Model 7356
– 11 chemin de la Pierre Blanche – 69800 SAINT-PRIEST – S.A.S with 240 000 € share capital – SIREN N° 311 810 287
Béné Inox
Tel. N°: +33 (0)4 78 90 48 22 – Fax N°: +33 (0)4 78 90 69 59 – www.bene-inox.com – bene@bene-inox.com
Technical information, illustrations and photographs are provided for information only, they are not contractual. Some may vary according to the tolerances accepted in the profession and the applicable standards. All
instructions for use, disassembly and maintenance are recommendations only. These could also vary depending on product usage conditions, its installation environment and purchaser requirements – of which the purchaser
High frequency level detector switch
alone is responsible for their definition.
Specifications
Connection:
1/2" BSPP according to ISO 228-1
Power supply:
7 to 34 VDC
Max. pressure:
1 bar
Ambient temperature:
Process temperature:
Material:
1.4404 stainless steel housing, 1.4301
stainless steel thread, nickel-plated brass/PA
M12x1 connector, PEEK electrode coating
NBR or EPDM gasket supplied
IP67
Delivered with an M12 connector and 2m of cable
On request:
-
ATEX version
-
Clamp connector
-
FKM gasket
Range
73
MEASURING
INSTRUMENTS
- 40ºC to +80ºC
- 40ºC to +100ºC
7356-A V0820
