Kamar L1857-B User Manual

User manual
L1857-B
Set lamp LED with magnes + wire 7,5m blister
Technical data
• Product dimensions: 106x99mm
• Cable: 2,5m + 7,5m ended 7PIN plug 12V
• Working voltage: 12/24V
• Approvals, certificates:
ECE R3, R4, R6, R7, R10
• LED quantity: 2x14pcs
• Material of execution:
Housing: ABS
Lens: PMMA
• Working temperature: from -30°C to + 60°C
Functions
• Rear lamp set LED
• For automo ve use only
• The lamp has road approval ECE R3, R4, R6, R7, R10 authorizing it to be used on public roads, (permanent assembly)
• The lamp is intended for vehicles with 12V installation
Mounting method
• Installation only in specialized workshops or professional service
• Lamps must be installed only in accordance with the UNECE regulations
Wire connection
FUNCTION
Indicator left
Indicator Right
Position Left
Position Right
The connection between the lamp and vehicle's installation should be isolated with heat-shrink
tube, to avoid getting water and moisture to the copper wire of the lamp, which can damage
electronic components and flood the lamp with water.
Warnings
• Use as intended
• Use in airly places
• The maximum speed of a vehicle with a beacon attached to the roof with a magnet is 50 km/h
• Do not touch the lamp during operation and immediately after it is turned off, the lamp may get warm
Any unauthorized interference with the lamp (associated with its depressurization, interference with the electronic system, etc.) is associated with the loss of
•
warranty
• The device must be installed and keeped out of reach of children
• Do not cut off tinned ends.
We reserve the right to change technical data and possible errors. Photos/drawing and
technical data are only illustrative, and given product may slightly differ from them. Coping
the part or the entire package without the written authorization is forbidden. All rights
reserved.
WIRES COLOR
White
Ground
Yellow
Green
Black
Brown
Red
STOP
Important! Do not look directly in the light. It can cause the the eye damage
Mounting lamps with a magnet not for use on public road
Importer: KAMAR Knapkiewicz S.K.A.
Terms of warranty:
- we provide a guarantee for a period of 24 months from the date of sale,
- any unauthorized interference with the item entails the loss of the guarantee.
al. Armii Krajowej 254
85-689 Bydgoszcz, Poland
Country of origin: PRC
www.myKAMAR.com
