- Page 1 Zenty | Professional A/V Solution Provider User Manual [V1.0] 8-Button Wall Plate Control Panel ZT-136 | ZT-CP8 ® ZENTY 9807 EMILY LANE STAFFORD, TX 77477 (844) 200-1945 SALES@ZENTY.COM (888) 610-2818 | www.zenty.com Page 1 of 32 Copyright © 2022 Zenty AV...
-
Page 2: Table Of Contents
7.1 USB Driver Installation10 7.2 Software Programming10 7.3 Main Menu11 7.4 Panel/Key Setting14 7.5 Action List17 7.6 Event Setting17 ➢ RS232 Setting17 ➢ IR Setting19 ➢ I/O Setting..............20 ➢ Relay Setting............20 (844) 200-1945 | sales@zenty.com Page 2 of 32 Copyright © Zenty AV... - Page 3 ➢ Loop Setting............24 ➢ Toggle Setting............25 7.7 Event List................26 8. Specifications………...…………........27 9. Panel Drawing..............28 10. Troubleshooting & Maintenance........29 11. Warranty..............29 12. Mail-In Service..............29 13. Limited Warranty Limits and Exclusions......29 (844) 200-1945 | sales@zenty.com Page 3 of 32 Copyright © Zenty AV...
-
Page 4: Introduction4
(1) x Power Adapter (DC 12V) (3) x 2-pin Captive Screw Connector (2) x IR Emitter (8) x Button Caps (1) x Button Label (1) x USB Converting Cable (1) x User Manual (844) 200-1945 | sales@zenty.com Page 4 of 32 Copyright © Zenty AV... -
Page 5: Installation5
Put the device into the hold and adjust it to flush with the table (shown in figure 1-2) • Plug a set screw in to the fixing mounting and screw the nuts tightly 5. Panel Description 5.1 Front Panel (844) 200-1945 | sales@zenty.com Page 5 of 32 Copyright © Zenty AV... -
Page 6: Side Panel6
Connect the PC via USB or RS232 • Every label inside the button can be changeable. You can choose the label you need and change it easily 5.2 Side Panel (844) 200-1945 | sales@zenty.com Page 6 of 32 Copyright © Zenty AV... -
Page 7: Rear Panel7
③ Low-Voltage relay ports: set the relay on/off by software JTD-Control ④ Power connector: 12VDC. Be sure that the “+” and “-” never be mixed or wrong connection. (844) 200-1945 | sales@zenty.com Page 7 of 32 Copyright © Zenty AV... -
Page 8: Connection Introduction8
The programmable control panel can active different ports at one time. It means every button can send the RS232 and RS485 commands, IR code and control the relay at the same time. The demo system diagram as below: (844) 200-1945 | sales@zenty.com Page 8 of 32 Copyright © Zenty AV... -
Page 9: Connection Of Programming And Looping
Several pieces programmable control panels can be also looped to be a system, for control more devices. It is looped by the inter RS232 setting. Please check the demo picture as below: (844) 200-1945 | sales@zenty.com Page 9 of 32 Copyright © Zenty AV... - Page 10 (844) 200-1945 | sales@zenty.com Page 10 of 32 Copyright © Zenty AV...
-
Page 11: System Operations
(button) setting, event setting, action list and event list. In this manual we will take programmable control panels-V for example, to show the uses of all functions. (844) 200-1945 | sales@zenty.com Page 11 of 32 Copyright © Zenty AV... -
Page 12: Main Menu11
2. System model: includes programmable control panels-H, programmable control panels-V, WP19R etc., and the buttons interface view are different with different models. The pictures below show the differences between programmable control panels-V and programmable control panels-H. (844) 200-1945 | sales@zenty.com Page 12 of 32 Copyright © Zenty AV... - Page 13 Note: When select the model, it will pop up “Output Port Selection” dialog, user can select different RS and IR types, depend on the uses of the two shared ports. The dialog is as the picture below: (844) 200-1945 | sales@zenty.com Page 13 of 32 Copyright © Zenty AV...
- Page 14 And there are four output types. They are showed as below form (“√” means port is available): 3. Connection type: the instructions are in the picture below: (844) 200-1945 | sales@zenty.com Page 14 of 32 Copyright © Zenty AV...
-
Page 15: Panel/Key Setting14
There are three different colors of keys in the panel set of JTD-Control. Add a key action to action list, then add events to this action, make this action will execute the events. Here take programmable control panels-V for example, to introduce the uses of different buttons (844) 200-1945 | sales@zenty.com Page 15 of 32 Copyright © Zenty AV... - Page 16 1. White keys: keys 1-8, correspond to the buttons on the programmable control panel. Click the key, it will pop up dialog as below: When select the type “Toggle”, the setting interface is as below: (844) 200-1945 | sales@zenty.com Page 16 of 32 Copyright © Zenty AV...
- Page 17 Example: Set time1 to 5 minutes, and time2 to 3 minutes, add event1 to time1 and event2 to time2. When the unit starts, it will execute event1 after 5 minutes, and then execute event2 after 8 minutes. (844) 200-1945 | sales@zenty.com Page 17 of 32 Copyright © Zenty AV...
-
Page 18: Action List17
The following introduction will show you the setting of each event: ➢ RS232 Setting This item is used for setting the parameters of the programmable control panel’s serial ports. Click “RS232”, it will show as below: (844) 200-1945 | sales@zenty.com Page 18 of 32 Copyright © Zenty AV... - Page 19 See in picture below: 3. The send port must be selected as the same as model setting, otherwise the event cannot be added. (844) 200-1945 | sales@zenty.com Page 19 of 32 Copyright © Zenty AV...
-
Page 20: Ir Setting19
1. The data of IR need to be selected from library. Click “Change Lib” to select a library file and open it. Click “Edit Lib” to create or edit a library file as below: Note: When editing finish, remember to save the editing, and then press “OK”. (844) 200-1945 | sales@zenty.com Page 20 of 32 Copyright © Zenty AV... -
Page 21: I/O Setting
There is no I/O port in the programmable control panel, so the setting is not introduced in this manual. ➢ Relay Setting This item is for the replay ports setting. The setting is as the picture below: (844) 200-1945 | sales@zenty.com Page 21 of 32 Copyright © Zenty AV... -
Page 22: Delay Setting
This item is to set a delay time, user can add a delay between two events; so when one event is finished, it will delay a certain time then start another event. The delay setting is as picture below: (844) 200-1945 | sales@zenty.com Page 22 of 32 Copyright © Zenty AV... -
Page 23: Compare Setting
If the compare is incorrect, the event behind compare will not be executed. ➢ LED Setting This item is used for set the button LEDs in the programmable control panel to turn on/off. The setting is as below: (844) 200-1945 | sales@zenty.com Page 23 of 32 Copyright © Zenty AV... -
Page 24: Page Setting
1. Take button1 for example: click key1 and select the action type “page”, add the four actions to the action list. Then add other four buttons “press” action to the list (here take keys 5-8 for example): (844) 200-1945 | sales@zenty.com Page 24 of 32 Copyright © Zenty AV... -
Page 25: Loop Setting
➢ Loop Setting This item is used for looping the programmable control panel. When use the loop function, the ID of each programmable control panel must be set. (844) 200-1945 | sales@zenty.com Page 25 of 32 Copyright © Zenty AV... -
Page 26: Toggle Setting
➢ Toggle Setting The toggle setting is as the picture below: (844) 200-1945 | sales@zenty.com Page 26 of 32 Copyright © Zenty AV... -
Page 27: Event List
The executing priority is from 1 to 10, see the picture below. If there is an event execute incorrectly, all the events behind it will not be executed (844) 200-1945 | sales@zenty.com Page 27 of 32 Copyright © Zenty AV... -
Page 28: Specifications
Output: 12V DC 2A Max Power Consumption Dimensions (W x H x D) 114mm x 70mm x 28mm 4.5” x 2.8” x 1.1” Net Weight 150g | 0.33lbs (844) 200-1945 | sales@zenty.com Page 28 of 32 Copyright © Zenty AV... -
Page 29: Panel Drawing
9. Panel Drawing (844) 200-1945 | sales@zenty.com Page 29 of 32 Copyright © Zenty AV... -
