200W beam shaking light+light
strip
User's Manual
Thank you for using the products produced by our company: this
manual contains important information such as product use, installation
and maintenance methods. Please read it carefully and install and operate it
as required. At the same time, please keep this manual properly in case of
emergency. When this product leaves the factory, its performance is intact
and its packaging is complete. All users shall strictly abide by the warnings
and operating instructions stated in this manual. Any damage caused by
misuse is not covered by our company's guarantee. This manual is subject
to technical changes without prior notice.
1
Advertisement
Table of Contents
Summary of Contents for Beam YUER
- Page 1 200W beam shaking light+light strip User's Manual Thank you for using the products produced by our company: this manual contains important information such as product use, installation and maintenance methods. Please read it carefully and install and operate it as required. At the same time, please keep this manual properly in case of emergency.
-
Page 2: Product Accessories
Product accessories This user book Yes (no) Power cord (as required by the order) Yes (no) U frame Yes (no) The screw is fixed on the lamp (used Yes (no) to fix the hanger) Product characteristics operating AC100～240V，50～60Hz voltage consumed 280W power Light source... -
Page 3: Safety Warning Information
Safety warning information 1. Before using it for the first time, please unpack it and check whether it is damaged due to transportation. In case of damage caused by transportation, please do not use this lamp and contact our company as soon as possible. - Page 4 10. There are no user-maintained parts in this lamp. Before starting to operate the lamps, please check whether all the shells have been installed and whether the screws have been tightened reliably. It is forbidden to use lamps with the shell open. Note: Please make sure that the power cord has been cut off before any installation, maintenance and cleaning of lamps! Connection of DMX control signal...
-
Page 5: Display Panel
environment where electrical appliances are noisy, such as dance halls. This can avoid the turbidity of digital control signal caused by electrical noise. The DMX terminator consists of a simple XLR connector with 2 cores and 3 cores connected with a resistor of 120. Please plug the terminator into the XLR output port of the last product, please refer to the following figure. - Page 6 Display screen function set up Parameter setting manual Manual setting system State monitoring, display senior Advanced parameter configuration Main page Chinese-English switching Switch between Chinese and English Inverted display/forward Forward/reverse display of display display switching screen reset Device reset Operation effect SH0-SH5(SH0 random effect) operational mode DMX, automatic, voice control...
- Page 7 X fine tuning Y fine tuning XY speed aiming stroboscopic Color wheel Pattern disk Prism, rotating focus Self-propelled/voice control reset Lamp strip Speed of light strip System error record error logging LED temperature Temperature display version number version number senior Enter password Up, down, up and down.
- Page 8 DMX channel control content [DMX1] Detailed description of 15-channel mode, receiving DMX512 international standard signal. passage numerical functional description value 000-255 The horizontal shaft runs 0-540 degrees. X axis X-axis fine 000-255 Horizontal fine-tuning fretting tuning 000-255 The vertical axis runs 0-200 degrees. three Y axis Y axis fine...
- Page 9 000-029 1-11 channels are valid. 030-059 Self-propelled mode 1 060-089 Self-propelled mode 2 090-119 Self-propelled mode 3 Self- propelled/voi 120-149 Self-propelled mode 4 ce control 150-179 Voice control mode 1 180-209 Voice control mode 2 210-239 Voice control mode 3 240-255 Voice control mode 4 000-020...
- Page 10 198-255 The color wheel is reversed and the speed is slow to fast. 000-005 Circular white light 006-071 Patterns 1-11 072-143 Pattern 11-1 dithers, and the speed changes seve from slow to fast. pattern 144-199 The pattern rotates forward, and the speed is from fast to slow.
-
Page 11: General Troubleshooting
General troubleshooting Lamps can't start normally. 1. Check the power cord for problems. 2. Check whether the power fuse is blown. 3. Check whether the switching power supply of lamps and lanterns has voltage output (multimeter) 4. Check the motherboard for voltage input (multimeter) Lamps and lanterns can emit 1.
