GRB Series PTC Temperature control module
1.SUMMARIZATION
The GRB series PTC Temperature control module is specially designed for
being used with MZ6 PTC Thermistors, if the electric motor ( or some place on the
electric motor)is overheating, the resistance of PTC Thermistors will rise, and can be
passed to the protection apparatus, the relay contact inside the protection apparatus
transforms to push the control circuit(electromagnetic switch etc) to switch off the
main power source, and further to protect the elector motor.
2.TECHNICAL PARAMETER
1)
Operating voltage：AC 220V;
2)
Allowable volt tolerance：±20%;
3)
Frequency：50～60Hz;
4)
Self-consuming power：<0.8VA;
5)
Allowable environment temperature：-30～70℃;
6)
Rated current of switch：7A;
7)
Operating resistance：3KΩ×（1±10%）;
8)
Restoring resistance：1500～1800Ω;
Weight：0.2Kg.
9)
3、PARAMETER CONNECTION DIAGRAM
SEVA-tec GmbH - Lether Gewerbestrasse 10 - 26197 Ahlhorn
Operation manual
1
Advertisement
Summary of Contents for Seva-tec GRB Series
- Page 1 GRB Series PTC Temperature control module 1.SUMMARIZATION The GRB series PTC Temperature control module is specially designed for being used with MZ6 PTC Thermistors, if the electric motor ( or some place on the electric motor)is overheating, the resistance of PTC Thermistors will rise, and can be...
- Page 2 2) Install the protector in the equipment’s control cabinet, avoid the fire and the rain. 3) The GRB-2 type electric motor overheated protection apparatus’s base is equipped with the slot, fix one side of the base slot of protector on one side of the SEVA-tec GmbH - Lether Gewerbestrasse 10 - 26197 Ahlhorn...
- Page 3 T1,T2 ends to PTC thermistor. Connect 14 end to the power source. 13 end should be connected to the electric motor’s start switch. 21 end should be connected to the failure indication instrument or the failure warning device. SEVA-tec GmbH - Lether Gewerbestrasse 10 - 26197 Ahlhorn...
- Page 4 2) In the course of installation, Product should be far away from the fire, In order to avoid the product reach to the high temperature and cause the product’s primary SEVA-tec GmbH - Lether Gewerbestrasse 10 - 26197 Ahlhorn...
- Page 5 When the electric motor’s red signal light is shining, the green signal light goes out. 10) Do not open the products and change the inside elements. SEVA-tec GmbH - Lether Gewerbestrasse 10 - 26197 Ahlhorn...
