OWNER'S MANUAL
LED LCD Monitor
(LED Monitor*)
*LG LED Monitors are LCD Monitors with LED Backlighting.
Please read this manual carefully before operating
your set and retain it for future reference.
LED LCD MONITOR MODEL
19M38A
20M38A
19M38D
20M38D
19M38H
20M38H
19M38L
22M38A
24M38A
22M38D
24M38D
22M38H
24M38H
27MP38VQ
27MP38HQ
www.lg.com
Advertisement
Table of Contents
Related Manuals for LG 19M38L
Summary of Contents for LG 19M38L
- Page 1 OWNER'S MANUAL LED LCD Monitor (LED Monitor*) *LG LED Monitors are LCD Monitors with LED Backlighting. Please read this manual carefully before operating your set and retain it for future reference. LED LCD MONITOR MODEL 19M38A 20M38A 22M38A 24M38A 27MP38VQ...
-
Page 2: Table Of Contents
CONTENTS CONTENTS LICENSE TROUBLESHOOTING ASSEMBLING AND PREPAR- SPECIFICATIONS Preset Modes (Resolution) Parts and buttons Indicator Moving and Lifting the Monitor Setting up the Monitor set PROPER POSTURE - Attaching the Stand Base Proper posture for using the Monitor set. - Detaching the Stand Base - Mounting on a table - Using the cable holder - Mounting on a wall... -
Page 3: License
24M38H 27MP38VQ 27MP38HQ LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. -
Page 4: Assembling And Preparing
It is recommended that use the supplied components. If you use generic cables not certified by LG, the screen may not display or there may be image noises. Illustrations in this document represent typical procedures, so they may look different from the actual product. -
Page 5: Parts And Buttons
ASSEMBLING AND PREPARING Parts and buttons Power Indicator Lighting On: Turned on Lighting Off: Turned off (Power Button) Button (See p.15) Connection panel (See p.12~14) -
Page 6: Moving And Lifting The Monitor
ASSEMBLING AND PREPARING Moving and Lifting the Monitor When holding the monitor, the screen should face away from you to prevent it being When moving or lifting the monitor, follow these scratched. instructions to prevent the monitor from being scratched or damaged and to ensure safe trans- portation regardless of its shape or size. -
Page 7: Setting Up The Monitor Set
19M38D 20M38D 22M38D 24M38D Stand Body 19M38H 20M38H 22M38H 24M38H 19M38L Attach the Stand Body to the monitor set. Attach the Stand Base. Tighten the screw to the right with a coin. Stand Body Stand Body Stand Base Stand Base... -
Page 8: Detaching The Stand Base
20M38D 22M38D 24M38D 19M38H 20M38H 22M38H 24M38H 19M38L Pull out the Stand Body and Stand Base from the monitor set. Turn the screw to the left with a coin. Stand Body Pull out the Stand Base. Stand Base Stand Body... -
Page 9: Mounting On A Table
ASSEMBLING AND PREPARING Mounting on a table Press (Power) button on the bottom switch panel to turn the power on. Lift and tilt the Monitor set into its upright position on a table. Leave a 100 mm(3.94 inches) (minimum) space from the wall for proper ventilation. CAUTION Unplug the power cord before moving the Monitor to another location. - Page 10 ASSEMBLING AND PREPARING Using the Kensington security system WARNING The Kensington security system connector is When you adjust the angle, do not hold the located at the back of the Monitor set. For more bottom of the Monitor set frame as shown on information of installation and using, refer to the the following illustration, as may injure your manual supplied with the Kensington security...
-
Page 11: Mounting On A Wall
If you use improper screw, the product might be Wall mount Pad damaged and drop from mounted position. Back Cover In this case, LG Electronics is not responsible Standard screw for it. Model 19M38A 20M38A... -
Page 12: Using The Monitor Set
USING THE MONITOR SET USING THE MONITOR SET Connecting to a PC DVI-D connection Transmits a digital video signal from your PC to Your Monitor set supports Plug & Play*. the Monitor set. Connect the PC and the Monitor *Plug & Play: A PC recognizes a connected set with a DVI cable as shown in the following device that users connect to a PC and turn on, without device configuration or user... -
Page 13: Hdmi Connection
Monitor set with the HDMI cable as shown in Transmits the digital video and audio signals from the following illustrations. your AV devices to the monitor. Connect your AV device to the monitor with the HDMI cable as il- 19M38L lustrated below. 22M38H 27MP38VQ 27MP38HQ... -
Page 14: Connecting To External Devices
When monitor power is turned on, the "Self Image Setting" Function is executed Connect peripheral devices to the monitor using automatically. (Only supported in Analog Mode) headphone ports. 19M38L 22M38H 27MP38VQ 27MP38HQ NOTE "Self Image Setting" Function. This function provides the user with optimal display settings.When the user connects... -
Page 15: Customizing Settings
When adjusting your display settings, always press the AUTO button on the MONITOR SETUP OSD. (Only supported in Analog Mode) The best display 19M38A/19M38D/19M38H/19M38L: 1366 x 768 mode 20M38A/20M38D/20M38H: 1600 x 900 22M38A/22M38D/22M38H/24M38A/24M38D/24M38H/27MP38HQ/ 27MP38VQ: 1920 x 1080 You can choose the input signal. -
Page 16: Customizing Settings
To adjust the brightness, contrast of the screen. Contrast ● ● ● 19M38L Response Time You can set a response time for displayed pictures based on the speed of the screen. For a normal environment, it is recommended 27MP38VQ 27MP38HQ ●... - Page 17 HDMI Description Picture Sharpness ● ● ● To adjust the clearness of the screen Black Level ● 19M38H 19M38L To set offset level 20M38H 22M38H 24M38H 27MP38VQ 27MP38HQ Overscan 19M38H 19M38L To improve the clarity and stability of the ●...
-
Page 18: Picture
Select EXIT to leave the OSD menu. To return to the upper menu or set other menu items, use the up arrow ( ) button. 19M38L Each option is explained below. Menu > Next Menu > Picture Description Sharpness To adjust the clearness of the screen. -
Page 19: Color
Enter to Color by pressing the ▼ button. Set the options by pressing the ◄ or ► or ▼ buttons. 19M38L Select EXIT to leave the OSD menu. To return to the upper menu or set other menu items, use the up arrow ( ) button. -
Page 20: Display
Phase To adjust the focus of the display. This item allows you to remove any horizontal noise and clear or sharpen the image of characters. Audio 19M38H 19M38L 20M38H 22M38H 24M38H 27MP38VQ 27MP38HQ Press MENU button on the bottom of the Monitor set to display the Menu OSD. -
Page 21: Others
Off.If you set Off, it will go off. If you set On at any time, the power indicator will automatically be turned on. Automatic Standby The monitor will automatically switch to standby mode after a certain period. 19M38H 19M38L 20M38H 22M38H 24M38H 27MP38VQ 27MP38HQ Resolution User can set the desired resolution. -
Page 22: Reader Setting
CUSTOMIZING SETTINGS READER Setting Press READER button on the bottom of the Monitor set to display the Reader Mode OSD. Set the options by pressing the ◄ or ► buttons. Select EXIT to leave the OSD menu. Each option is explained below. Reader Mode Description Reader 1... -
Page 23: Func. Setting
CUSTOMIZING SETTINGS FUNC. Setting 19M38L SMART ENERGY SAVING Press FUNC. button on the bottom of the Monitor set to display the FUNC. OSD. Enter to SMART ENERGY SAVING by pressing the ▼ button. Set the options by pressing the ◄ or ► buttons. -
Page 24: Picture Mode
Enter to Picture Mode by pressing the ▼ button. Set the options by pressing the ◄ or ► buttons. Select EXIT to leave the OSD menu.To return to the upper menu or set other menu items, use the up 19M38L arrow( )button. Each option is explained below. -
Page 25: Color Weakness
CUSTOMIZING SETTINGS Color Weakness Press FUNC. button on the bottom of the Monitor set to display the FUNC. OSD. Select Color Weakness by pressing the ► button. Enter to Color Weakness by pressing the ▼ button. Set the options by pressing the ◄ or ► buttons. Select EXIT to leave the OSD menu.To return to the upper menu or set other menu items, use the up arrow (... -
Page 26: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING Check the following before calling for service. No image appears y Check and see if the power cord is connected properly to the power Is the power cord of the display connected? outlet. y Press the Power button. Is the power indicator light on? Is the power indicator flickering? y If the display is in power saving mode, try moving the mouse or... - Page 27 Do you see an "Unrecognized monitor, Plug&Play (VESA DDC) monitor found" message? Have you installed the display y Be sure to install the display driver from our web site: http://www. driver? lg.com. y Make sure to check if the video card supports Plug&Play function.
-
Page 28: Specifications
SPECIFICATIONS SPECIFICATIONS 19M38A 19M38D 19M38H 19M38L Display Screen Type TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel Anti-Glare coating Pixel Pitch 0.3 mm x 0.3 mm (Pixel Pitch) Resolution 1366 x 768 @ 60 Hz Recommend VESA 1366 x 768 @ 60 Hz Power consump- On Mode : 18 W Typ.(Outgoing condition)*... - Page 29 SPECIFICATIONS 19M38H/ 19M38A 19M38D 19M38L Video Signal Horizontal 30 kHz to 83 kHz Frequency (Automatic) 30 kHz to 61 kHz ● ● ● (Automatic) Vertical 56 Hz to 75 Hz (D-SUB) ● ● ● Frequency 56 Hz to 75 Hz (DVI-D) ●...
- Page 30 SPECIFICATIONS SPECIFICATIONS 20M38A 20M38D 20M38H Display Screen Type TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel Anti-Glare coating Pixel Pitch 0.271 mm x 0.262 mm (Pixel Pitch) Resolution 1600 x 900 @ 60 Hz Recommend VESA 1600 x 900 @ 60 Hz Power consump- On Mode : 18 W Typ.(Outgoing condition)* Sleep Mode (Standby Mode) ≤...
- Page 31 SPECIFICATIONS 20M38A 20M38D 20M38H Video Horizontal 30 kHz to 83 kHz (Automatic) ● ● ● Signal Frequency 30 kHz to 61 kHz (Automatic) Vertical Frequency 56 Hz to 75 Hz (D-SUB) ● ● ● 56 Hz to 75 Hz (DVI-D) ●...
- Page 32 SPECIFICATIONS SPECIFICATIONS 22M38A 22M38D 22M38H Display Screen Type TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel Anti-Glare coating Pixel Pitch 0.248 mm x 0.248 mm (Pixel Pitch) Resolution 1920 x 1080 @ 60 Hz Recommend VESA 1920 x 1080 @ 60 Hz Power consump- On Mode : 18.8 W Typ.(Outgoing condition)* Sleep Mode (Standby Mode) ≤...
- Page 33 SPECIFICATIONS 22M38A 22M38H 22M38D Video Horizontal 30 kHz to 83 kHz (Automatic) ● ● ● Signal Frequency 30 kHz to 61 kHz (Automatic) Vertical Frequency 56 Hz to 75 Hz (D-SUB) ● ● ● 56 Hz to 75 Hz (DVI-D) ●...
- Page 34 SPECIFICATIONS SPECIFICATIONS 24M38A 24M38D 24M38H Display Screen Type TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel Anti-Glare coating Pixel Pitch 0.272 mm x 0.272 mm (Pixel Pitch) Resolution 1920 x 1080 @ 60 Hz Recommend VESA 1920 x 1080 @ 60 Hz Power consump- On Mode : 27.5 W Typ.(Outgoing condition)* Sleep Mode (Standby Mode) ≤...
- Page 35 SPECIFICATIONS 24M38A 24M38D 24M38H Video Horizontal 30 kHz to 83 kHz (Automatic) ● ● ● Signal Frequency 30 kHz to 61 kHz (Automatic) Vertical Frequency 56 Hz to 75 Hz (D-SUB) ● ● ● 56 Hz to 75 Hz (DVI-D) ●...
- Page 36 SPECIFICATIONS SPECIFICATIONS 27MP38HQ 27MP38VQ Display Screen Type TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel Anti-Glare coating Pixel Pitch 0.311 mm x 0.311 mm (Pixel Pitch) Resolution 1920 x 1080 @ 60 Hz Recommend VESA 1920 x 1080 @ 60 Hz Power consump- On Mode : 31.13 W Typ.(Outgoing condition)* Sleep Mode (Standby Mode) ≤...
- Page 37 SPECIFICATIONS 27MP38HQ 27MP38VQ Video Signal Horizontal 30 kHz to 83 kHz (Automatic) ● ● Frequency 30 kHz to 61 kHz (Automatic) Vertical 56 Hz to 75 Hz (D-SUB) ● ● Frequency 56 Hz to 75 Hz (DVI-D) ● 56 Hz to 75 Hz (HDMI) ●...
-
Page 38: Preset Modes (Resolution)
SPECIFICATIONS Preset Modes (Resolution) D-SUB/DVI-D Timing 19M38A 19M38D 19M38H 19M38L Horizontal Vertical Display Modes (Resolution) Polarity(H/V) Frequency(kHz) Frequency(Hz) 720 x 400 31.468 640 x 480 31.469 640 x 480 37.500 800 x 600 37.879 800 x 600 46.875 832 x 624 49.725... -
Page 39: Hdmi Timing
SPECIFICATIONS HDMI Timing 19M38H 19M38L 20M38H Factory support mode Horizontal Vertical HDMI (Preset Mode) Frequency(kHz) Frequency(Hz) 480P 31.50 576P 31.25 720P 37.50 720P 45.00 22M38H 24M38H 27MP38VQ 27MP38HQ Factory support mode Horizontal Vertical HDMI (Preset Mode) Frequency(kHz) Frequency(Hz) 480P 31.50 576P 31.25... -
Page 40: Proper Posture
PROPER POSTURE PROPER POSTURE Proper posture for using the Monitor set. Adjust the Adjust the location of the Monitor set and Monitor set to avoid it your posture to reflecting light. allow you to view images at the optimal viewing angle. - Page 41 Supplier’s Declaration of Conformity Trade Name Responsible Party LG Electronics USA, Inc. Address 1000 Sylvan Ave Englewood Cliffs, NJ 07632 Telephone (201)266-2215 Make sure to read the Safety Precautions before using the product. The model and serial number of the product are located on the back and on one side of the product.
