Introduction
1.Passive noise reduction: PNR 23dB.
2.Super soft foam head pad and half gel half
foam ear cushion.
3.270°microphone boom rotation.
4.Volume control box with resistance adjust
ment and 3.5mm audio jack.
5.Stereo/mono mode switch.
Parts info
②
③
⑥
① Comfortable Foam Head Pad
② Over-the-head Adjustable Stainless
Steel Band
③ Comfortable half gel half foam ear pad
④ YOUR LOGO HERE(Special Order Only)
⑤ 270 Degree Rotatable
⑥ Noise-canceling Electret Mic Element
⑦ Flexible Boom
Specifications
①
1000+30
④
⑤
⑦
Speaker Specification
Impedance:
Sensitivity:
Resonance freq:
Frequency respond:
Rated input power:
Maximum input power:
Microphone Specification
Sensitivity Range:
Impedance Max:
Frequency :
Current Consumption Max:
Operation Voltage Range:
Max Sound pressure Level:
4.0mm Black PU Cable
Connector 6.3mm
290+15
Connector 5.2mm
150Ω
119±3dB At 1K Hz/IEC318， 547m
/ ±20%Hz
20-20KHZ
80mW
80mW
-35±2dB
2.2KΩ@1KHz
50-10KHz
500uA
1.0-10V
110dB
Advertisement
Summary of Contents for RayTalk PH-100A-GA
- Page 1 Introduction Specifications 1.Passive noise reduction: PNR 23dB. 2.Super soft foam head pad and half gel half foam ear cushion. 3.270°microphone boom rotation. 4.Volume control box with resistance adjust ment and 3.5mm audio jack. 5.Stereo/mono mode switch. Parts info ① 1000+30 ② 4.0mm Black PU Cable ③ ④ Connector 6.3mm ⑤ ⑥...
- Page 2 Operation Instructions Warranty service Any headphone purchased from RayTalk can have after-sales maintenance services provid- Adjustable Resistance ed by our company or authorized providers due to product quality problems. We provide a one-year warranty for the prod- uct, the warranty period starts from the day of receipt of the goods.
