Panasonic SA-PT550GC Service Manual
Panasonic SA-PT550GC Service Manual

Panasonic SA-PT550GC Service Manual

Dvd home theater sound system
Table of Contents

Advertisement

Quick Links

Specifications
lGENERAL
Power Supply:
Power Consumption:
Power Consumption in Standby Mode:
Dimensions (W×H×D):
Mass:
Operating Temperature Range:
Operating Humidity Range:
lAMPLIFIER SECTION
RMS Output Power: Dolby Digital Mode
lTotal RMS Dolby Digital mode power:
At 1 kHz and total harmonic of 10%
lFront Ch:
lCenter Ch:
lSurround Ch:
At 100 Hz and total harmonic of 10%
AC 110-127 V/220-240 V,
50/60 Hz
140 W
approx. 0.8 W
430×60×364.4 mm
Main unit approx. 3.5 kg
+5°C to +35°C (+41°F to
+95°F)
5% to 90% RH (no
condensation)
1000 W
125 W / Channel (3 Ω)
250 W / Channel (6 Ω)
125 W / Channel (3 Ω)
DVD Home Theater Sound System
SA-PT550GC
SA-PT550GCS
SA-PT550GCT
SA-PT550GS
Colour
(S).......................Silver Type
lSubwoofer Ch:
PMPO Output Power:
DIN Output Power: Dolby Digital Mode
lTotal DIN Dolby Digital mode power:
At 1 kHz and total harmonic of 1%
lFront Ch:
lCenter Ch:
lSurround Ch:
At 100 Hz and total harmonic of 1%
lSubwoofer Ch:
lFM TUNER, TERMINALS SECTION
Preset Memory:
Frequency Modulation (FM)
Frequency range:
Sensitivity:
S/N 26 dB:
Antenna terminals:
Digital Audio Input:
© 2007 Matsushita Electric Industrial Co., Ltd. All
rights
reserved.
distribution is a violation of law.
ORDER NO. MD0705018CE
250 W / Channel (6 Ω)
7500 W
590 W
75 W / Channel (3 Ω)
145 W / Channel (6 Ω)
75 W / Channel (3 Ω)
145 W / Channel (6 Ω)
FM 30 stations
87.50-108.00 MHz
(50-kHz step)
1.8 µV (IHF)
1.4 µV
75 Ω (unbalanced)
