Page 1: User Guide
USER GUIDE EZ Connect VisionTM Wireless Night Vision IP Camera SMCWIPCFN-G... - Page 2 Information furnished by SMC Networks, Inc. (SMC) is believed to be accurate and reliable. However, no responsibility is assumed by SMC for its use, nor for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of SMC.
- Page 3 The Limited Lifetime warranty covers a product during the Life of that Product, which is defined as the period of time during which the product is an “Active” SMC product. A product is considered to be “Active” while it is listed on the current SMC price list. As new technologies emerge, older technologies become obsolete and SMC will, at its discretion, replace an older product in its product line with one that incorporates these newer technologies.
- Page 4 IN THIS WARRANTY SHALL BE TAKEN TO AFFECT YOUR STATUTORY RIGHTS. * SMC will provide warranty service for one year following discontinuance from the active SMC price list. Under the limited lifetime warranty, internal and external power supplies, fans, and cables are covered by a standard one-year warranty from date of purchase.
-
Page 5: Federal Communication Commission Interference Statement
Compliances Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 6: Industry Canada Statement
To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the EIRP is not more than required for successful communication. EC Declaration of Conformity SMC contact for these products in Europe is: SMC Networks Spain, S.L. Edificio Conata II,... - Page 7 EU-overensstemmelseserklæring er tilgængelig under det relevante produktafsnit på følgende webadresse: http://www.smc.com. [German] Hiermit erklärt SMC Networks, dass sich dieses Wireless LAN Gerät in Übereinstimmung mit den grundlegenden Anforderungen und den anderen relevanten Vorschriften der Richtlinie 1999/5/EG befindet. Die offizielle EC-Declaration of Conformity finden Sie im Internet unter http://www.smc.com...
- Page 8 Conformity can be found under the corresponding product section on the web http://www.smc.com. [Spanish] Por medio de la presente SMC Networks declara que el Radio LAN device cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE.
- Page 9 Deklaracja zgodności UE znajduje się w odpowiedniej sekcji produktu w witrynie http://www.smc.com. [Portuguese] A SMC Networks declara que este dispositivo de LAN de Rádio está em conformidade com os requisitos essenciais e com outras provisões relevantes da Directiva 1999/5/CE. A Declaração de Conformidade CE oficial encontra-se na secção correspondente...
- Page 10 Royaume-Uni, Portugal, Grèce, Irelande, Icelande. Des conditions sont appliquées à certains pays pour l’utilisation en extérieur, tels que des licences spécífiques et des canaux d’opération. Veuillez contacter votre autorité locale ou SMC Networks pour plus de détails quant aux restrictions actuelles concernant l’utilisation en extérieur.
- Page 11 Portugal, Spanien, Sverige, Schweiz og Storbritannien. I visse lande gælder der krav vedrørende udendørs betjening af enheden, f.eks. licenskrav og tilladte betjeningskanaler. Kontakt de lokale lovgivende myndigheder eller SMC Networks for at få oplysninger om aktuelle begrænsninger vedrørende udendørs betjening. [Estonian] See seade on 2.4 GHz juhtmeta LAN vastuvõtu-saatejaam, mis on...
- Page 12 Βασίλειο, Πορτογαλία, Ελλάδα, Ιρλανδία, Ισλανδία. Σε ορισμένες χώρες επιβάλλονται απαιτήσεις για χρήση σε εξωτερικό χώρο, όπως απαιτήσεις παραχώρησης άδειας και επιτρεπόμενα κανάλια λειτουργίας. Απευθυνθείτε στην τοπική αρμόδια αρχή ή στην SMC Networks για λεπτομέρειες σχετικά με τους τρέχοντες περιορισμούς για χρήση σε εξωτερικό χώρο.
- Page 13 Unit, Il-Portugal, Il-Greċja, L-Irlanda, L-Islanda. Rekwiżiti għal tħaddim fuq barra, bħal ħtiġijiet ta’ liċenzja u kanali permessi għal tħaddim japplikaw f’ċertu pajjiżi. Jekk jogħġbok ikkuntattja lill-awtorità regolarorja lokali jew SMC Networks għal dettalji dwar restrizzjonijiet attwali dwar l-użu fuq barra. [Hungarian] Ez az eszköz egy 2,4 GHz-es vezeték nélküli LAN adó-vevő,...
- Page 14 Če potrebujete natančne informacije o trenutnih omejitvah uporabe na prostem, se obrnite na lokalni regulativni organ ali družbo SMC Networks. [Slovak] Toto zariadenie je prijímač a vysielač pre bezdrôtové siete v pásme 2,4 GHz a je určené...
-
Page 15: Safety Compliance
Írland, Ísland. Kröfur fyrir notkun utanhúss, svo sem kröfur um leyfi og heimilaðar rásir eiga við í sumum löndum. Hafið samband við reglugerðaryfirvöld á hverjum stað eða SMC Networks til að fá upplýsingar um gildandi takmarkanir á notkun utanhúss. [Norwegian] Denne enheten er en trådløs 2.4 GHz LAN-mottaker som er... - Page 16 Wichtige Sicherheitshinweise (Germany) 1. Bitte lesen Sie diese Hinweise sorgfältig durch. 2. Heben Sie diese Anleitung für den späteren Gebrauch auf. 3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Verwenden Sie keine Flüssig- oder Aerosolreiniger. Am besten eignet sich ein angefeuchtetes Tuch zur Reinigung. 4.
- Page 17 EN61000-4-6: 2001 EN61000-4-11 : 2004 A copy of the CE Declaration of Conformity is available for download at: http://www.smc.com Intended for indoor use in the following countries: AT, BE, CZ, CY, DK, EE, FI, FR, DE, GR, HU, IS, IE, IT, LV, LT, LU, MT, NL, NO, PL, PT, SI, SK, ES,...
-
Page 18: User Manual
MPEG4 Wireless Day & Night IP camera User Manual (SMCWIPCFN-G) Version 1.0 March, 2008... -
Page 19: Table Of Contents
Table of Contents Introduction………………………………………………………………………….. 20 Key Features………………………………………………………………………………………. 20 Package Contents………………………………………………………………………………… 21 Specification……………………………………………………………………………………….. 22 Product Views……………………………………………………………………………………… 23 Indicators…………………………………………………………………………………………… 24 System Requirements……………………………………………………........25 A. Hardware Installation…………………………………………………………… 26 Assembling the stand…………………………………………………………………………….. 26 Connecting to a Network………………………………………………………………………… 27 Connecting power………………………………………………………………………………… 27 B. Software Installation…………………………………………………....28 B.1.IPCamera Manager Server version –installation............ - Page 20 D.5.4.3. Alarm Actions……………………………………………………………………….. 55 D.5.4.4. Motion Detection……………………………………………………....D.5.4.5. Image Quality…………………………………………………………………….. D.5.5.Tools in Menu Bar of eMap Interface…………………………………………………. 58 E. Monitor Program…………………………………………………………………. 59 E.1. Running the Monitor Program……………………………………………………………… 59 E.2. Monitor Program Interface…………………………………………………………………. 60 E.2.1. Video Display Area…………………………………………………………………….. 60 E.2.2. PT Control Interface…………………………………………………………………… 60 E.2.3.
-
Page 21: Introduction
About this Manual This user manual has been designed to help you make the most of your IP camera and its many features and functions. Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. -
Page 22: Package Contents
Package Contents The package should contain all the following. If anything is missing or appears damaged, please contact your dealer immediately. IP camera module Stand (Mounting bracket) RJ-45 cable Mounting screws AC power adaptor Quick Install Guide CD-ROM with manual and IPCamera Manager™... -
Page 23: Specification
Specifications CMOS Camera 307,200 pixels VGA、1/4" CMOS sensor Number of effective pixels Lens Type Board Lens Focal length f = 3.6mm F-number F2.0 Format 1/4” 72ﾟ Angel of View System/Network CPU/Encode Chip ARM9 / MPEG4 encode chip Memory 16M DDR / 8M SDRAM / 2M Flash Video Compression MPEG4 Audio Compression... -
Page 24: Product Views
Product Views Use the following illustrations to familiarize yourself with the camera and identify each of the parts. Front View Power LED LAN LED Light Sensor WLAN LED Focus Adjust Night Vision IR LEDs*6 Lens Assembly Microphone Back View Restore Stand mount Button Press and hold the Restore button for three seconds or longer while powered on and IP... -
Page 25: Indicators
Indicators The following table shows what each of the LED indicators mean. Color Description Power Green Power indicator Green Network activity indicator WLan Green Wireless network activity indicator System Requirements The system requires an Ethernet port/wireless connection and an IP address. •... -
Page 26: System Requirements
System Requirement- SERVER version Intel P4 3.0GHz 1G or above Operating System Windows 2000 Pro Windows 2000 Server Windows 2003 Windows XP Home Windows XP Professional Windows Vista Home Basic Windows Vista Home Premium Windows Vista Business Windows Vista Ultimate Network 10/100 Mbps Fast Ethernet Display Card... -
Page 27: Hardware Installation
A. Hardware Installation Read this section to learn how to install the camera and connect it to a network. Assembling the Stand (Mounting Bracket) The camera can be assembled in two different ways; either from the top of the unit or the bottom. -
Page 28: Connecting To A Network
Connecting to a Network The IP camera can be connected to an Ethernet network using the RJ-45 port as shown. Connect the camera to an Ethernet hub or switch using a standard cable. You can also connect the camera directly to a computer using the supplied cable. Connecting Power Connect the power adapter to the DC-IN socket on the camera as shown. -
Page 29: Software Installation
B. Software Installation B.1. IPCamera Manager Server version – Installation Easy to Install Insert CD Input Software License Select Setup Type Select Feature Select Recording Folder Finish STEP 1: Please insert IPCamera Manager CD into CD-ROM drive. Go to IPCamera Manager\Server directory to execute Setup.exe. - Page 30 STEP 4: Click “Next” to begin the installation process. STEP 5: Please read the License Statement and select “Yes” to accept and continue. Select a setup type and Choose Destination Location or click “Next” to continue STEP 6: Specify the Destination Folder;...
- Page 31 STEP 7: Select the features you want to install. [Note] Main Component is a required component. IIS will need to be installed to support the Web Component. STEP 8: Select folder locations to store video recordings and input the size of the storage needed.
-
Page 32: B.2.Ipcamera Manager Client Version -Installation
STEP 10: Please review the configuration you have chosen and click “Next” to accept these settings to continue. [Note] The installation process may take several minutes to complete, depending on the specifications of your computer system. STEP 11: Click “Finish” to complete the setup. -
Page 33: Ipcamera Manager-Uninstall
B. 3. IPCamera Manager – Uninstall Click Start Control Panel Add or Remove Programs STEP 1: Select “Change/ Remove” to remove IPCamera Manager from your system. STEP 2: Select “Remove”. Remove Confirmation. STEP 3: Select “OK” to remove IPCamera Manager from your system. - Page 34 STEP 4: Click “OK” to continue the uninstall process. Uninstall Complete. STEP 5: Click “Finish” to exit the window.
-
Page 35: Start Service Program
C. Start Service Program C.1. Automatically starts upon system boot up Only one IPCamera Manager Server’s control program can be running at a time. The computer with the running control program will become IPCamera Manager Server. After installation, the program can be found in the windows start menu at Start Programs IPCamera Manager... -
Page 36: System Administration Program
D. System Administration Program D. 1. Running the System Administration Program STEP 1: Select Start All Programs IPCamera Manager System Administration STEP 2: System Log on window. Server Location: “127.0.0.1” is the default IP address for local server. If you want to access server from client, then please enter the IP of server to this text box. -
Page 37: System Administration Program Interface Overview
D. 2. System Administration Program Interface Overview The System Administration Menu Bar screen is divided into three areas: The Menu Bar area The System Setup area The eMap Interface area If your system does not display the screen properly, please check if your current display resolution is set at least 1024 x 768, and that the font size is... -
Page 38: System Configuration Overview
D.3. System Configuration Overview Select System Configuration icon in System Setup Area, you will see the button in Menu Bar change accordingly. Button Use To E-Mail Setting: Specify the email outgoing server for sending security alert. Holiday Setting: Specify the calendar holidays for schedule setting which is not included in weekly routine. -
Page 39: D.3.3.Storage
[Note] User is able to enable alarm service full day during these holidays if you check “Holiday” box in Section D.5.4.3 Video – Alarm Actions. Export: If you have installed multi sites with IPCamera Manager server, they might require the same holiday settings. You can set on one server first, and use the “Export”... - Page 40 Path1 and Path2 Assign folder to store recorded data Area 1 of Schedule and Alarm. (Alias: Please assign a name for the path, so it can be easily differentiated) Storage1 and Storage2 Set the maximum disk space for recording image. Allocation: The storage allocation Area 2 should be no less than 2 GB.
-
Page 41: D.3.4.System Alarm
D.3.4. System Alarm By selecting System Alarm button from the Menu Bar, you can enable system diagnostics and alarm action. Alarm Action from three system events: 1. Storage Threshold Reached. 2. Device Disconnected. 3. Database Error. Ring Settings: there are 4 sound effects available;... -
Page 42: Rotation
D.3.5. Rotation By selecting Rotation button from the Menu Bar, you can set the camera to assigned split screen and rotation interval. Select the Tab of split STEP 1: screen: 4CH, 9CH, 16CH and 32CH. Assign camera to split screen. STEP 2: Example: (16-splitscreen) Select 16CH Tab, then select... -
Page 43: User Group Overview
D.4. User Group Overview D.4.1. User The User Group functions in System Setup area is for managing user privileges. Default user “Administrator” is created with full privileges during installation. You can add users to the system and differentiate their privilege by designating them to different groups. -
Page 44: Delete User
Designating a User to a Group. STEP 3: Select the “User Belongs” tab to designate a user to a group. Select the group name and move it between “Selected group” and “Unselected group”. Click “OK” to continue. STEP 4: After setting both general information and user belongs, click “Create”... -
Page 45: Group
D.4.2. Group Admin Group is the user group that has the full access and privileges to the Admin and Monitor programs. The user of “Administrator”, system default and belong to “Admin Group”, can add users and assign users to any user group. Monitor Group is the group for general users that has the full access and privileges to the Monitor program. -
Page 46: Delete Group
D.4.2.2. Delete Group Select Delete Group button from the Menu Bar and a warning message box will appear. Click “OK” to delete a group. D.4.2.3. Edit Group STEP 1: Select Group icon in the System Setup area; the User Group Table display in eMap Interface area. -
Page 47: Area And Emap Management Overview
D.5. Area and eMap Management Overview Area refers to the geography and device scope of the IPCamera Manager. Area is a prerequisite of any device setting; IPCamera Manager provides multi-areas to meet users’ different requirements. eMap refers to (1) a hierarchical tree-structured management tool in System Setup area (2) background of the area, it could be a picture or a map (3) an interface which combines eMap background and device icon, eMap visually presents the devices in your security system. - Page 48 Change Icon Size: This button allows you to change the ratio of the device icons to display on the eMap interface. Add Camera: This button allows you to add a new camera to the area. When you select the Camera icon, Menu Bar will display the following functions: Button Use to Edit Camera: This button allows you to configure IP/ Port Number...
-
Page 49: Emap
D.5.1. eMap By selecting eMap icon, you can add or delete one area or all areas. D.5.1.1. Add Area STEP 1: Select eMap icon from the System Setup. STEP 2: Click Add Area button from the Menu Bar. An Area Setting window will pop up. -
Page 50: My Map
D.5.2. My Map By selecting My Map icon, you can edit area, delete area, load/refresh map, change icon size and add camera. D.5.2.1. Edit Area STEP 1: Select My Map icon. STEP 2: Click the Edit Area button. You can modify the area name. -
Page 51: Add Camera
D.5.2.6. Add Camera STEP 1: Click button from the Menu Bar to bring up the Add Camera window. STEP 2: You can add camera(s) automatically by choosing “Auto Search” then “Next” or manually “Manual”. Auto Discovery. STEP 2a: The system will search all cameras that are located within the same subnet in a LAN environment. -
Page 52: Camera
After device is added, you can modify the Video Settings (refer to Section D.5.4. Video). [Note] In the left example, the Camera now appears under Area icon - the device tree of System Setup area and of video icon appears under the camera tree. -
Page 53: Video
STEP 1: Select the device icon in the System Setup area, and click Device Password button from the Menu Bar to bring up the setting window. STEP 2: Current User Name/Password： (1) Information saved in system currently. (2) System default User Name: root. - Page 54 STEP 2: Set Orientation Click on the right of Image Rotation drop list to support different camera mounting methods. Options available are “Normal” or “Inverted”. [Note] (1) Monitor program requires restarting to activate the new setting. (2) This configuration will require at least 20 sec to reconnect camera.
- Page 55 function can be found in Image setting, weekly setting, alarm action, etc. STEP 4: Click “Create” to save the setting. [Note] Weekly setting is a reoccurring setting which automatically applies to the following week, with each block being equal to 1 hour. If an error message pops up, please check if any related device is unable to connect due to the information described...
-
Page 56: Delete Video
D.5.4.2. Delete Video Remove all the configuration of a selected video. D.5.4.3. Alarm Actions Click Alarm Actions to set alarm action when alarm is detected on selected video. Activate Alarm Action STEP 1: Select the Video icon of a Camera in the System Setup area, then click Alarm Actions button from the Menu Bar to bring up the Alarm Actions... - Page 57 immediately. STEP 7: Create it to Alarm Action List Click “Create” to add action to alarm action list. If no further action to add, click “Close” to dismiss this window. STEP 8: Click “Add” to add new Alarm Action. STEP 9: Click “OK”...
-
Page 58: Motion Detection
D.5.4.4. Motion Detection STEP 1: Select the Video icon of a Camera in the System Setup area and click Motion Detection button from the Menu Bar to bring up the Motion Detection window. STEP 2: Setting Detection Area: A red square will follow the movement of the mouse. -
Page 59: Image Quality
D.5.4.5. Image Quality STEP 1: Select the Video icon of a Camera in the System Setup area, then click Image Quality button from the Menu Bar to bring up the Image Quality window. STEP 2: You can drag the scroll bar right or left for your viewing preferences. -
Page 60: Monitor Program
E. Monitor Program Monitor program can be selected from the Program Path; user may log into the monitor program through Monitor.exe or Web monitor. You can also access IPCamera Manager server through IE browser by entering the URL. (Format: IP address of server and \Web Example:127.0.0.1\Web) E.1. -
Page 61: Monitor Program Interface
E.2. Monitor Program Interface The User Interface has been classified into the following functions: Video Display Area PT Control interface Display Selection 4: Alarm Notification Alarm Notification Log Camera Selection System/Video Setting E.2.1. Video Display Area Video display area displays video of a single camera or split screen of multiple cameras. When you want to control a camera in your monitor program, you can click the split-ed screen and it will be covered by a red-frame. -
Page 62: Display Selection
1: PT Speed: You can select the drop list to change the speed of camera movement. 2: PT control: PT interface consists of a control icon which can be used to change the view angle of your camera to 4 directions manually. -
Page 63: Alarm Notification Log
E.2.5. Alarm Notification Log The most up-to-date alarm is logged in the alarm notification log. E.2.6. Camera Selection Select a camera number to display the video. E.2.7. System/Video Setting E.2.7.1. Playback The Playback button allows you to playback recorded video of “Schedule Recording” or “Alarm Recording”. -
Page 64: Query Alarm
E.2.7.2. Query Alarm STEP 1: Click “Query Alarm” button. STEP 2: Open a window to set query criteria. Query Alarm Log via criteria setting of: 1. Display Alarm Only or Display Alarm and Actions 2. Alarm location 3. Alarm Type 4. -
Page 65: Manual Recording
E.2.7.4. Manual Recording Live video can be manually recorded in the local computer by clicking the Manual Recording button. STEP 1: Select a camera from display area by a red frame. STEP 2: Click button to start the recording. [Note] The button will change from . -
Page 66: Manual Recording Folder
E.2.7.6. Manual Recording Folder Click button, system will bring up Manual Recording Folder window for user to select the local recording folder. System will create a sub-folder differentiated by camera location automatically. E.2.7.7. Pause Live Image Click the pause button , the live video will be paused and the button changed to play button . -
Page 67: Web Monitor Program
F. Web Monitor Program Web Monitor provides User an easy access thru IE to access real time video and central monitoring. Log on Web Monitor from server Start Program Files IPCamera Manager Web Monitor。 Log on Web Monitor from client Open IE browser and enter the URL in the format of server IP and “\Web”. -
Page 68: Media Viewer Program
Monitor and Monitor program are (1) no alarm notification log and (2) no schedule status display in the Web Monitor. G. Media Viewer Program Media Viewer is a program designed for quickly accessing and viewing alarm or schedule recording files. Browse…... -
Page 69: Other Settings
H. Other Settings Read this section to learn how to configure the IP Camera by using the settings menus. To access the settings menus, click “Open Web Interface” icon while you are adding a new camera (auto search/manually) or entering device settings. Auto Search Camera：... - Page 70 Device Setting： Then, enter User name and Password. The default User name and Password are set to “admin”. A login prompt appears: Then the setting page will appear. There are two sub menus in the menu sidebar: “Basic” and “Advanced” settings.
-
Page 71: H.1.Configuring Basic Settings
H.1.Configuring Basic Settings Read this section to learn about settings and options available on “Basic” Setting. H.1.1.Configuring System Settings The System submenu allows you to configure system related settings. There are four main screens accessible via the tabs at the top of the screen: Status, Log, Time, and Firmware. -
Page 72: H.1.1.3.Time Settings
H.1.1.3.Time Settings Click the “Time” tab on the top to access the date and time settings screen. You can choose “Synchronize with Time Server”, “Synchronize with computer time” or “Set manually”. If you select “Synchronize with Time Server”, check the checkbox then choose your time zone and enter NTP server details. -
Page 73: H.1.1.4.Firmware Upgrade
H.1.1.4.Firmware Upgrade Click the “Firmware” tab on the top to access the firmware upgrade screen: Here you can upgrade the system firmware version, reset and restore original camera settings. Click button to restart the camera. Click button to reset all settings to original factory default settings except current IP address. -
Page 74: H.2.1.Ethernet Settings
H.2.1.Ethernet Settings Click the “Ethernet” tab on the top to access the ethernet settings screen: Here you can configure your ethernet, DNS and HTTP port settings. Under IP Configuration and DNS Configuration, you can enter the settings manually or select the “Obtain IP address via DHCP” and “Obtain DNS server address via DHCP” radio button to obtain the address via DHCP. -
Page 75: H.2.2.Wireless Settings
H.2.2.Wireless Settings Click the “Wireless” tab on the top to access the wireless settings screen: Here you can configure wireless network settings for your camera. If your network allows for wireless connection, complete all the fields under “Basic Configuration” to connect wirelessly. Ask your network administrator for all relevant information should you need it. -
Page 76: H.2.3.Pppoe Settings
H.2.3.PPPoE Settings Click the “PPPoE” tab on the top to access the PPPoE settings screen: Here you can configure PPPoE connection settings. If you connect to your network via PPPoE, check the “Enable PPPoE” checkbox and enter your User Name and Password. Check the “Send Email when IP changes”... -
Page 77: H.2.4.Ddns Settings
H.2.4.DDNS Settings Click the “DDNS” tab on the top to access the DDNS settings screen: Here you can configure DDNS connection settings. DDNS allows PPPoE or DHCP dynamic IP users to access the IP camera using a single domain name. The IP camera supports DDNS and meets the Dynamic Network Service, Inc standards. -
Page 78: H.3.Configuring User Settings
H.3.Configuring User Settings The User submenu enables you to set up users and administrators for the system. There are two main screens accessible via the tabs at the top of the screen: “User” and “Password”. H.3.1.User Settings Click the “User” tab on the top to access the user settings screen. Under “User Authorization”, check “Allow anonymous viewer”... -
Page 79: H.3.2.Password Settings
H.3.2.Password Settings Click the “Password” tab on the top to access the password settings screen. Enter your username and new password. Re-confirm the new password and click to change the password. H.4.Configuring Video Settings The Video submenu enables you to configure video and audio settings. There are two main screens accessible via the tabs at the top of the screen: “Video”... - Page 80 Connection Speed: Select the High, Medium or Low radio buttons depending on the speed of your network connection. Resolution: Select the image resolution you require from the drop- down box. Compression: Select the image compression you require from the drop-down box. Maximum Frame Rate: Enter the maximum frame rate you require.
-
Page 81: H.4.2.Monitor
H.4.2.Monitor The Monitor submenu enables you to playback and convert recorded video clips to playable video format. Click button to locate the file you wish to play. Click buttons to start and stop playback. Click button to convert the open video clip from .av to .avi format. -
Page 82: Configuring Advanced Settings
I. Configuring Advanced Settings Read this section to learn about settings and options available under the Advanced Setting submenu. I.1.Configuring FTP Settings The FTP submenu enables you to configure all FTP (File Transfer Protocol) settings: When FTP alerting is enabled, the camera sends a still image to the ftp server every time the alert is triggered (see “Configuring Breach Manager Settings”... -
Page 83: I.2.Configuring Mail Server Settings
I.2.Configuring Mail Server Settings The Mail submenu allows you to configure mail server settings: When mail alerting is enabled, the camera sends a still image to a specified email address every time the alert is triggered. Enter your mail server address, mail sender address, and mail receiver address. Check the radio buttons to enable notification via SMTP and enter your username and password. -
Page 84: I.3.Configuring Alarm Settings
I.3.Configuring Alarm Settings The Alarm submenu enables you to configure all breach alerts and motion detection settings: You can configure the system to capture images when the motion detection is enabled. To set a breach alert, do the following: Select the alert trigger device type by checking the “Enable”... -
Page 85: Using An Internet Browser To Connect To The Camera
J. Using an Internet Browser to Connect to the Camera Read this section to learn how to use your Internet browser to connect to the IP camera, view images, and hear audio. To connect to the IP camera using an Internet Explorer: Launch “System Administration”... - Page 86 “Auto Search Camera” window will appear and will start scanning for the camera in the network. When the scanning is completed, the camera information on the network will be displayed. Click “Create” button to complete the process. ** Please take note of the IP address of the camera Enter the IP address of the camera in the Internet browser address field.
-
Page 87: Appendix 1. Iis Installation For Windows Vista
Appendix 1. IIS installation for Windows Vista To Install IIS for Windows Vista version, please do the followings: STEP 1: Click “Continue”. STEP 2: Start Control Panel Program and Features Click Turn Windows features on or off. The Windows Features dialog box opens. - Page 88 STEP 4: Double-click (or expand) “Web Management Tools”, double-click “IIS 6 Management Compatibility”, then select the “IIS 6 Management Console, IIS 6 Scripting Tools, IIS 6 WMI Compatibility, IIS Metabase and IIS 6 Configuration Compatibility” check box. STEP 5: Double-click (or expand) World Wide Web Services, double-click Application...
- Page 89 Magyar: Műszaki tamogat informacio elerhető -on www.smc.com 简体中文: 技术支持讯息可通过www.smc-prc.com查询 繁體中文: 產品技術支援與服務請上 www.smcnetworks.com.tw ไทย: สามารถหาข้ อ มู ล ทางด้ า นเทคนิ ค ได้ ท ี ่ www.smc-asia.com 한국어: 기술지원관련 정보는 www.smc-asia.com을 참고하시기 바랍니다 INTERNET E-mail address: techsupport@smc.com Driver updates http://www.smc.com/index.cfm?action=tech_support_drivers_downloads World Wide Web http://www.smc.com/...
