Rev.1.00.230210.
This manual consists of system introduction, system installation, system use, system expansion and appendix A/B
KIOSK System
Electronic
Manuals

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASTAR263 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sam4s ASTAR263

  • Page 1 KIOSK System Electronic Manuals Rev.1.00.230210. This manual consists of system introduction, system installation, system use, system expansion and appendix A/B...

  • Page 2: Table Of Contents

    Contents Part 1. System Introduction Appendix A. BIOS Set Up 01. Safety Notices Before Installation or Use 01. Understanding BIOS 02. System Introduction 02. Serial voltage change & Using Keyboard shortcut 03. Specifications 04. Name and Function of each component (Front View) Appendix B.

  • Page 3: Part 1. System Introduction

    Part 1. System Introduction 01. Safety Notices Before Installation or Use Use the following safety guidelines to help ensure your own personal safety and to help protect. your equipment and working environment from potential damage. Caution Keep rated voltage. The product can be damaged or burned by overvoltage. Do not use damaged components.
  • Page 4 Part 1. System Introduction 01. Safety Notices Before Installation or Use Use the following safety guidelines to help ensure your own personal safety and to help protect. your equipment and working environment from potential damage. Caution Use the cleaner which is only for computer. Do not use benzene, thinner and alcohol or the product may be damaged.

  • Page 5: System Introduction

    Part 1. System Introduction 02. System Introduction The exterior design and specifications of product can be changed without prior notice in order to improve quality. Adaptor / Power cable Lock Key Cap Rubber Quick manual KIOSK System Electronic Manuals l...

  • Page 6: Specifications

    Part 1. System Introduction 03. Specifications Model ASTAR263 ASTAR363 ASTAR563 21.5inch (1920 X 1080 / FHD) Display Touch 10 Points support(PCAP) Intel Celeron J6412 Intel Core i3-1115G4 Intel Core i5-1135G4 (Quad Core up to 2.6GHz) (Dual Core up to 4.1GHz) (Dual Core up to 4.2GHz)

  • Page 7: Name And Function Of Each Component (Front View)

    Part 1. System Introduction 04. Name and Function of each component (Front View) Multi Touch EFT (Option) Barcode Scanner EFT Cover(Front) Printer Outlet (Printer) Lock key KIOSK System Electronic Manuals l...

  • Page 8: Name And Function Of Each Component (Side/Rear View)

    Part 1. System Introduction 05. Name and Function of each component (Side/Rear View) Use the following safety guidelines to help ensure your own personal safety and to help protect. your equipment and working environment from potential damage. Speaker (Left/Right) EFT Cover(Side) EFT (Option) Power Button KIOSK System Electronic Manuals l...

  • Page 9: Name And Function Of Each Component (I/O)

    Part 1. System Introduction 06. Name and Function of each component (I/O) • J6412 D-SUB 9P Serial Port D-SUB 9P Serial Port Audio Port(Line Out) RJ-45 LAN(Ethernet) Port USB 3.0 Port RJ-45 8P Serial Port USB 3.0 Port Display Port (VGA) 12V DC Power Input 12V DC Power Output D-SUB 9P Serial Port...
  • Page 10 Part 1. System Introduction 06. Name and Function of each component (I/O) • i3 / i5 D-SUB 9P Serial Port Audio Port(Line Out) USB 3.0 Port RJ-45 LAN(Ethernet) Port RJ-45 LAN(Ethernet) Port USB 3.0 Port D-SUB 9P Serial Port HDMI Port HDMI Port 12V DC Power Input D-SUB 9P Serial Port...

  • Page 11: Part 2. System Installation

    Part 2. System Installation 01. Open the Rear Cover Remove the rubber cap(ⓐ) and screw(ⓑ) as shown in the picture and the "Rear Cover" in the direction of the arrow to connect the peripheral device cables. • When removing the cover, wear gloves to avoid damaging the edges of the device. Cautions ⓑ...

  • Page 12: Connect Peripheral Devices

    Part 2. System Installation 02. Connect Peripheral Devices • Connect peripherals after turning off the device. • Please use gloves to prevent injury from the edge of the equipment. Cautions • Check the printed I/O specifications before connect peripheral cables. Camera Mouse Keyboard...

  • Page 13: Connect Power Cable

    Part 2. System Installation 03. Connect Power Cable • Connecting AC power supply cable Connect the AC power cable to the AC power input connector at the bottom of the system. (Adapter 100V – 220V free voltage of the system can be used.) Power Inlet LAN (Ethernet) 2xUSB 2.0...

  • Page 14: Printer Usage

    Part 2. System Installation 04. Printer Usage 1. Turn the lock key clockwise. 2. Press the open button to open the cover and remove the core of the roll paper. 3. Pay attention to the direction when loading paper. (Refer to the picture) 4.

  • Page 15: Part3. System Utilization

    Part3. System Utilization 01. Using Touch Screen During the use of touch screen, when the accuracy becomes an is sue, please re-do coordination adjustment. 1. Right click on the icon located at the lower right corner of menu and Click on Setting Tab of ACDC Touch Studio. 2.
  • Page 16 Part3. System Utilization 01. Using Touch Screen • Do not use sharp objects such as pen as it may damage surface of the display. Cautions 4. Click on Calibrate button to proceed coordination adjustment. 5. Proceed coordination adjustment by clicking Calibrate button. KIOSK System Electronic Manuals l...

  • Page 17: Introducing Pos Driver And Utility

    1. The driver and utility is inside the C:＼Util_Drivers folder of the window installed on the storage device. Adobe Reader 11.0 : The Adobe Reader program is inside the folder. MiniPrinter : The window driver for SAM4S printer is inside the folder. MS Excel Viewer : The Microsoft excel viewer program is inside the folder.
  • Page 18 Part3. System Utilization 02. Introducing POS Driver and Utility Drawer Driver : Cash Drawer Driver Installation file is inside the folder. MSR : MSR Setup file is inside the folder. OPOS : OPOS driver installation file is inside the folder. Self TestProgram : Test programs for dealers are inside folder.

  • Page 19: Part4. System Extension & Disassemble

    Part4. System Extension & Disassemble 01. EFT Terminal (Front) Please refer to Part2. 01. Open the Rear Cover to remove the "Rear Cover" Note After arranging the cables of the EFT terminal, adjust the positions of the 4 screws to fix the terminal firmly. Cable arrangement KIOSK System Electronic Manuals l...
  • Page 20 Part4. System Extension & Disassemble 01. EFT Terminal (Front) After unscrewing the 4 screws to remove the DUMMY MSR, assemble the EFT terminal with the 4 screws again. KIOSK System Electronic Manuals l...
  • Page 21 Part4. System Extension & Disassemble 01. EFT Terminal (Front) Connect the EFT terminal cable to the I/F of the system and close the COVER REAR. EFT Terminal EFT Terminal Connection KIOSK System Electronic Manuals l...

  • Page 22: Eft Terminal (Side)

    Part4. System Extension & Disassemble 02. EFT Terminal (Side) Remove the COVER EFT by unscrewing the two screws, arrange the cables of the EFT terminal Cable arrangement KIOSK System Electronic Manuals l...
  • Page 23 Part4. System Extension & Disassemble 02. EFT Terminal (Side) adjust the position of the four screws to fix the terminal firmly, and assemble the cover EFT with the two screws. KIOSK System Electronic Manuals l...
  • Page 24 Part4. System Extension & Disassemble 02. EFT Terminal (Side) Please refer to Part2. 01. Open the Rear Cover to remove the "Rear Cover" Note Remove DUMMY EFT by unscrewing a screw and assemble the EFT terminal with two screws. Connect the EFT terminal cable to the I/F of the system and close the COVER REAR.
  • Page 25 Part4. System Extension & Disassemble 02. EFT Terminal (Side) Remove DUMMY EFT by unscrewing a screw and assemble the EFT terminal with two screws. Connect the EFT terminal cable to the I/F of the system and close the COVER REAR. EFT Terminal EFT Terminal Connection KIOSK System Electronic Manuals l...

  • Page 26: Ssd & Memory

    Part4. System Extension & Disassemble 03. SSD & Memory Please refer to Part2. 01. Open the Rear Cover to remove the "Rear Cover" Note 2.5" SSD Remove the SSD from the location shown in the picture in an upward direction. (Some models may not support 2.5"...

  • Page 27: Wifi

    Part4. System Extension & Disassemble 04. WiFi Please refer to Part2. 01. Open the Rear Cover to remove the "Rear Cover" Note WiFi Antenna WiFi Module KIOSK System Electronic Manuals l...
  • Page 28 Part4. System Extension & Disassemble 04. WiFi Assemble the WiFi module with a screw as shown in the picture. Attach the two WiFi antennas to the locations shown in the picture and connect the cables to the terminals on the WiFi module. Antenna attachment direction Attaching Filament Tape KIOSK System Electronic Manuals l...

  • Page 29: Lcd

    Part4. System Extension & Disassemble 05. LCD Please refer to Part2. 01. Open the Rear Cover to remove the "Rear Cover" Note • Disassemble the screws after separating the TOUCH FPC and SCANNER CABLE from the set. Cautions KIOSK System Electronic Manuals l...
  • Page 30 Part4. System Extension & Disassemble 05. LCD After separating the touch fpc and the scanner cable from the set, unscrew fifteen screws and remove the MAIN BODY ASSY. KIOSK System Electronic Manuals l...
  • Page 31 Part4. System Extension & Disassemble 05. LCD Unscrew four screws and remove the LCD. KIOSK System Electronic Manuals l...

  • Page 32: Printer

    Part4. System Extension & Disassemble 06. Printer Please refer to Part2. 01. Open the Rear Cover to remove the "Rear Cover" Note After separating the printer cable from the set, unscrew five screws. KIOSK System Electronic Manuals l...
  • Page 33 Part4. System Extension & Disassemble 06. Printer remove the printer. KIOSK System Electronic Manuals l...

  • Page 34: Stand

    Part4. System Extension & Disassemble 07. Stand • For the safety of this product, the floor must be It must be installed on a flat surface. • The stand must be anchored (screw) Secure it firmly so that it does not move or fall. Cautions Remove 6 screws and remove plate.

  • Page 35: Wall Mount

    Part4. System Extension & Disassemble 08. Wall Mount ① Mark on wall where parts are installed. ② Drill hole with 8.5mm external diameter and 60mm deep. After drilling, insert the 6 included anchors into the hole. ③ Secure the bracket to the anchor of the wall mount hole with the included screw.
  • Page 36 Part4. System Extension & Disassemble 08. Wall Mount • After connecting the cables, install the wall mount. • After installing the wall mount, be sure to check that it is securely fixed. Cautions Secure the 4 wall mount holders with the included screws.

  • Page 37: Appendix A. Bios Set Up

    Appendix A. BIOS Set Up 01. Understanding BIOS • Understanding BIOS Set up BIOS provides configuration and set up information for driving the main board. BIOS values are saved in CMOS ROM on the main board. BIOS(Basic Input and Output System) Setup is a menu-oriented software utility which enables a user to configure the system’s environmental set up, system hardware, power saving functions, etc.

  • Page 38: Serial Voltage Change & Using Keyboard Shortcut

    Appendix A. BIOS Set Up 02. Serial voltage change & Using Keyboard shortcut 1. Advanced Menu Use this menu to set up for system performance. • Advanced > Onboard Device Configuration > COM port 'n' power delivery : This item allows you to set the output voltage value of Serial port 1/2 PIN9 type This item allows you to set the output voltage value of Serial port 3 PIN1 type 2.

  • Page 39: Appendix B. System Configuration

    Appendix B. System Configuration 01. System Block Diagram • Elkhart Lake (J6412) System Block Diagram LVDS CONN 2 x Channel eDP to LVDS Bridge 2 x SODIMM 2*20pin header ANALOGIX_ANX1122FN DDR4 3200 MAX 32GB DDI 1 SVID VGA Port DP to VGA VCORE DB15 REALTEK_RTD2166-AS1...

  • Page 40: Main Chipset & Connector

    Appendix B. System Configuration 02. Main Chipset & Connector • Elkhart Lake (J6412) Main Chipset & Connector SODIMM DDR4 SODIMM DDR4 SDRAM SLOT A SDRAM SLOT B SERIAL FLASH BIOS SATAIII CONNECTOR SERIAL (COM4) SATAIII PCIe m.2 SSD SLOT SERIAL (COM6) SERIAL (COM5) Intel Celeron CPU J6412 CPU...
  • Page 41 Appendix B. System Configuration 02. Main Chipset & Connector • Core i3/i5 LVDS Backlight Control Pin Header EDP Backlight Control LVDS VDD GPIO Pin Pin Header Select Jumper Header LVDS Signal SIM Card KeyBoard & Mouse Pin Header EDP VDD Select Jumper Slot Pin Header Cash Drawer Pin Header...

  • Page 42: Main Jumper Setting

    Appendix B. System Configuration 03. Main Jumper Setting • Elkhart Lake (J6412) Main Jumper Setting JCMOS1 JTXE _P80_ JEUP1 (ME DEBUG MODE) AUTOPWR1 PORT80 JINVERTER1 JBLR JPWM JLV1 JLV1(Voltage Provided to Panel) Function Jumper Pin JINVERTER1(Voltage Provided to Panel Backlight) 3.3V 1 - 2 (Default) Function...
  • Page 43 Appendix B. System Configuration 03. Main Jumper Setting • I3/I5 Main Jumper Setting JC_EDP1 JC_LVDS1 JC_COM5/6 CLR-CMOS [7] EDP VDD Select Jumper (3*1 Pin 2.54mm) Location Setting Function 1-2 (Default) +3.3V JC_EDP1 [10] LVDS VDD Select Jumper (3*2 Pin 2.54mm) Location Setting Function...

  • Page 44: Io Pin Map

    Appendix B. System Configuration 04. IO Pin map • COM1/2 RS-232 Serial Port • COM3 RS-232 Serial Port (RJ-45) (D-SUB9 MALE) Pin Num Description Pin Num Description Ring / +5V / +12V Ring / +5V / +12V • LAN Port (RJ-45) •...

  • Page 45: Parts List

    Appendix B. System Configuration 05. Parts List •SET TOTAL KIOSK System Electronic Manuals l...
  • Page 46 Appendix B. System Configuration 05. Parts List Part Code Part Name Q'TY Serviceable Remark JK70-20621A IPR-PLATE SUPPORT, WHITE S600100039A SCREW-MACHINE ; PWH, M4, L8 PACKAGE SKE-AFW(STD) EFT BRKT, FRONT, WHITE SKS-NAW(STD) STAND, WHITE ASSY-MAIN BODY SKE-ARW(STD) EFT BRKT, RIGHT, WHITE JK73-11023A RMO-FOOT RUBBER JK70-70151A...
  • Page 47 Appendix B. System Configuration 05. Parts List •MAIN BODY KIOSK System Electronic Manuals l...
  • Page 48 Appendix B. System Configuration 05. Parts List Part Code Part Name Q'TY Serviceable Remark JK72-21224A PMO-COVER REAR,WHITE JK73-11025B RMO-CAP RUBBER,WHITE JK95-71020A ASSY MAIN BODY,WHITE S600100016A SCREW-MACHINE:PWH,M3,L4 JK48-10057A LED Backlight Driver JK07-70016B LCD Panel,21.5" JK70-20616A IPR-BRKT LCD JK48-10031B CONTROLLER BOARD JK48-10060A SCANNER JK49-10038A MOTHER BOARD,J6412...
  • Page 49 Appendix B. System Configuration 05. Parts List Part Code Part Name Q'TY Serviceable Remark S600200028A SCREW-TAPPING;PWH,M3,L6 JK48-10011C WiFi/Bluetooth module S421000024A WiFi ANTENNA S600100021A SCREW-MACHINE:RH,M2,L4 M.2 SSD RAM,DDR4 JK70-20620A IPR-BRKT PRINTER JK72-21212A PMO-LEVER OPEN,WHITE JK75-50022A LOCK JK95-70997A ASSY-GCUBE,KIOSK,WHITE S600200003A SCREW-TAPPING:PH,M4,L10 KIOSK System Electronic Manuals l...
  • Page 50 Appendix B. System Configuration 05. Parts List KIOSK System Electronic Manuals l...
  • Page 51 Appendix B. System Configuration 05. Parts List Part Code Part Name Q'TY Serviceable Remark SKE-AFW(STD) EFT BRKT,FRONT,WHITE JK72-21225B PMO-COVER EFT,WHITE S600100046A SCREW-MACHINE:PWH,M4,L6,BLACK JK70-20622A IPR-HOLDER EFT,WHITE JK70-20623A IPR-BRKT EFT,WHITE JK73-11087B RMO-FOOT RUBBER,BLACK S600200006A SCREW-TAPPING:PWH,M3,L8 S600200006A SCREW-TAPPING:PWH,M3,L8 PACKAGE KIOSK System Electronic Manuals l...
  • Page 52 Appendix B. System Configuration 05. Parts List KIOSK System Electronic Manuals l...
  • Page 53 Appendix B. System Configuration 05. Parts List Part Code Part Name Q'TY Serviceable Remark SKE-ARW(STD) EFT BRKT,RIGHT,WHITE JK70-20624A IPR-HOLDER EFT_RH,WHITE S600100046A SCREW-MACHINE:PWH,M4,L6,BLACK JK70-20623A IPR-BRKT EFT,WHITE JK73-11087B RMO-FOOT RUBBER,BLACK JK70-20625A IPR-COVER EFT,WHITE JK70-20626A IPR-SUPPORT EFT_RH,WHITE S600100017A SCREW-MACHINE:PWH,M3,L6 S600100046A SCREW-MACHINE:PWH,M4,L6,BLACK PACKAGE KIOSK System Electronic Manuals l...
