VELTOP Modulo 3 Assembly Instructions

Download this manual

Veltop Modulo 3

Assembly instructions

Thank you for choosing the Veltop Modulo 3 model.

This product is designed, manufactured, and assembled by CYCLO-SYSTEM, located in Haute-Savoie

(74), France. To ensure proper use, optimal performance, and a long life for your new accessory, please

read and carefully follow the usage and assembly instructions.

This model can be installed on any mobility scooters compatible with the front and rear mounts listed

below.

Assembly video

Warning

Failure to follow this manual may impair the protection's functionality and cause certain parts to fail. This could compromise the

effectiveness of the system and endanger your safety during travel.

Choice of two rear mounts

Front mounting

Seat square tube fixation

Headrest fixation

Plate fixation

Product contents

Screws / Spacers / Washers

Windshield

Allen key

Side panels with armrest

fixations

Front structur

Tubular structure

Canopy

Need help?

Do you have a question about the Modulo 3 and is the answer not in the manual?

Page 1 Veltop Modulo 3 Assembly instructions Thank you for choosing the Veltop Modulo 3 model. This product is designed, manufactured, and assembled by CYCLO-SYSTEM, located in Haute-Savoie (74), France. To ensure proper use, optimal performance, and a long life for your new accessory, please read and carefully follow the usage and assembly instructions.
Page 2 Mounting rear attachments Rear attachment to the headrest Rear attachment on the square tube under the seat Remove the scooter’s headrest, insert the tubes between the Place the square tube welded to the plate under the seat two mounting plates, and tighten. Then, place the headrest so that the vertical tube can be centred in the middle of the back into position.
Page 3 Mounting the tubular structure Assemble the tubular structure and centre it in the brackets of the rear attachment. Installing the canopy Attach the canopy to the frame, starting from the front. Then, place the elastic bands on the horizontal tube. Attaching the side panels Use the zipper to attach the side protections to the canopy.
Page 4 Reattach your basket support to the top of the front plate before placing your basket. CYCLO-SYSTEM 3621 route d’Albertville 74320 SEVRIER FRANCE T : 0033 (0)4 50 77 56 17 F : 0033 (0)4 50 63 45 36 info@veltop.com www.veltop.eu/en SKU: VELMOD3...
