- Page 1 USER MANUAL LiFEPO4 51.2V/5.1KWh & 10.2KWh Batteries VER. 2411.06 ENGLISH USER MANUAL BM-LFP-WALL-5KWh-51.2V BM-LFP-WALL-10KWh-51.2V WALL & FLOOR MOUNT BATTERY LFP BATTERY MODULE Technical information on this manual is property of XMART This manual Information cannot be copied or distributed totally ...
-
Page 2: Limitation Of Liability
USER MANUAL LiFEPO4 51.2V/5.1KWh & 10.2KWh Batteries LIMITATION OF LIABILITY The preparation of the site, wiring, installation, and operation of this product by the user or their technicians will not be the responsibility of the distributor or the manufacturer XMART-UPS. The site will be prepared by the end user or their electrical contractor and must comply with the current local electrical regulations and the operating specifications of this product. -
Page 3: Product Description
USER MANUAL LiFEPO4 51.2V/5.1KWh & 10.2KWh Batteries 2. PRODUCT DESCRIPTION This battery belongs to the Lithium-Ion group, specifically the LiFePO4 type (Lithium Iron Phosphate, abbreviated as LFP). This is the safest type of Lithium battery, but all safety, storage, and operation regulations must be followed to avoid overheating, fire, and/or explosions. - Page 4 USER MANUAL LiFEPO4 51.2V/5.1KWh & 10.2KWh Batteries Operation Interface (Right View): 7. Address Dip Switch (ADD) 8. Indicator LEDs 9. DC Breaker 10. ON/OFF Button COMM. PORT PIN OUT DESCRIPTION 1: RS485_B RS485 PIN MAP 2: RS485_A 3, 4, 5, 6, 7, 8: NC 1, 2, 3, 4, 5, 6: NC LINK-IN/LINK-OUT PIN MAP 7: RS485-2_A...
-
Page 5: Storage And Transportation
USER MANUAL LiFEPO4 51.2V/5.1KWh & 10.2KWh Batteries ADDRESS DIP SWITCH (ADD): When connecting batteries in parallel, each battery must have a unique address defined by ADD Dip Switch, according to the following table: ADD Setting ADD Setting ADD Setting NOTES: Battery Module with ADD Setting=1 is the Master Battery Module, capable of communicating with the inverter. -
Page 6: Connection Instructions
USER MANUAL LiFEPO4 51.2V/5.1KWh & 10.2KWh Batteries To maintain the batteries' state of charge at an optimal level, they should be recharged periodically: Storage at 25ºC: Recharge once every 6 months. Storage at 40ºC: Recharge once every 3 months. This product passes the certifications of the UN38.3 and belongs to class 9 dangerous goods. -
Page 7: Battery Recharge
USER MANUAL LiFEPO4 51.2V/5.1KWh & 10.2KWh Batteries 5. BATTERY RECHARGE This kind of battery is designed to replace VRLA batteries, but it is mandatory that the chargers used to recharge these batteries have the appropriate technology (constant current chargers in the "bulk" phase) and must be configurable to adjust their charging parameters (voltages and currents) for this type of lithium battery. -
Page 8: Battery Discharge
USER MANUAL LiFEPO4 51.2V/5.1KWh & 10.2KWh Batteries CHARGING CURRENT FOR XMART LIFEPO4 51.2V – 5.1KWh/100AH & 10.2KWh/200AH BATTERIES The maximum charging current depends on the environment temperature. It is important to adjust the charger's maximum current depending on the site temperature. When in doubt or in environments with variable temperatures, it is recommended to be conservative and use the lower current. - Page 9 USER MANUAL LiFEPO4 51.2V/5.1KWh & 10.2KWh Batteries Accessories for Floor Mounting 2 Floor Mounting Bracket 2 pcs outer hexagon inner cross combination bolt M6X16mm screws Accessories for Wall Mounting Wall mounting Bracket 4 pcs outer hexagon inner cross combination bolt M8X16mm screws 8 pcs stainless steel expansion screws M8*100mm...
- Page 10 USER MANUAL LiFEPO4 51.2V/5.1KWh & 10.2KWh Batteries - Fix wall mounting bracket to the wall and fasten the screw head of the expansion bolts - Use a proper hammer to fit the expansion bolt into the holes. The screw head protuberance could interfere with the battery cabinet.
- Page 11 USER MANUAL LiFEPO4 51.2V/5.1KWh & 10.2KWh Batteries 10KWh – Wall Mount - Fix the bracket to the battery using 4 M8X16mm bolts included with the battery. - Look at the image on the right for reference. Red arrows point to screws. - Drill 8 pcs Φ10 *110mm holes on the wall, according to dimensions in the image on the right.
- Page 12 USER MANUAL LiFEPO4 51.2V/5.1KWh & 10.2KWh Batteries 10KWh – Floor Mount - Fix the floor mounting brackets to the battery using 2 M8X16mm bolts included with the battery. - Drill two holes on the wall according to the dimensions shown in the imagen on the right.
- Page 13 USER MANUAL LiFEPO4 51.2V/5.1KWh & 10.2KWh Batteries Wiring – Single Inverter & Single Battery The following procedure and image explain how to connect the battery and the inverter. For details about the inverter installation, refer to the inverter User Manual. - Make sure the battery breaker is in off condition.
- Page 14 USER MANUAL LiFEPO4 51.2V/5.1KWh & 10.2KWh Batteries - Connect Link-Out Port from Master Battery 1 to Link-In Port of Battery Module with ID Code=2, then connect Link-Out Port of this battery to Link-In of Battery Module with ID Code=3, and so on until finishing with all batteries. Refer to the following image for reference.
-
Page 15: Technical Specifications
USER MANUAL LiFEPO4 51.2V/5.1KWh & 10.2KWh Batteries 8. TECHNICAL SPECIFICATIONS BATTERY MODULES LFP 51.2V BM-LFP-WALL-5KWH-51.2V BM-LFP-WALL-10KWH-51.2V Mounting Type / Tipo de Montaje Wall & Floor / Pared y Suelo 2 (Black & Red) 25 mm2, L=1500mm. 2 (Black & Red) 50 mm2, L=1500mm. Battery Cables / Cables de Batería Terminals: SC25-M6 (Batt) &... - Page 16 USER MANUAL LiFEPO4 51.2V/5.1KWh & 10.2KWh Batteries ANNEX 1. COMMUNICATION WITH INVERTERS The T568B communication cable included with your battery is designed to interconnect batteries through their Link-Out and Link-In ports, allowing their BMS units to communicate and coordinate parallel operation. To connect an individual battery or the Master Battery in a parallel system to a Xmart inverter with a DC voltage compatible with BM-LFP-WALL-51.2V batteries, the T568B cable must be modified to make one end compatible with the inverter's BMS port.
