Page 2: Safety Information
SAFETY INFORMATION PRODUCT DESCRIPTION Our powerful portable air conditioners are great cooling solutions for single rooms, creating a comfortable atmosphere in your space. They also have ventilation, heating (model dependent) and dehumidifying functions for effectively circulating air and the removal of excess moisture. They are self- contained systems allowing you to move the unit to the space in which it is most needed. - Page 3 SYMBOLS FROM THE UNIT AND USER MANUAL This unit contains a flammable refrigerant. If the refrigerant leaks and comes in contact with fire or other warning heating part, it will create harmful gas and there is risk of fire. Read the INSTRUCTION MANUAL carefully before operation. Further information is available in the INSTRUCTION MANUAL, and the like.
-
Page 4: The Following Should Always Be Observed For Safety
THE FOLLOWING SHOULD ALWAYS BE OBSERVED FOR SAFETY The unit is designed only for use with R290(propane) gas as the designated refrigerant. The refrigerant loop is sealed. Only a qualified technician should attempt to service! Do not discharge the refrigerant into the atmosphere. ... -
Page 5: Operational Precautions
OPERATIONAL PRECAUTIONS WARNING - to reduce the risk of fire, electric shock or injury to persons or property: If the supply cord is damaged, it must be replaced by the service agent or similarly qualified persons to avoid a hazard. ... - Page 6 Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacture. The appliance should be stored in a room free from continuously operation sources (for example: open flames, an operating gas appliance or an operating electric heater).
-
Page 7: Product Overview
PRODUCT OVERVIEW PRODUCT IDENTIFICATION Control Panel Air Outlet with Manual Ho rizontal and Vertical Adjustable Louver Handle Air Inlet with Air Filter Cast r Drainage Opening Air Exhaust Note: The unit in the above diagram is for reference only and may differ slightly from the model purchased. -
Page 8: Product Features
PRODUCT FEATURES Compact unit with High Output Capacity Cooling, Heating (DVAC10CHW model only) Dehumidifying and Fan Functions Wi-Fi Enabled Compatible with Alexa and Google Home Devices 1.8m Exhaust Hose 2 Window Kits Horizontal and Vertical Manual Louver Oscillation ... -
Page 9: Installation
INSTALLATION UNPACKING Unpack the carton taking the appliance and all accessories out. Please check that no parts are missing before installation. Accessories: Ducting Hose（1.8m) Duct Hose Connector Duct Window Kit Adapter Remote Control Window Kit Plate ... - Page 10 PRE-SET UP ADVICE If tipped more than 45°, allow the unit to sit upright for at least 8 hours before operation. Place the unit on a firm, level surface in an area with at least 50cm of free space around it to allow for adequate air circulation.
- Page 11 WARNING! Install the unit in rooms which exceed 10m². Do not install the unit in a place where inflammable gas may leak. INSTALLING THE WINDOW KIT The portable air conditioner must be vented outside to remove the hot air. There are two types of window kit provided. Only one type of kit is required and will depend on the window or door being used.
- Page 12 Step 4: Close the window to secure the kit in place. It needs to hold the window kit firmly in place (secure the window kit with duct tape if required). It is recommended that the gap between the adapter and the sides of the window should be sealed off for maximum efficiency.
- Page 13 Step 7: Adjust the louver at the air outlet and switch on the unit. The louvers can be manually adjusted to control the air flow horizontally and vertically. FLEXIBLE WINDOW KIT INSTALLATION Mark the middle (M) of the window seal (Fig.1) Mark the middle of the window frame and the casement (Fig.2-4) (Figure2 shows an open window, Figure 3 a tilted window and Figure 4 an open skylight).
-
Page 15: Operation
OPERATION CONTROL PANEL AND DISPLAY POWER Press to switch the machine on or off. Press to switch between the operating modes: fan, MODE cooling, heating (where applicable) and dehumidifier. SPEED Press to switch between the Low and High fan speeds. DOWN Decrease the desired temperature or timer setting. - Page 16 1. High Fan Speed 2. Low Fan Speed 3. Timer 4. Dehumidifier Mode 5. Heating Mode 6. Cooling Mode 7. Fan Mode 8. Sleep Mode 9. Child Lock 10. Wi-Fi 11. Display Window...
-
Page 17: Remote Control
REMOTE CONTROL... -
Page 18: Startup And Shutdown
SETTINGS Start-up and Shutdown Press the POWER button to turn the unit on (when the unit begins operating it runs on the fan mode as default). Press the POWER button again to turn off the unit. Operating Modes The unit has five operating modes: Cool, Dry, Fan, Heat (for heating model only), Sleep. -
Page 19: Drying Mode
Drying Mode Press the MODE button repeatedly until the LED DRY icon illuminates. The fan speed cannot be changed in this mode. When using the drying mode, the user should connect the drainage hose to the drain outlet at the bottom of the unit. Note: In this mode, the low fan speed is set as default and cannot be changed. -
Page 20: Timer Function
TIMER FUNCTION The timer function can be set between 1-24 hours, in hourly increments. The timer has two modes of operation: Press Timer key to Use the Up/Down To turn off turn on the timer arrows to set the (When power on) function. - Page 21 9. WIFI CONNECTION How to connect to your mobile phone This appliance allows you to operate the appliance via your home network. A prerequisite is a permanent WIFI connection to your router and the free app “Smart Life”. “ Smart Life” app is available for android and iOS.
- Page 22 TROUBLE SHOOTING Network connection failed Solution 1.Check if you have selected the Wi-Fi named “ SmartLife- XXXX” . Network connection 2 .Turn off the machine and unplug it from the timeout power source. Wait 10 seconds before plugging the unit back in, then follow the connectivity instructions.
- Page 23 How to connect to your Alexa devices • Type ‘Smart Life’ in the search bar and click the option with the icon • Click ‘Enable to use and type your phone number/ email address and password and click ‘Link Now’ •...
- Page 24 How to connect to your Google Home devices Follow the below instructions to connect your device to Google Home. Download the Google Home App and pair your device. Note: change the name of the device to an easily identifiable name such as ‘Air Conditioner’. Note: Ensure you have downloaded and have configured the Google Home/Assistant apps.
- Page 25 How to connect to your Google Home devices • Click ‘Works with Google’ • Type ‘Smart Life’ in the search bar and click the option with the icon • Enter your phone number/ email address and password and click ‘Link Now’...
- Page 26 How to connect to your Google Home devices Click ‘Authorise’ and all devices from • your Google Home App will appear on screen. You then have the option to add these to a particular room in your home. When you go back to the home screen, your devices will now appear, and you can operate the unit using voice control.
- Page 27 DRAINAGE Self- evaporating system There is usually no need to empty the drainage tank in cooling mode, as the self-evaporating system uses the collected water to cool the condenser coils and the excess water is evaporated and released through the exhaust hose. The drainage tank will usually fill up when used in heating mode (DVAC10CHW model only) or in dehumidifying mode.
-
Page 28: Cleaning The Air Filter
To avoid water spillage: • As the negative pressure of condensate drain pan is large, tilt the drain hose downward toward the floor. It is appropriate that the degree of inclination should exceed 20 degrees. • Straighten the hose to avoid a trap existing in the hose. CLEANING AND CARE CLEANING THE AIR FILTER Dust collects on the filter and restricts the airflow. - Page 29 Pic2. Rinse the air filter under running Pic1. Switch off the unit and remove the water. air filter. Warning!!! Do not touch the evaporator surface with your bare-hand, or it could cause injury of your fingers. CLEANING UP OF REFRIGERANT General Measures: ...
- Page 30 spray to disperse vapors. Isolate the area until gas has dispersed. Ventilate and gas test area before entering. Contact competent authorities after a spill.
-
Page 31: Troubleshooting
TROUBLESHOOTING Symptom Inspection Solution Insert the power cord and check Check the power connection. the power outlet. The unit is not Check if the water level Empty the tank by removing the indicator is illuminated. rubber plug. operating. - Page 32 DECOMMISSIONING STORAGE Long-Term Storage - If you will not be using the unit for an extended period (more than a few weeks), it is best to clean the unit and dry it out completely. Please store the unit per the following steps: Unplug the unit, emove the exhaust hose and window kit, to store with the unit.
- Page 36 35 36...
