- Page 1 IN240800474V01_UK 800-241V70 Compressor Wine Cooler IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY INSTRUCTION MANUAL...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS To reduce the risk of fire, electrical shock or WARNING injury, follow these basic precautions when using this appliance: WARNING: 1) This appliance should only be used by persons who are physically and mentally capable, experienced or supervised by someone responsible for their safety. 2) Supervise children to ensure they do not play with the appliance. -
Page 3: Installation Instructions
When using, servicing or disposing of the appliance, pay attention to the fire risk warning symbol, found on the rear panel or compressor in yellow or orange. This indicates flammable materials in the refrigerant pipes and compressor. Keep away from fire sources during these times. INSTALLATION INSTRUCTIONS ●... -
Page 4: Operating Your Unit
OPERATING YOUR UNIT Setting the temperature control Button function ① Unlock key: Press to switch between upper and lower room setting state. Hold for two seconds to unlock. ② Light/CF key: Press to toggle the light on and off. Hold for two seconds to switch between Fahrenheit and Celsius. - Page 5 Tips ● This appliance is designed exclusively for storing wine. ● It is not suitable for freezing food. ● The recommended temperature setting for the wine cooler is 12°C. ● Factory-placed shelves offer the most efficient energy use. ● Use the recommended shelf combination for optimal energy efficiency. THERE ARE SIX SHELVES AND ONE DISPLAY SHELF IN TOTAL The first shelf The second shelf...
- Page 6 GENERAL FAULT DESCRIPTION If the product is not working properly, follow these steps: 1. Check and handle the issue using the methods provided. 2. If the issue persists, contact your local after-sales service centre. 3. Provide detailed information about the model name and product number. The refrigerator doesn’t work Is the power on? Is the power supply voltage too low?
-
Page 7: Wiring Diagram
WIRING DIAGRAM LED1 LED2 DISPLAY PLUG CONTROL BOARD OVERLOAD PROTECTOR NTC1 NTC2 Electromagnetic STARTER Valve COMPRESSOR Model No. JC-94D(800-241V70BK) Netcapacity (litres) Voltage (V) AC230V Frequency (Hz) 50Hz Ratedpower (W) Dimensions(mm) 430x450x950 Netweight (kg) Correct disposal of this product This symbol indicates that the product should not be treated as household waste.
