Enzo eBikes, Folding Electric Bike

Specification

Product:

APT Model:

Client Model:

Supplier：

September 2023

TFT LCD Display

850C

Enzo eBikes

1620 East Sample Road

Pompano Beach, FL 33064 USA

Tel: 844-324-5348

customersupport@enzoebike.com

1 / 21

Table of Contents

Need help?

Do you have a question about the 850C and is the answer not in the manual?

Questions and answers

Summary of Contents for Enzo eBike 850C

Page 1 Enzo eBikes, Folding Electric Bike Specification September 2023 Product: TFT LCD Display APT Model: 850C Client Model: Enzo eBikes Supplier： 1620 East Sample Road Pompano Beach, FL 33064 USA Tel: 844-324-5348 customersupport@enzoebike.com 1 / 21...
Page 2: Product Name
Enzo eBikes, Folding Electric Bike Product name Model : 850C Supplier APT (Tianjin) Development Co., Ltd. Electrical Parameters  3.2inch TFT screen  24V/36V/48V battery supply  Rated operating current : 40mA  Max operating current : 100mA (36V battery, with USB equipment changed) USB changing port : 5V 500mA ...
Page 3 Enzo eBikes, Folding Electric Bike  3.2-inch TFT screen. Independent button, easy to operate.   Speed display: AVG SPEED, MAX SPEED, SPEED(Real-time).  Kilometer/mile: Can be set according to customer habits.  Intelligent power indicator: Provides stable power prompts through optimized algorithms.
Page 4: Function Description
Enzo eBikes, Folding Electric Bike Clock Battery indicator Headlight Speed indication Speed display Power display Assist level Power indication Riding-Time/ Mileage mode Speed mode LOGO/ERROR Clock: display clock information，12h   Headlight: Displayed when the headlights are on  Speed indication : Graphical indication of speed value, Km/h or MPH ...
Page 5: Power On/Off
Enzo eBikes, Folding Electric Bike 7.1 Power On/Off Press and hold POWER button for 2 seconds, you can turn on/off the instrument. If there is no riding and no operation on the instrument for 5 minutes (the time can be set by the user, see 8.1.4 ‘Auto off’), the instrument will automatically turn off.
Page 6: Data Cleanup
Enzo eBikes, Folding Electric Bike *The display of Range requires controller and battery support. 7.4 Headlight / Display Mode/ Light Sensor Press and hold UP button for 2 seconds can turn on/off headlight, display will switch to the corresponding mode (Day or Night). The built-in light sensor can turn on/off headlight automatically when the external light changes (requires controller support).
Page 7: Display Setting
Enzo eBikes, Folding Electric Bike * Temporary data is automatically saved when power off. Abnormal power outage will cause data lost. * Restore Factory Mode (advanced settings in Menu Page) can clear temporary data (TRIP, Riding-Time, AVG SPD, MAX SPD, MENU settings) except ODO. * ODO will reset to zero over 99999km.
Page 8 Enzo eBikes, Folding Electric Bike MENU M E N U Display Setting D i s p l a y S e t t i n g Language Language System Metric S y s t e m I m p e r i a l Brightness | | || | B r i g h t n e s s | | | | |...
Page 9 Enzo eBikes, Folding Electric Bike MENU Display Setting Language System Metric Brightness | | || | Auto off 5min Scenes Analog Battery Ind Voltage Pow Ind Power Clock > Start Password > Basic Setting . . . EXIT 8.1.6 Battery Ind Support Voltage / Percent / OFF display.
Page 10 Enzo eBikes, Folding Electric Bike 8.1.8 Clock You can select the adjustment items year /month/day/hour/minute/second. MENU D i s p l a y S e t t i n g C l o c k Display Setting Language System Metric Y e a r 2023 Brightness...
Page 11: Basic Setting
Enzo eBikes, Folding Electric Bike MENU Start Input Start Input Password Password Display Setting Language BACK BACK System Metric Start input Start input Brightness | | || | Setting Password Setting Password Auto off 5min Scenes Analog 0 0 0 0 0 0 0 0 Battery Ind Voltage...
Page 12 Enzo eBikes, Folding Electric Bike MENU M E N U Display Setting D i s p l a y S e t t i n g Language Language System Imperial S y s t e m I m p e r i a l .
Page 13 Enzo eBikes, Folding Electric Bike MENU L i g h t S e n s o r L i g h t S e n s o r Display Setting Language System Imperial B A C K B A C K .
Page 14 Enzo eBikes, Folding Electric Bike Advance Setting Speed limit 25km/h Current limit Poles in motor Start after poles Clockwise Start Throttle 6km Throttle Level Start mode Assist levels Assist setting > BACK EXIT The speed limit is restricted by the motor and controller and may not reach the set value. 8.2.5.2 Current Limit Adjustment range 06~50A .
Page 15 Enzo eBikes, Folding Electric Bike Advance Setting Speed limit 25km/h Current limit Poles in motor Start after poles Clockwise Start Throttle 6km Throttle Level Start mode Assist levels Assist setting > BACK EXIT 8.2.5.5 Clockwise Start This parameter represent speed sensor turn direction, support front (Y) or reverse (N). Advance Setting Speed limit 25km/h Current limit...
Page 16 Enzo eBikes, Folding Electric Bike Advance Setting Speed limit 25km/h Current limit Poles in motor Start after poles Clockwise Start Throttle 6km Throttle Level Start mode Assist levels Assist setting > BACK EXIT 8.2.5.8 Start mode Supports three modes: STD/Eco/Pow Pow means the fastest start Eco means energy saving start STD means standard start...
Page 17 Enzo eBikes, Folding Electric Bike Assist Setting A s s i s t S e t t i n g Gear - 1 G e a r - 1 Gear - 2 Gear - 2 Gear - 3 Gear - 3 Gear - 4 Gear - 4 Gear - 5...
Page 18 Enzo eBikes, Folding Electric Bike Information P r o d u c t I n f o r m a t i o n Speed Version 0.0 Km/h H a r d w a r e v e r E2.3 0.0 Km/h S o f t w a r e v e r .
Page 19: Error Code Definition
Enzo eBikes, Folding Electric Bike L a s t T e s t I n f o Self-Testing S t e p 6 - 1 C o n t r o l l e r BACK S t e p 6 - 2 START P A S s e n s o r S t e p 6 - 3...
Page 20: Copyright Notice
Enzo eBikes, Folding Electric Bike Clamps suit for three sizes of handlebar, 31.8mm, 25.4mm, 22.2mm, and you can be selected according to actual demand. 25.4mm and 22.2mm handlebars need to be used with the corresponding rubber rings. The assembly of the rubber ring is directional. Pay attention to the opening direction when installing.
Page 21 Enzo eBikes, Folding Electric Bike Questions about your e-bike, please contact with dealer firstly. Enzo eBikes reserves the right to modify this specification file， without declaration in advance. Content and Image owner：Enzo eBikes 1620 East Sample Road Pompano Beach, FL 33064 USA https://enzoebike.com/ website：...
