Summary of Contents for FEIG ID CPR.Ethernet Connect-RJ45
- Page 1 IDENTIFICATION INSTALLATION MANUAL ID CPR.Ethernet Connect-RJ45 Ethernet Connection Board for ID CPR50.10-xE and ID MAX50.10-xE M20811-2e-ID-B...
- Page 2 INSTALLATION MANUAL ID CPR46.10-4SUSB FEIG ELECTRONIC GmbH Seite 2 von 8 M20811-2e-ID-B.doc...
- Page 4 All rights reserved in the event of the grant of a patent, utility model or design. Composition of the information in this document has been done to the best of our knowledge. FEIG ELECTRONIC GmbH does not guarantee the correctness and completeness of the details given in this manual and may not be held liable for damages ensuing from incorrect or incomplete information.
- Page 5 INSTALLATION MANUAL ID CPR.Ethernet Connect-RJ45 1. 1. Safety Instructions / Warning - Read before start-up ! • The device may only be used for the intended purpose designed by for the manufacturer. • The operation manual should be conveniently kept available at all times for each user.
- Page 6 INSTALLATION MANUAL ID CPR.Ethernet Connect-RJ45 2. 2. Characterization The connection board ID CPR.EthernetConnect-RJ45 offers a RJ45 connector for standard Ether- net cables to connect ID CPR50.10-eE or ID MAX50.10-xE to the Ethernet. ID CPR.EthernetConnect-RJ45 can be used as an alternative to the LSA connection board which is included in deliveries content.
- Page 7 INSTALLATION MANUAL ID CPR.Ethernet Connect-RJ45 The terminals of X3 can be used to connect an external power-supply (if the device is not powered via Pover over Ethernet and depending on the hardware version to connect the internal relay or the external ID CPR.I/O module.
- Page 8 3. Radio Approvals Declaration of Conformity (CE) Hereby FEIG ELECTRONIC GmbH declares that the radio equipment type ID CPR50.10-E is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.feig.de/en/service/eu-declarations-of-conformity/...
