The document is intended for use by end-of-life recyclers or treatment facilities. It provides
the basic instructions for the disassembly of LG products to remove components and
materials requiring selective treatment.
Product Identification
Type of Product
Model name
Displays must be stored in accordance with the requirements stipulated in Appendix VII (1)
or (2) of Directive 2012/19/EU and must, amongst other things, be stored in a
weatherproof manner. Containers with covers must be used when storing and transporting
the Displays.
Contents
1. Materials and components for Selective Treatment
2. Tools Required
3. Product Dismantling Process
Dismantling information
LED TV
32LR60006LA
Advertisement
Related Manuals for LG 32LR60006LA
Summary of Contents for LG 32LR60006LA
- Page 1 Dismantling information The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions for the disassembly of LG products to remove components and materials requiring selective treatment. Product Identification Type of Product LED TV...
- Page 2 1. Materials and components for Selective Treatment Displays may contain hazardous substances like Pb and BFRs which are covered by exemptions under the RoHS directive. However, the majority is present in the PCB assembly. In order to reduce emissions as much as possible, a complete disposal of the old appliance is required. This treatment may only be performed in authorized handling plants.
-
Page 3: Tools Required
2. Tools Required List the type that would typically be used to disassemble the product to a point where components and materials requiring selective treatment can be removed. Tool Description Tool information Screw driver Nipper... - Page 4 3. Product Dismantling Process 1. Batteries Batteries can easily be removed from the remote control once the back cover of the remote control has been removed.
- Page 5 3. Product Dismantling Process 2. PCBs and LCD Module Remove the stand with (+) screw driver 1.Remove the back cover. Remove the Screws with (+) screw driver Release the buckle with a (-) screwdriver on the shown position 2.Place your hands on back cover and lift the back cover up and pull back *The angle at which the back cover is lifted should not be too large, otherwise the buckle will be damaged...
- Page 6 3. Product Dismantling Process 2. PCBs and LCD Module 3.Take the AV stand with hands and pull out horizontally 4.Remove the mainboard screws with (+) screw driver and disconnect all the cable. 5.Remove the mainboard *Be careful not to touch the high-voltage area in the red frame...
- Page 7 3. Product Dismantling Process 2. PCBs and LCD Module 6.Remove the back cover screws with (+) screw driver. 7. Release the buckle with “(-)” screw driver and remove the back cover.
- Page 8 3. Product Dismantling Process 2. PCBs and LCD Module 8.Remove the FFC cable and WIFI Antenna Use a plastic sheet or blade to separate the adhesive from the backplate. LCD Module...
- Page 9 3. Product Dismantling Process 3. Power cord To unplugged the Power cord need press down on the snap and pull it back at the same time 4. Capacitors > 25 mm Capacitors > 25 mm are located in the power supply units and can be removed by nipper Nipper *sample picture...
