Instruction manual Motor Protection Switch K3100
with emergency stop and or rotating field detection
Dear customer,
Thank you for purchasing this product.
The article has been finally tested and meets the requirements of the
applicable European and national directives. We hereby confirm CE
conformity, the corresponding declarations are on file with us as the
manufacturer.
In order to maintain the delivery condition of the product and to ensure
safe operation, you as the user must observe these operating instructions.
Therefore, please read the operating instructions in full before using the product and
observe all operating and safety instructions!
These operating instructions belong to the product mentioned. It contains important information on
commissioning and handling. Pay attention to this, even if you pass this product on to third parties.
Therefore, please keep these operating instructions for future reference
The version without a motor protection switch may only be connected to the mains after a
motor protection switch has been fitted.
There is a danger to life if live parts of the appliance are touched.
During installation, retrofitting and maintenance work, ensure that all electrical conductors,
terminals and connecting parts are de-energized.
Connection
The appliance may only be connected by qualified personnel and only with the mains plug
disconnected. To do this, open the cover, install a suitable motor protection switch and connect the
connecting cable. Then refit the cover. The motor protection switch is now ready for operation.
Fasten the housing with M5 threaded screws.
Rotating field detection (optional)
If installed correctly, the mains connections should be designed with a clockwise rotating field. The
signal lamp of the phase sequence indicator lights up when the left-hand phase sequence is on the
mains side. You can correct the phase sequence accordingly using the phase inverter in the CEE
collar plug.
Emergency stop (optional)
This version is designed with an undervoltage release. Ensure the correct connection voltage for the
undervoltage coil. Test the triggering of the emergency stop function before use.
When the emergency stop mushroom button is pressed, it engages when switched off. It is then not
possible to switch it on again. To do this, the mushroom button must be reset by turning it.
