- Page 2 . . k...
- Page 4 Flip the extension leaf and remove the support rails as shown. Keep the support rails for the next step, but you won’t need these bolts or washers anymore. Reattach the support rails to the table top as shown, using the bolts and washers from Step 2. Pavilion Extending Dining Table - V03...
- Page 5 Assembly Instructions Customer Service Pavilion Extending Dining Table help.furniturechoice.co.uk Attach the pedestal legs and centre rail to the brackets as shown. Attach the feet to the brackets as shown. Pavilion Extending Dining Table - V03...
- Page 6 Assembly Instructions Customer Service Pavilion Extending Dining Table help.furniturechoice.co.uk Remove the mounting plates and keep the bolts and washers for Step 9. Attach the mounting plates to the pedestal legs as shown. Pavilion Extending Dining Table - V03...
- Page 7 Attach the mounting plates to the extension rails as shown, using the bolts and washers from Step 7 and 4 bolts and washers from the hardware pack, then tighten with the Allen key. Pavilion Extending Dining Table - V02 Pavilion Extending Dining Table - V03...
- Page 8 To store the centre leaf, unlock the clasps beneath the table top and pull both sides apart. Gently store the centre leaf within the opening. Close the table and lock the clasps. Unlock the clasps Lock the clasps Pavilion Extending Dining Table - V03...
- Page 9 Assembly Instructions Customer Service Pavilion Extending Dining Table help.furniturechoice.co.uk To extend the table, unlock the clasps beneath the table top and pull both sides apart. Unlock the clasps Pavilion Extending Dining Table - V03...
- Page 10 Assembly Instructions Customer Service Pavilion Extending Dining Table help.furniturechoice.co.uk Gently place the centre leaf in position and lock the clasps to secure. Lock the clasps Pavilion Extending Dining Table - V03...
- Page 11 Assembly Instructions Customer Service Pavilion Extending Dining Table help.furniturechoice.co.uk If your floor is uneven, use the adjustable levellers to stabilise the table. Pavilion Extending Dining Table - V03...
