LENCO TTA-080SI Operation Instruction Manual

English
Operation instruction to adjust the lighting effect
To adjust the microphone input's gain/sensitivity for driving the flash lighting and effects (refer to the
corresponding table for detail), follow the steps below:
1. Power On: Long press the "ON/OFF" button to power on the device;
2. Enter Gain Adjustment Mode: While the device is powered on, quickly short press the "ON/OFF" button
twice to enter [Gain Adjustment] mode;
3. Adjust Gain: In [Gain Adjustment] mode, short press the "ON/OFF" button once, or repeatedly, to adjust
the light's gain to the desired level. There are 5 gain levels (1, 2, 3, 4, and 5) available for selection;
4. Exit Gain Adjustment Mode: Once the adjustment is complete, quickly short press the "ON/OFF" button
twice to exit [Gain Adjustment] mode. Alternatively, the mode will exit automatically after 30 seconds of
inactivity.
Note:
- The corresponding light flashing are depending on the gear number (1 – 5) of gain level, higher the number
will be the higher the sensitivity = more reaction to music beats
- The default gain level of the software is set at gear 3
Mic Gain/Sensitivity Adjustment for Driving Light Effects
Corresponding table:
Gear Mode Selection
1
2
3 (Factory Default)
4
5
Low battery
⚫
When the battery voltage drops to low level, all 5 LEDs will flash 5 seconds.
⚫
When the battery voltage drops to the lowest level, all 5 LEDs will flash for 5 seconds and then the device
will power off.
Remark: this device can also be used without turntable and will light like a disco ball but will not rotate.
TTA-080SI / TTA-180TN
LED Indication
Red LED light up
Blue LED light up
White LED light up
Pink LED light up
Green LED light up
Gain/Sensitivity Level
lowest
lower
Medium sensitivity
higher
highest
