Ultrasonic level sensor
alone is responsible for their definition.
Specifications
Measuring range: 0.25m to 6m
Connection: 1" BSPP or 1"1/2 BSPP
Power supply: 18 to 36 VDC
Electrical output: 4–20mA (2 wires) or
0–10V (3 wires)
Accuracy: 0.15% of the measurement range
Max. pressure: 1 bar
Ambient temperature:
Material: PP housing, PVDF transducer
IP67
Delivered with 5m of cable
On request:
- ATEX version
- measuring range up to 20m
- flange connectors
Range
73
MEASURING
INSTRUMENTS
- 30ºC to +60ºC
