SMC Networks WGBR14-N - FICHE TECHNIQUE Manual

WIRELESS
OVERVIEW
The Barricade™ N ProMax Gigabit Broadband Router (SMCWGBR14-N) is the
perfect all-in-one networking solution for connecting and sharing your high
speed cable/xDSL internet connection. Designed for the home and of-
fice, this platform independent multi-functional router combines a 4-port
10/100/1000Mbps LAN switch, high speed Wireless-N (802.11n) access point,
NAT firewall with Stateful Packet Inspection (SPI), Intelligent stream han-
dling technology, a Multi-function print server and a User friendly web-based
management interface in one convenient device.
The built-in wireless access point is Wi-Fi CERTIFIED™ for full compliance
with the 802.11n standard, as well as the popular Wireless-G (802.11g) and
Wireless-B (802.11b) standards. This next generation wireless networking stan-
dard utilizes advanced MIMO (Multiple-In, Multiple-Out) technology to de-
liver incredible speed and range. With wireless speeds up to 300Mbps and
up to 11x the coverage, there is enough bandwidth to simultaneously stream
video and audio, play online games, transfer large files, make VoIP calls and
surf the Internet. With security being a key consideration, SMCWGBR14-N
supports the latest WPA and WPA2 wireless encryption standards, which
prevent unauthorized access to wireless networks and ensure data is
secure. Wireless security can also be set up easily using Wi-Fi Protected
Setup™ (WPS) that enables push button or PIN configuration. The 4-port
10/100/1000Mbps LAN switch is ideal for connecting Gigabit Ethernet
FEATURES
Share your high speed cable/xDSL internet connection
4-port 10/100/1000Mbps Gigabit LAN switch with auto MDI-MDIX
Built-in Wireless-N (802.11n) access point
NAT firewall with Stateful Packet Inspection (SPI)
WPA/WPA2 Encryption
Wi-Fi Protected Setup™ (WPS)
Intelligent stream handling technology
USB2.0 Multi-function print server
Web-Based management interface
www.smc.com
SMCWGBR14-N
Barricade™ N ProMax Wireless 4-port Gigabit Broadband Router
devices, such as Network Attached Storage (NAS), and transferring large
files or streaming media content at up to gigabit speeds.
The integrated NAT firewall with SPI provides protection from hackers and
Denial of Service attacks by analyzing individual data packets, to ensure
that only authorized packets are allowed access to the network. Using the
Access Control feature parents or network administrators can block certain
websites, limit web access based on time or dates, and/or block internet
access for applications like P2P utilities or games. Intelligent stream
handling technology automatically manages and prioritizes the flow of
time-sensitive data in your local network and going to the Internet, without
the need for end user configuration. As a result time-sensitive applica-
tions like online gaming and video, run smoothly without lag and breakup
problems. We've also included a USB2.0 multi-function print server which
supports both printing and scanning*. The print server has been designed
with ease-of-use at the forefront and can be setup in minutes using the
printer installation wizard. Scanning and saving of documents is performed
using a web-based interface so there is no need to install scanning software
on each computer. Finally, configuration of your internet connection and ad-
vanced router functions is made simple and straightforward with the EZ™
Installation Wizard and intuitive web-based management interface.
BENEFITS
Simply connect your cable or xDSL modem with Ethernet connection to the
10/100/1000Mbps WAN port for instant always on internet.
Connect Gigabit Ethernet devices, such as Network Attached Storage (NAS), and
transfer large files or stream media content at up to gigabit speeds.
Delivers speeds up to 300Mbps and up to 11x the coverage. Perfect for streaming
video and music, online gaming and networking multiple PC's.
Provides protection from hackers and Denial of Service attacks by analyzing indi-
vidual data packets, to ensure that only authorized packets are allowed access to
your network.
Prevents unauthorized access to your wireless network and insures your data is
secure.
Makes wireless security setup easy with push button and PIN configuration methods.
Automatically manages and prioritizes the flow of time-sensitive data in your
local network and going to the Internet, without the need for end user configura-
tion. As a result time-sensitive applications like online gaming, voice and video,
run smoothly without lag and breakup.
Print and scan from any PC on your network*
Simple and straightforward set-up with the intuitive web-based management
interface and EZ™ Installation Wizard.
