Summary of Contents for Vantage Hearth D9 Series
- Page 1 VantageVehicle.com 2024 Lithium Electric Vehicle Owner’s Manual (R4) Vantage Vehicle D9 series Trucks and Vans LIV9DX LIV9DR LIV9DP LIV9DC...
-
Page 2: Introduction
Introduction This manual will familiarize you with the operation, maintenance, safety and warranty information about your new vehicle. Updates to this manual are available online with links on our website – www.vantagevehicle.com. Some of the equipment described in this manual and the various illustrations may not apply to your vehicle. Specifications and descriptions in this manual are accurate at the time of printing. -
Page 3: Table Of Contents
Table of Contents Introduction ............................. 2 Safety Nomenclature..........................4 Vehicle Overview ..........................5 Vehicle Identification Tags ........................6 Replacement Keys ..........................7 Audible Warning Device ........................7 Operator Safety ............................ 8 Main Electrical Disconnect ........................9 Features and Controls, Diagnostic System, Rear Backup Camera ........10,11,12 Key Switch ........................... -
Page 4: Safety Nomenclature
Safety Nomenclature The following safety indications and nomenclature are used and appear in this manual and on your vehicle. Please become familiar with their meanings and applications when reviewing this manual. Hazardous situation which will result in a serious injury or death Hazardous situation which could result in a serious injury or death ⚠... -
Page 5: Vehicle Overview
Vehicle Overview This manual covers Vantage’s LIV9DC and LIV9DP vans, as well as the LIV9DX and LIV9DR pickup trucks. It is the user’s responsibility to adhere to all state and local laws pertaining to the use of Vantage vehicles used in LSV (low speed vehicle) applications. -
Page 6: Vehicle Identification Tags
Vehicle Identification Tags The VIN (Vehicle Identification Number) tag is located on the driver’s side of the dashboard, well under passenger seat, as shown in the photos on left. In addition, a manufacturers identification label is also located in the driver’s side door jamb. This indicates the recommended tire pressures, gross vehicle weight (GVWR) and gross axle weight rating (GAWR). -
Page 7: Replacement Keys
Replacement Keys Your Vantage vehicle comes with two keys. If a replacement key is required, please contact our parts department at: Parts and Accessories – 1-951-735-1237 Audible Warning Device Federal Motor Vehicle Safety Standard 141 mandates that Hybrid and Electric vehicles provide an audible alert to increase awareness by a pedestrian of a vehicle’s presence. -
Page 8: Operator Safety
Operator Safety • Operators and passengers must always wear a seatbelt when operating this vehicle. • Read, understand and follow all instructions and procedures in this manual. • Never exceed the maximum passenger capacity of your vehicle For standard pickups maximum capacity is – 2, crew cab pickup – 4, cargo van –... -
Page 9: Main Electrical Disconnect
Main Electrical Disconnect Before servicing the vehicle, a safety cut-off switch is located underneath the driver’s side front seat. To access, unclip the two latches located at the front of seat as shown in picture below on left, and swing seat rearward. The electrical cut-off switch has a large red button which is pushed to disconnect the main traction battery pack. -
Page 10: Features And Controls
Features and Controls 1 – Instrument Cluster 2 – HVAC Vent 3 – Hazard Switch Entertainment System 5 – Key Switch 6 – HVAC Temperature Control 7 – Air Conditioning Switch (if equipped) 8 – Recirculating Air Switch 9 – HVAC Fan Speed Switch 10 –... -
Page 11: Diagnostic System
Features and Controls 11 – Headlight Height Adjustment Switch (only LIV9DR) 12 – Diagnostic Switch 13 – Front Fog light Switch 14 – Rear Fog Light Switch 15 – Forward – Reverse Switch 16 – Multi-Function Stalk 17 – Hood Release 18 –... -
Page 12: Instrument Cluster
Instrument Cluster 24 23 19 – Diagnostic Message Area 20 – High Beam Indicator 21 – Odometer 22 – Regen – Charge Indicator 23 – Speedometer 24 – State of Charge Indicator 25 – Turn Signal Indicator 26 – System Fault Message Area 27 –... -
Page 13: Key Switch
Key Switch Key rotated fully CCW – Lock Position, power circuits are switched off. The key can be removed. The steering column locks in place. Key rotated CW into first detent -Accessory position, all accessory equipment, such as entertainment system are powered on. Key rotated fully CW into second detent –... -
Page 14: Multi-Function Stalk
Multi-Function Stalk Rotating the end of the stalk CCW, to the first detent turns on parking lights Rotating the end of the stalk CCW to the second detent turn on the headlights Rotating the end of the stalk CW fully, turns off all exterior lights Moving the end of the stalk up and down activates the turn signal Pushing the end of the stalk away from the driver activates the high beams, pulling it back cancels the high beams... -
Page 15: Seatbelts
Seatbelts Both the driver’s seat and the front passenger’s seat are equipped with a 3-point safety belt and shoulder harness. Pull out the belt and stretch it over your body, and then insert the belt latch into the buckles until a “click” is heard. Then, the belt is locked. -
Page 16: Right Side Control Stalk, Interior Lighting Control
Right Side Control Stalk The control stalk on the right side of the steering wheel is used for controlling the windshield wipers and washers. To operate the windshield wiper, rotate the stalk CW from the off position for turning the wipers on, and setting the speed from intermediate to Hi. To activate the windshield washer, pull the end of the stalk towards the driver and release to cancel. -
Page 17: Forward Reverse Switch
Forward Reverse Switch The forward/reverse switch is located to the left of the steering wheel. Depress the brake pedal then select drive direction by pressing shift switch to the desired position. Once a direction is selected, the vehicle will begin to slowly move in that direction. -
Page 18: Hvac Controls
Mode HVAC Controls Control Air Conditioning (if equipped) Temperature Control Recirculating Air Switch Fan Speed The center knob controls the 4 fan speeds. If your vehicle is equipped with air conditioning, pressing the button to the left will turn the cooling function on and off. The output temperature of the unit is controlled by the left side knob, blue for cold, and red for hot air. -
Page 19: Door Lock And Window Switches
Door Lock and Window Switches Door Lock Knob Window Switches Your vehicle is equipped with power windows and locks. To activate windows, pull window switch up, to lower, push window switches down. Door locks are unlocked by pulling up door lock knob on top of door, locked by depressing knob. Both door locks are tied into this switch. -
Page 20: Infotainment System
Infotainment System Power Home Screen And rear Home Camera Display Back Screen Volume Up Volume Down To use the system, a series of controls is located on the left side of the display, as shown above. To access specific functions, utilize the provided touchscreen. -
Page 21: Seat Adjustment
Seat Adjustment To adjust seat fore and aft movement, pull up on lever at base, lift the control lever in front of the driver’s seat cushion and move the seat fore and aft along the tracks. Release the control lever at the required position and the track locks in place. -
Page 22: Parking Brake Lever
Parking Brake Lever The parking brake lever is located in between the driver and passenger seat. Pull up the handle until it is tight whenever parking the vehicle. Release the brake by pulling up on the handle slightly and pressing the button on the end. You can then release the brake by lowering the handle. -
Page 23: Operating Your Vehicle
Operating Your Vehicle • Make sure battery pack is charged • Check the condition of the tires • Tire Air Pressure – 40 PSI for minimum rolling resistance • Check brake pedal, parking brake and accelerator pedal for proper operation •... -
Page 24: Maximizing Your Driving Range
Maximizing Your Driving Range Electric vehicle range depends on many factors, including driving style, vehicle load, terrain and accessory energy use. Temperature also plays a factor as cold decreases battery capacity. Plan your route to minimize stop and start driving and avoid hills for the maximum range. -
Page 25: Charging Your Vehicle
Charging Your Vehicle – Charge Point Location The charger port is located behind locked door on passenger side of vehicle. The charger point is designed to be used with a 20-amp charging cord. A weather resistant rubber boot fits over the plug when it is in not in use. - Page 26 Charging Your Vehicle – Lithium-Ion Battery Pack • Your vehicle is equipped with an on-board charger which is controlled automatically by the batteries’ management system • Unless vehicle is equipped with the optional battery warmer, do not charge your vehicle in weather below 32 degrees F or above 113 degrees F •...
- Page 27 Charging Your Vehicle – AGM Battery Pack • Maintain adequate ventilation during the charging process as harmful gas may build up during the charging process. At least 5 air changes per hour is required • Unless vehicle is equipped with the optional battery warmer, do not charge your vehicle in weather below 0 degrees F or above 120 degrees F •...
- Page 28 Charging Your Vehicle – Risk of Electric Shock • Your vehicle comes from the factory with a charge cable. Never use an extension cord to charge your vehicle as the use of extension cords can cause battery undercharging, lack of performance, cord overheating or fires •...
- Page 29 Charging Your Vehicle – 12V Battery • Your vehicle is equipped with 2 separate battery packs: a main AGM or Lithium-Ion battery pack for vehicle propulsion, and a separate conventional 12V battery for all other vehicle features • The 12V battery is located beneath the driver’s seat, near the main electrical disconnect •...
-
Page 30: Changing A Tire
Changing a Tire 3 - Position jack under rear axle for rear tires and 1 - Spare tire is located 2 - Jack and lug beneath the vehicle wrench located behind front wheel on pinch weld of body for front tire under hood change Hazardous situation which will result in a serious injury or death... -
Page 31: Vehicle Storage
Vehicle Storage Please follow the protocol below for storing your vehicle for more than one week Lead acid batteries should be fully charged when stored, Lithium-Ion batteries should be stored at 40-60% state of charge (SOC). Check the voltage on the auxiliary battery. With the key off, this battery should be about 12.6 volts. If it is below this voltage, charge the car with the ignition key ON for at least one hour, or until the battery is charged. -
Page 32: Towing Your Vehicle
Towing Your Vehicle Help! My Vehicle won’t run! Your vehicle has two separate electrical systems. If the 12-volt system goes dead, you will not have exterior lights, and the dash won’t come on. It also can’t turn on the drive system. Check the 12v battery under the driver’s seat. It can be “jumped”... -
Page 33: Fuses
Fuses FUSE PANELS Fuse panel locations are as follows: The extended cab truck (LIV9DX) has the fuse box located under the hood as shown below: The crew cab truck (LIV9DR), panel van (LIV9DC) and window van (LIV9DP) have the fuse box located under the left side of the dash as shown below:... -
Page 34: Specifications
Specifications Specifications - All Vehicles Max Speed (kph/mph) 40/20 Range (miles) 30+(100 Ah battery pack) 50+(163 Ah battery pack) Standard Battery 100 Ah Lithium battery Optional High Capacity Battery 163 Ah lithium battery Gross Vehicle Weight Rating (GVWR) (kg/Lbs) 1360/3000 Transmission F/N/R single speed transmission Motor... -
Page 35: Warranty
Warranty – LIV9D Series Limited Vehicle Warranty Vantage Vehicle International Inc. hereby warrants to the original purchaser of any Vantage Vehicle International Inc. LIV9D Series electric vehicle purchased through an authorized Vantage Vehicle International dealer in the continental United States will be free of defects in material and workmanship for a period of 2 years/8,000 miles (12,900 km) whichever comes first, limited warranty on all components (except batteries) of your Vantage vehicle against defects in material or workmanship. - Page 36 Warranty – LIV9D Series Lithium-Ion Battery Pack Limited Warranty For vehicles purchased after 2-1-25, battery coverage begins on the date of purchase by the original purchaser and continues for 5 years or 30,000 miles (48,300 km), whichever comes first. During this period, Vantage warrants your vehicle’s batteries against defects in materials or workmanship.
- Page 37 Warranty – LIV9D Series Remedies The sole remedy for any breach of this warranty shall be, at the discretion of Vantage Vehicle International, the repair or replacement of any defective materials, components, or products. The remedies outlined in this warranty are the only options available to any individual for a breach of this warranty.
-
Page 38: How To Obtain Warranty Service
⚠ NOTE How to Obtain Warranty Service Important information When and if your vehicle requires warranty support, you must take it to an authorized Vantage Vehicle International service dealer. A warranty registration card must be presented to the dealer prior to any servicing. The cost of transportation for the vehicle to the dealer is the responsibility of the user. -
Page 39: Scheduled Maintenance
Scheduled Maintenance Exercise care to prevent damage to your vehicle or to yourself whenever performing maintenance or inspection. We recommend that you have your Authorized Vantage dealer, or a reliable and qualified service shop perform this work. Keep all your maintenance receipts as proof the service was performed. Service Item Daily Weekly Monthly Annually... - Page 40 This page blank...
