Summary of Contents for Technoalarm TECNOCELL 4

Page 1 Installation Release FW release 1.7.02 Model TECNOCELL 4 Programming SW release Update 04/2022 Language English...
Page 3 Conﬁ guration of user ﬁ le Operating modes 3-2-1 GSM intern mode 3-2-2 GSM extern mode Conﬁ guration of telephone parameters - GSM Conﬁ guration of telephone parameters - TECNOCELL Conﬁ guration of device speciﬁ c parameters Emergency message 4 - FIRMWARE-UPGRADE TECNOCELL 4...
Page 4 The product features can be subject to change without notice. Unauthorized reproduction or distribution of this manual, or any portion of it, on any device and in any form, is prohibited. The contents of this manual may be subject to change without notice. TECNOCELL 4...
Page 5 1 - TECHNICAL AND FUNCTIONAL SPECIFICATIONS General Model TECNOCELL 4 RS485 Connection features Tecno Server Product category Communicator Remote Server Communication channels Communication Telephone numbers ✓ IP addresses parameters External Voice - Data - SMS GSM mode Event notiﬁcation ✓...
Page 6 TECNOCELL 4...
Page 7: Warnings For Installation
2-2 - General warnings The TECNOCELL 4 telephone communicator must be installed in indoor areas. Monitoring of temperature and humidity is not required. For the safety of the operators protect the device, as any electronic device, against splashes and avoid placing recipients containing liquids next to it.
Page 8: Cpu Board
Insert for RS422 connection with ESP GSM LINK (GSM intern mode)* * Insert JP6 - RS485 jumper, too. END-OF-SERIAL BUS RS485 RS485 Insert on the last device of the serial bus* * Insert for RS422 connection with ESP GSM LINK (GSM intern mode), too. TECNOCELL 4...
Page 9 Signal power 5 Low battery * If the LED 4 to 8 are ﬂ ashing slowly simultaneously, they signal an active GSM jamming alarm. Signaling Error GSM module Green Flashing Normal operating conditions Flashing Data transmission Connection active TECNOCELL 4...
Page 10: Operating Mode
The settings for both operating modes are completed in the device-speciﬁ c menus of the device. Operating mode GSM intern - Connection via RS422 serial bus with ESP GSM LINK TECNOCELL 4 ESP GSM LINK 1 OFF 38.400bps...
Page 11: Sim Card Installation
SYSTEMS KEEP ONLINE KEEP ONLINE TP10-42 ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ TP8-88 ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ TP20-440 ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ TECNOCELL 4...
Page 12 TECNOCELL 4...
Page 13 3 - PROGRAMMING The telephone communicator TECNOCELL 4 must be added in the user ﬁ le of the associated control panel. 3-1 - Conﬁ guration of user ﬁ le New user 1 - Modify user ﬁ le Name Address Click on Modify to open the user ﬁ le.
Page 14 E - Click on the screwdriver icon Tecnoalarm - START_CODE Conﬁ guration Pnet - 0019 - SMITH F - Select TECNOCELL 4. Hardware conﬁ guration Modules available PROGNET Abort G - Click on Yes. Centro Add: TECNOCELL 4 H - Conﬁ rm with OK.
Page 15: Operating Modes
Password Abandon E - Click on the T4 icon and open the conﬁ guration tables of the device. TECNOCELL 3 TECNOCELL 4 F - Conﬁ gure the Options menu. Options G - Conﬁ gure the Messages menu. Messages H - Conﬁ gure the Vocabulary menu.
Page 16 Abandon E - Click on the T4 icon and open the conﬁ guration tables of the device. TECNOCELL 4 F - Conﬁ gure the TECNOCELL menu. TECNOCELL G - Conﬁ gure the GSM menu. H - Conﬁ gure the Options menu.
Page 17 Airtime request by SMS - Enable/disable the function. Airtime request SMS Provider no. for airtime request - Enter the telephone number provided by the provider. Airtime request SMS - Enter the text provided by the provider TECNOCELL 4...
Page 18: Mobile Network
N.B. The international preﬁ x is not considered. The GSM menu is completed. Abandon To conﬁ rm the settings click OK. To cancel the settings click Abandon. N.B. Proceed with the settings in the device speciﬁ c menus of the telephone communicator (chapter 3-5). TECNOCELL 4...
Page 19 30 seconds, the telephone communicator sends a failure message to up to 4 telephone numbers. These emergency phone numbers are programmed in the device speciﬁ c menu Options. Message - Do not program (refers only to previous models). TECNOCELL 4...
Page 20 6 - Data channel Data channel (do not use with BACKUP protocols) (do not use with BACKUP protocols) N.B. This function is not available for the TECNOCELL 4. TECNOCELL 7 - JDR (Jam detector) With the help of this function, the control panel is able to recognize...
Page 21: Syntax Rules
If the call back number programmed on the control panel corresponds to one of the 8 numbers on the telephone communicator, the device forwards the call back to the IP address of the corresponding software. TECNOCELL 4...
Page 22 Firmware release - Shows the ﬁ rmware release of the 4G interface. Service provider Vodafone Firmware release MDF.220006 Hardware release - Shows the hardware release of the 4G interface. Hardware release LE910C1-EU PSNT network type - Shows the type of telephone network. PSNT network type (L) LTE network (4G) TECNOCELL 4...
Page 23 30 seconds. N.B. A possible emergency message programmed on the control panel overrules the settings of this menu. 6 - Enable data channel Enable data channel ✔ Enable/disable the data channel of the on-board 4G interface. TECNOCELL 4...
Page 24 For the voice message select max. 6 words ROOM (A, B, C, D, E, F) from the vocabulary and click on the arrow key (G) to conﬁ rm and apply the setting. For the SMS write the text directly in the corresponding item. TECNOCELL 4...
Page 25 PC and click on the START key to upload the settings to the device. At the end of the process click on OK to save the setting in the archive of the Tecnoalarm software. TECNOCELL 4...
Page 26: Emergency Message
0112354894 3331245987 3181548791 AT&T AT&T AT&T Conﬁ rmation End of cycle Call cycle The telephone communicator repeats the call up to 4 times, unless it is conﬁ rmed. Number 4 attempt? 3333598753 AT&T Conﬁ rmation End of cycle TECNOCELL 4...
Page 27: Firmware Upgrade
3 ﬂ ashes/second Boot loader mode (ﬁ rmware being loaded) E - Remove the jumper JP3 BOOT. F - Connect the USB cable to the PC and verify that the red USB LED is lit (otherwise check the drivers). TECNOCELL 4...
Page 28 Verify that the LED 2 ﬂ ashes 3 times a second. - UTS 4.3 PROX PROG USB PROG PROG ENABLE ENABLE Send ﬁ rmware Autoscan COM1-16 START STOP START STOP VOLTAGE VOLTAGE RS485 RS485 PROG32 PROG32 RS232 RS232 TECNOCELL 4...
Page 29 O - Verify that the LED 2 ﬂ ashes once a second. P - Disconnect the USB cable. Q - Insert the jumper JP7 RESET for some seconds, then remove it. POWER SUPPLY 12V DC LED 2 LED USB JP7 RESET The ﬁ rmware upgrade is completed. TECNOCELL 4...
