- Page 1 Manual Compact router 6.5 mm 1/4” Collet Applies for: Codes Models 102865 ROUI-20A 103262 ROUI-20AS ROUI-20A Read this manual thoroughly CAUTION before using the tool.
-
Page 2: Table Of Contents
Safety warnings for the use of routers The illustrations in this manual are for reference only. They might be different from the real tool. Parts Preparation Operation Maintenance Environmental protection Troubleshooting Notes Authorized service centers Warranty policy ROUI-20A ROUI-20AS ENGLISH... -
Page 3: Technical Data
Avoid the risk of electric shock or severe injury. When the power cable gets damaged it should only be replaced by the manufacturer or at a TRUPER Authorized Service Center. The build quality of the electric insulation is altered if spills or liquid gets into the tool while in use. -
Page 4: General Safety Warnings For Electric Tools
General safety warnings for electric tools WARNING! Read all safety warnings, instructions, illustrations, and specifications provided with this power tool. Failure to follow any of them may result in electric shock, fire, and/or serious injury. Keep the warnings and instructions for future reference. The term "power tool"... - Page 5 Use and care of the battery-powered tool Only recharge with the charger specified by the manufacturer. Do not expose a battery or tool to fire or excessive temperatures. A charger that is suitable for one type of battery can pose a fire risk when used with a different one.
-
Page 6: Safety Warnings For
• Only recharge the battery with the charger specified by materials. When not in use, keep batteries away from any TRUPER. Do not use any charger not specifically provided metallic objects such as clips, coins, keys, nails, screws, or for the equipment. -
Page 7: Safety Warnings For The Use Of Routers
Safety warnings for the use of routers WARNING KICKBACK RISK. Kickback refers to the DANGER • Keep your hands away from the cutting sudden and forceful movement that the tool experiences area and the cutting bit. When operating the tool, hold it outward from the workpiece and can cause the operator firmly with the anti-slip handle to avoid accidental injuries to lose control or even result in an injury. -
Page 8: Parts
Parts Battery included only for model ROUI-20A Battery capacity indicator Variable speed control Battery release button Power on/off switch Motor housing Fine depth adjustment wheel Quick-release lever for cutting depth adjustment Parallel guide locking knob Locking lever (for cutting depth... -
Page 9: Preparation
Preparation NOTE: Before using the tool, carefully read the instruction manual. Intended use Battery status check This product is intended for making slots, edges, profiles, Before starting or after use, press the button next to the and elongated holes in wood, plastic, and lightweight lights to check the battery status. - Page 10 Preparation Insertion 7. Tighten the clamping nut clockwise using the supplied 1. First, open the cutting depth locking lever (C). wrench. 2. Press the quick-release lever and hold it in position (D). 8. Release the spindle lock button and ensure that the 3.
- Page 11 Preparation Adjustment of the parallel guide • Loosen the parallel guide locking nut counterclockwise (K). • Slide the parallel guide to the desired working position (I). • Secure the parallel guide in the working position by tightening the locking knob (K) clockwise. When cutting, always ensure that the parallel guide is flush with the side of the workpiece.
- Page 12 Preparation Template cuts • Place the appropriate template guide on the product. • Place the template over the workpiece and secure it with suitable clamps. Ensure that the clamps do not obstruct the movement of the product. • Place the product on the workpiece with the neck of the template guide against the edge of the template.
-
Page 13: Operation
Preparation 6. Dust cover installation The router comes with a dust cover for dust collection. To install it, simply place the two small, raised cylinders into the corresponding holes located on both sides of the outer aluminum casing. Operation Power on and off WARNING Before installing the battery, ensure that the tool is turned off. -
Page 14: Feed Direction
Operation General routing WARNING During operation, fine dust will be Place the base on the workpiece to be cut without making any contact with the router bit. Turn on the tool and wait generated! Use a dust mask. • Ensure that the workpiece is free from obstacles such as until it reaches full speed. -
Page 15: Maintenance
Cleaning and care Service • Keep the vents clean and free from obstructions to Tool servicing should only be performed at a TRUPER ensure proper motor cooling. Authorized Service Center. Service and maintenance • Regularly inspect all mounting screws and ensure they performed by unqualified persons can be dangerous and are tightened correctly. -
Page 16: Environmental Protection
Electrical appliances and batteries should not be disposed of with household waste. Please deliver this device, as well as its batteries with isolated contacts covered with adhesive tape, to a recycling center. Check the location of the nearest center in your community. Compatibility with vacuums ROUI-20A ROUI-20AS ASP-03 ASP-04... -
Page 17: Troubleshooting
Troubleshooting Problem Cause Solution • The router loses • Low battery. • Charge the battery. efficiency. • The workpiece • Dull cutting bit. • Use a sharp cutting bit. surface is not smooth • The cutting bit speed reduces to an •... -
Page 18: Notes
Notes ENGLISH... -
Page 19: Authorized Service Centers
Authorized service centers In the event of any problem contacting a TRUPER Authorized Service Center, please see our webpage WWW.TRUPER.COM to get an updated list, or call our toll-free numbers 800 690-6990 or 800 018-7873 to get information about the nearest Service Center. -
Page 20: Warranty Policy
It includes the costs of transportation of the product that derive from its fulfillment of its service network. . Phone number 800-018-7873. Made in China. Imported by TRUPER, S.A. de C.V. Parque Industrial 1, Parque Industrial Jilotepec, Jilotepec, Edo. de Méx. C.P. 54257, Phone number 761 782 9100.
