GRB Series PTC Temperature control module
1.SUMMARIZATION
The GRB series PTC Temperature control module is specially designed for
being used with MZ6 PTC Thermistors, if the electric motor ( or some place on the
electric motor)is overheating, the resistance of PTC Thermistors will rise, and can be
passed to the protection apparatus, the relay contact inside the protection apparatus
transforms to push the control circuit(electromagnetic switch etc) to switch off the
main power source, and further to protect the elector motor.
2.TECHNICAL PARAMETER
1)
Operating voltage：AC 220V;
2)
Allowable volt tolerance：±20%;
3)
Frequency：50～60Hz;
4)
Self-consuming power：<0.8VA;
5)
Allowable environment temperature：-30～70℃;
6)
Rated current of switch：7A;
7)
Operating resistance：3KΩ×（1±10%）;
8)
Restoring resistance：1500～1800Ω;
Weight：0.2Kg.
9)
3、PARAMETER CONNECTION DIAGRAM
JS-Technik GmbH - Lether Gewerbestrasse 10 - 26197 Großenkneten
Operation manual
1
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for JS Technik GRB Series
- Page 1 GRB Series PTC Temperature control module 1.SUMMARIZATION The GRB series PTC Temperature control module is specially designed for being used with MZ6 PTC Thermistors, if the electric motor ( or some place on the electric motor)is overheating, the resistance of PTC Thermistors will rise, and can be...
- Page 2 4、OUTLINE DIMENSIONS：68×33×53(mm) 5、INSTALLTION AND USE 1、Installation 1) First please confirm the model of the product conforms to the electrical machinery’s matching requirement. 2) Install the protector in the equipment’s control cabinet, avoid the fire and the rain. 3) The GRB-2 type electric motor overheated protection apparatus’s base is equipped with the slot, fix one side of the base slot of protector on one side of the JS-Technik GmbH - Lether Gewerbestrasse 10 - 26197 Großenkneten...
- Page 3 distributing box or distribution cabinet’s track, then pull out the protector’s set pin, put the protector into the distributing box or distribution cabinet’s track, unloose the protector’s set pin, then fix the protector into the track. When installing, strain should be made evenly, in order to avoid causing the product damage. As shown in figure 1.
- Page 4 2) Lead wire should be connected to the right wiring terminal and firmed. 3) Cover the wiring lid tightly after wiring. 4) The installation is finished, as the chart shows. 3、Safety attention 1) When installing the protector, the product can’t be stricken, prevents the product the product from being damaged.
- Page 5 elements being damaged. 3) The product should install in the distribution box or the distribution cabinet prevented the product being soaked by the water. 4) Before installation, please confirm whether the product specification model conforms to the requirement, prevents the wrong use. 5) Please confirm the input power source is cut off before wiring, in order to avoid getting an electric shock.
