KAVAN Smart PRO GPS2 Logger - Instruction manual
INTRODUCTION
Congratulations on purchasing the Smart PRO GPS2 Logger, a telemetry device that offers fast and accurate real-time position detection and feedback. It
uses multiple satellite navigation systems to achieve maximum precision and resolution. Logging all the data is possible due to its large integrated Flash
memory. The logged data can be downloaded and analyzed on a computer using the free MAV Manager software.
FEATURES
Small dimensions, high measurement accuracy
Large industrial memory for data logging
Latest generation GPS chipset supporting multiple satellite systems
3-axis magnetometer/compass for external navigation purposes
Backup supercapacitor for fast position fix after powering off
Voltage measurement and logging
Automatic telemetry detection: FPort, Duplex EX, Hott, MSB, S.Bus2, P²Bus. Automatic timezone detection
Configuration through the transmitter or MAV Manager
Firmware updates.
TECHNICAL SPECIFICATIONS
Dimensions: 28×30×9 mm
Weight: 14 g
Memory: 256 MB
Supported positioning systems: GPS, GALILEO, GLONASS
Recording time (5 samples/s): 66 hours
Sampling: 10 Hz, 5 Hz, 2 Hz, 1 Hz
Flash endurance: 100 000 erase cycles
Operating current: 50 mA
Operating temperature: (-20)–85 °C
Supply Voltage: 3.5–8.4 V
Telemetry: FPort, Duplex EX, Multiplex MSB, Graupner Hott, Futaba S.Bus2, PowerBox P²Bus
Status LED: Yes
GNSS receiver sensitivity: -167 dBm
GNSS max. acceleration: 4G
AVAILABLE TELEMETRY
The telemetry options depend on the radio control system. The complete data are automatically logged in the internal Flash memory.
Advertisement
Summary of Contents for Kavan Smart PRO GPS2 Logger
- Page 1 INTRODUCTION Congratulations on purchasing the Smart PRO GPS2 Logger, a telemetry device that offers fast and accurate real-time position detection and feedback. It uses multiple satellite navigation systems to achieve maximum precision and resolution. Logging all the data is possible due to its large integrated Flash memory.
-
Page 2: Installation
INSTALLATION Connect the Smart PRO GPS2 Logger to the receiver telemetry port. Place the device on top of the plane, so the internal patch antenna is not shielded in any direction. Shielding materials, such as metal, carbon or anything conducting, can reduce the position detection performance. Additionally, make sure that the 2.4GHz antennas are located at least 20 cm or more from the GPS Logger. - Page 3 Timezone - Press Left+Right to switch between automatic timezone detection and manual configuration. If the “Auto” mode is used, the detected timezone is displayed when the sensor has a position fix. If the timezone is detected incorrectly, switch to “Manual” mode and type the zone using LEFT or RIGHT keys. For example, Central Europe uses GMT+1, while US Eastern Time uses GMT-5.
- Page 4 FUTABA AND MULTIPLEX CONNECTION Futaba and Multiplex systems do not offer wireless device configuration. The telemetry transmission is possible with the following fixed sensor slots: Futaba S.Bus2 Multiplex MSB Speed Altitude Time Vario Latitude 12–13 Longtitude 14–15 Distance Satellites Course Note Manual detection in the menu Linkage –...
- Page 5 ANALYZE LOG FILES The free MAV Manager software allows you to download and analyze the GPS data after the flight. You can download it from the manufacturer's website. 1. Connect the MAV USB interface to the computer. Attach the GPS Logger to it. 2.
- Page 6 4. Select the log file and press the “Download” button. You will be asked to select the destination filename. When the transfer finishes, you will be asked if you want to open the downloaded file. Press “Yes”. 5. You can view the logged data in a chart or map. Save the log file, or export the coordinates to KML.
-
Page 7: Safety Information
SAFETY INFORMATION Operate the GPS Logger always in a dry environment and within the device limits stated in this guide. Never expose the device to excessive heat or cold. Never apply mechanical stress or excessive force to the GPS Logger. The sensing element can measure imprecisely or be damaged if a force is applied. - Page 9 GUARANTEE The KAVAN Europe s.r.o. products are covered by a guarantee that fulfils the currently valid legal requirements in your country. If you wish to make a claim under guarantee, please contact the retailer from whom you first purchased the equipment. The guarantee does not cover faults which were caused in the following ways: crashes, improper use, incorrect connection, reversed polarity, maintenance work carried out late, incorrectly or not at all, or by unauthorised personnel, use of other than genuine KAVAN Europe s.r.o.
