Page 1 Standard manual version 1 – February,2025...
Page 2 Notice d’utilisation – Terrain multisport This file contains all our recommendations to guide you in the use of your new MICHELIN Inflatable Solutions product. We recommend that you read it carefully before using your product for the first time, and refer to it if you have any doubts.
Page 3: Table Of Contents
Notice d’utilisation – Terrain multisport CONTENTS PRECAUTIONS FOR USE CHECKING THE CONTENTS OF THE DELIVERY LEGEND III. CHARACTERISTICS INSTALLATION DISMANTLING PROBLEM SOLVING VII. MAINTENANCE VIII. WARRANTY CONDITIONS Ref/document : Instruction manual MIS Classification: D3 Conservation : WA...
Page 4: Precautions For Use
Notice d’utilisation – Terrain multisport PRECAUTIONS FOR USE Uses involving risks Do not use machinery or cutting equipment near ✓ the structure, as this could damage it. Do not use abrasive ballast (breeze block, stone, ✓ metal), as this may cause premature damage to the perimeter of the shelter.
Page 5 Your product is inflatable, so there is a risk that a bladder in your structure could ✓ leak. In this case, evacuate the people present under the structure, dismantle the structure and contact the after-sales service: commerce@inflatable.michelin.com. A systematic check is recommended when assembling your structure. If you notice ✓...
Page 6: Checking The Contents Of The Delivery
Notice d’utilisation – Terrain multisport II. CHECKING THE CONTENTS OF THE DELIVERY Items included in a KIT : 2x carry bags (A) ▪ 1x inflatable structure (2 goals + 4 corners + 2 15m modules) (B) ▪ 8x connecting flap (C) ▪...
Page 7: Legend
Notice d’utilisation – Terrain multisport III. LEGEND Lower ring for deflation Upper ring (cap with non-return valve) for inflation ‘Clamp open: lets air through (position when inflating/deflating) ‘Clamp closed: does not let air through (position when structure is inflated) Guy ring / ballast ring Pump (with ‘...
Page 8: Characteristics
Notice d’utilisation – Terrain multisport IV. CHARACTERISTICS MULTISPORT FIELD 19 x 14 m Interior dimensions 24 x 15 m Exterior dimensions 4,6 m Maximum height 104 kg (2 sacs de 52kg) Weight Ref/document : Instruction manual MIS Classification: D3 Conservation : WA...
Page 9: Installation
Notice d’utilisation – Terrain multisport V. INSTALLATION Installation takes 1 hour. A minimum of 2 people are required for installation. 220V/50Hz power supply(s) to connect the pump(s). The main installation stages THE GOALS THE ANGLES THE 15M MODULES INSTALL THE CONNECTING FLAPS BALLAST AND BRACE THE STRUCTURE Ref/document : Instruction manual MIS Classification: D3...
Page 10 Notice d’utilisation – Terrain multisport V. INSTALLATION THE GOALS 1. Take the structure out of the bag 2. Spread the structure on the ground ✓ To position the structure on the ground in the right direction, each structure has a ‘UP’ which must be placed on top. UPs are only visible if there is no cover, so if your product has a cover, the cover must be placed on top when it is installed on the ground.
Page 11 Notice d’utilisation – Terrain multisport V. INSTALLATION 4. Close all the caps ✓ Close all the plugs on the structure. 5. Inflating the goal ✓ Unscrew the upper ring from a plug on the structure and connect the pump to it. ✓...
Page 12 Notice d’utilisation – Terrain multisport V. INSTALLATION THE ANGLES Take the inflatable out of its bag Unfold and lay the inflatable on the ground Close all the caps Close all the plugs on the structure. ✓ Inflate the corners Unscrew the top ring of a plug on a corner and connect the pump to it. ✓...
Page 13 Notice d’utilisation – Terrain multisport V. INSTALLATION Install the connecting flaps (between corners and goals) Place the corners facing the goals so that they can be connected. ✓ Position the connecting flaps on the velcro fasteners on the structures, then wrap ✓...
Page 14 Notice d’utilisation – Terrain multisport V. INSTALLATION 15m MODULES Remove the module from its transport bag Unfold and lay the inflatable on the ground Close all the caps Close all the caps on the structure. ✓ Inflate the modules Unscrew the top ring of one of the caps on the module and connect the pump to it. ✓...
Page 15 Notice d’utilisation – Terrain multisport V. INSTALLATION Install the connecting flaps (between corners and goals) Place the 15m modules facing the corners. ✓ Install the connecting flap using the Velcro fasteners provided. ✓ 6. Ballast and brace the structure The structure must be ballasted in accordance with the recommended weights and distributions.
Page 16: Dismantling
Notice d’utilisation – Terrain multisport VI. DISMANTLING 1. Remove accessories and fixings ✓ Remove the connecting flaps between the various elements. 2. Deflate the structure CAUTION: Do not use the pump to deflate the structure, as this could damage ✓ Open all the lower rings of the caps and allow each structure to deflate on its own. 3.
Page 17: Problem Solving
Pull-out zipper teeth  Use a rigid object (wrench, stick, etc.) to align them. ▪ To help you with small repairs, please refer to the repair guide, which can be consulted and downloaded from our website: https://inflatable.michelin.com/en/after-sales- service-maintenance/repair-guide Ref/document : Instruction manual MIS Classification: D3...
Page 18: Maintenance
Notice d’utilisation – Terrain multisport VIII.MAINTENANCE 1- Maintenance tips Covers should be folded appropriately to maintain their watertight properties and prevent damage during storage. You can wash the structure with a jet of water (avoid pressure washing). Use mild detergents: soap, dishwashing detergents, etc.. Wait for the structure to dry before storing it in its carry bag.
Page 19: Warranty Conditions
Notice d’utilisation – Terrain multisport IX. WARRANTY CONDITIONS The MICHELIN Inflatable Solutions guarantee lasts for one (1) year. This guarantee covers the following defects: Leaks from a defective weld. Valve detachment or valve leakage. The guarantee does not cover damage resulting from incorrect assembly, incorrect use or resulting from an external cause such as : Normal wear and tear of components.
Page 20 Notice d’utilisation – Terrain multisport IX. WARRANTY CONDITIONS When acting under the legal guarantee of conformity, the consumer : has a period of two years from the date of delivery of the goods in which to take ✓ action may choose between repairing or replacing the goods, subject to the cost ✓...
