E Page 13 of 35 www.oilgear.com © 2024...
Page 14 15. Disassembly for this stage of repair is complete. B E S T U N D E R P R E S S U R E Page 14 of 35 www.oilgear.com © 2024...
Page 15 (5) with the four pins in the sensing cap (4). Firmly compress the spring can until it can be turned B E S T U N D E R P R E S S U R E Page 15 of 35 www.oilgear.com © 2024...
Page 16 7. Use a wrench to hold the adjustment stem (7) in place and tighten the lock nut (15). Then tighten the cap nut (22) to the lock nut. 8. Pressure adjustment is complete. B E S T U N D E R P R E S S U R E Page 16 of 35 www.oilgear.com © 2024...
Page 17: Hsr-20-N-01 Regulator Maintenance
6 Gen POD 9/6/2024 HSR-20-N-01 Regulator Maintenance This section will cover the maintenance information and procedures for the HSR-20-N-01 regulator. Procedures include valve replacement, seal replacement, overhaul component replacement, and required disassembly and assembly instructions. 4.4.1 Assembly Drawings – HSR-20-N-01...
Page 18 Operation and Maintenance Manual – Subsea Regulators for 5 and 6 Gen POD 9/6/2024 Figure 4-4: HSR-20-N-01 Assembly Exploded View B E S T U N D E R P R E S S U R E Page 18 of 35 www.oilgear.com...
Page 19 EB#614S01 Revision D Operation and Maintenance Manual – Subsea Regulators for 5 and 6 Gen POD 9/6/2024 4.4.2 Bill of Materials – HSR-20-N-01 Bill of Material for HSR-20-N-01 Valve Item Part No. Description Overhaul 07546-01 BODY-MSR-20 07547-01 END CAP 07548-04...
Page 20 8. Assembly for this stage is complete. Perform any air bleed procedures and test the regulator for appropriate performance and leakage prior to deployment. B E S T U N D E R P R E S S U R E Page 20 of 35 www.oilgear.com © 2024...
Page 21 14. Disassembly for this stage of repair is complete. B E S T U N D E R P R E S S U R E Page 21 of 35 www.oilgear.com © 2024...
Page 22 18. Align the vent cap (3) over the vent valve (21) and secure it using the six 1/4" bolts (10). Torque bolts per section 0. B E S T U N D E R P R E S S U R E Page 22 of 35 www.oilgear.com © 2024...
Page 23 Thread the nipple into the reducer then thread into the NPT port on the pilot cap (6). Be sure that the nipple (15) is the straight-through type supplied with the Oilgear HSR. Some legacy regulators use a restricted nipple on the pilot port which may hinder the performance of the Oilgear regulator.
Page 24: Msr-08-N-01 Regulator Maintenance
Procedures include valve replacement, seal replacement, overhaul component replacement, and required disassembly and assembly instructions. 4.5.1 Assembly Drawings – MSR-08-N-01 Figure 4-5: MSR-08-N-01 Assembly Isometric View B E S T U N D E R P R E S S U R E Page 24 of 35 www.oilgear.com © 2024...
Page 25 Operation and Maintenance Manual – Subsea Regulators for 5 and 6 Gen POD 9/6/2024 Figure 4-6: MSR-08-N-01 Assembly Exploded View B E S T U N D E R P R E S S U R E Page 25 of 35 www.oilgear.com © 2024...
Page 26 SPRING, MSR-MAIN SENSING   SSR-08-SV-01 1/2" REGULATOR SUPPLY VALVE   SSR-08-VV-02 1/2" REGULATOR VENT VALVE B E S T U N D E R P R E S S U R E Page 26 of 35 www.oilgear.com © 2024...
Page 27 7. Assembly for this stage is complete. Perform any air bleed procedures and test the regulator for appropriate performance and leakage prior to deployment. B E S T U N D E R P R E S S U R E Page 27 of 35 www.oilgear.com © 2024...
Page 28 16. Disassembly for this stage of repair is complete. B E S T U N D E R P R E S S U R E Page 28 of 35 www.oilgear.com © 2024...
Page 29 Then align the stem with the can and thread the adjuster fully onto the stem. B E S T U N D E R P R E S S U R E Page 29 of 35 www.oilgear.com © 2024...
Page 30 7. Use a wrench to hold the adjustment stem (4) in place and tighten the lock nut (13). Then tighten the cap nut (18) to the lock nut. 8. Pressure adjustment is complete. B E S T U N D E R P R E S S U R E Page 30 of 35 www.oilgear.com © 2024...
Page 31: Troubleshooting
1. Always vent all pressure from the system prior to removing components. 2. Standby vent leakage is often a sign of an internal problem. For this reason, Oilgear recommends venting the regulator directly to atmosphere through use of a short tube or open port. This allows problems to be more easily traced to a single component.
Page 32: Drawings
Revision D Operation and Maintenance Manual – Subsea Regulators for 5 and 6 Gen POD 9/6/2024 RAWINGS B E S T U N D E R P R E S S U R E Page 32 of 35 www.oilgear.com © 2024...
Page 33 Revision D Operation and Maintenance Manual – Subsea Regulators for 5 and 6 Gen POD 9/6/2024 B E S T U N D E R P R E S S U R E Page 33 of 35 www.oilgear.com © 2024...
Page 34 Revision D Operation and Maintenance Manual – Subsea Regulators for 5 and 6 Gen POD 9/6/2024 B E S T U N D E R P R E S S U R E Page 34 of 35 www.oilgear.com © 2024...
Page 35 Revision D Operation and Maintenance Manual – Subsea Regulators for 5 and 6 Gen POD 9/6/2024 B E S T U N D E R P R E S S U R E Page 35 of 35 www.oilgear.com © 2024...

This manual is also suitable for:

Msr-20-n-01 Msr-08-n-01
