  • Page 1 EBOX-EHL Series Fanless Box PC User’s Guide...

  • Page 2: Trademarks Acknowledgment

    No part of this manual may be reproduced, copied, translated or transmitted, in whole, in part, or in any form or by any means without the prior written permission of the ICOP Technology Inc. ©Copyright 2024 ICOP Technology Inc.

  • Page 3: Table Of Contents

    EBOX-EHL Series User Manual Contents Chapter 1 1.1 Unpacking EBOX PC……………………….……………………………………………………05 1.2 Preface………………………………………………….………………………………………………06 Chapter 2 2.1 External I/O….…………………….………………………….……….………………………………08 2.2 Specifications…………………………………………….………….……………………………….09 2.3 IO Explanation…………………….………………………………….……………………………….10 2.4 Appearance Diagram……………...…………………………….……………………………………12 2.5 Mounting instruction......………………………….……………………………………13 Chapter 3 3.1 Installing RAM Modules...........…………………….………………………….15 3.2 Installing the WLAN/BT (2230) Module.…………………………………………….………………….16 3.3 Installing the M.2 M-key (2260/2280) Storage……………..…………….…………………………17...
  • Page 4 EBOX-EHL Series User Manual Chapter ICOP Technology Inc.

  • Page 5: Chapter 1 1.1 Unpacking Ebox Pc

    1.1 Unpacking EBOX Fanless Box PC Component List: Item No. Description Quantity EBOX-EHL Series Fanless Box PC Power Adaptor 40W; Vin: 100~240V AC 50~60Hz (Optional) Power cord US/UK/EU/AU types (Optional) VESA Rack (Optional) Note: The accessories are subject to change without immediate notice.

  • Page 6: Preface

    EBOX-EHL Series User Manual 1.2 Preface EBOX-EHL Series Fanless Box PC High-Performance Processing: Equipped with the offering Elkhart Lake J6412 quad-core performance at 2.0GHz ensures fast and efficient processing support for DDR4 3200MHz SO- DIMM memory up to 32GB. Triple Display Support: With two HDMI 2.0 ports and one DP 1.4 port, each capable of delivering stunning 4K resolution at 60Hz.
  • Page 7 EBOX-EHL Series User Manual Chapter ICOP Technology Inc.

  • Page 8: External I/O

    EBOX-EHL Series User Manual 2.1 External I/O Front IO Rear I/O ICOP Technology Inc.

  • Page 9: Specifications

    EBOX-EHL Series User Manual 2.2 Specifications EBOX-EHL Series Processor Intel® Elkhart Lake J6412 Processor (Quad core 2.0GHz) System RAM DDR4 3200MHz SO-DIMM, memory up to 32GB BIOS AMI BIOS Disk Support M.2 M-key x1 (2260/2280), PCIe Gen.3 x2/SATA interface support NVMe SSD Expansion M.2 E-key x1 (2230), USB2.0/PCIe x1 interface (CNVi supported) WLAN/BT...

  • Page 10: Io Explanation

    EBOX-EHL Series User Manual 2.3 IO Explanation Front A: D-Sub 9-pin connector (COM1: RS232/485/422) Connection for RS232/485/422 applications. B: D-Sub 9-pin connector (GPIO) Connection for 8-bit GPIO applications. C: USB 3.1 (Gen.2) Type-C (No Display function) Connection for external USB devices, maximum data transfer rate up to 10Gbps.
  • Page 11 EBOX-EHL Series User Manual Rear H: DC power Jack DC +12V Input power is used for the power source. I: HDMI 2.0b Connector x2 Connecting 4K HDMI display via HDMI 2.0b cable J: Display port 1.4 (DP 1.4) Connector Connect display port via display port 1.4 cable.

  • Page 12: Appearance Diagram

    EBOX-EHL Series User Manual 2.4 Appearance Diagram ICOP Technology Inc.

  • Page 13: Mounting Instruction

    EBOX-EHL Series User Manual 2.5 Mounting instruction The optional VESA Rack allow EBOX can be Wall-mount and VESA-mount supported. 2.5.1 Wall-mount installation 1. Secure the convex surface rack to the EBOX bottom. 2. Utilize the round head screws included in the accessory package to fasten the rack, then, EBOX can be mounted to the wall with the rack.
  • Page 14 EBOX-EHL Series User Manual Chapter ICOP Technology Inc.

  • Page 15: Installing Ram Modules

    EBOX-EHL Series User Manual 3.1 Installing RAM module 3.1.1 Remove the front and rear I/O panel screws. 3.1.2 Remove foot pad screws from the bottom. 3.1.3 Hold the DDR4 SO-DIMM memory module by its edge and slide it into the memory module slot, slightly press the SO-DIMM module down until a click sound securing the module in place.

  • Page 16: Installing The Wlan/Bt (2230) Module

    EBOX-EHL Series User Manual 3.2 Installing the WLAN/BT Module 3.2.1 Remove the front and rear I/O panel screws. 3.2.2 Remove foot pad screws from the bottom. 3.2.3 Remove the default screw marked as below and slide the M.2 WLAN/BT module into the M.2 2230 PCIe slot.

  • Page 17: Installing The M.2 M-Key (2260/2280) Storage

    EBOX-EHL Series User Manual 3.3 Installing the M.2 M-key (2260/2280) Storage 3.3.1 Remove the front and rear I/O panel screws. 3.3.2 Remove foot pad screws from the bottom. 3.3.3 Remove the default screw marked as below and slide the M.2 2280 SSD into the M.2 PCIe/SATA slot.
  • Page 18 EBOX-EHL Series User Manual Chapter ICOP Technology Inc.

  • Page 19: Bios Reconfiguring

    EBOX-EHL Series User Manual 4. BIOS Reconfiguring 4.1.1 Load Default Setting 1. To reconfigure the hardware, press <Delete> during boot up to enter BIOS menu. 2. Press <F3= key to load optimized defaults as below: 3. After setting, press <F4= key to save & exit.
  • Page 20 EBOX-EHL Series User Manual 4.1.2 Hot key Press <F7> after boot up, a select menu will appear. Use direction key to select boot device. ICOP Technology Inc.

  • Page 21: Bios Com Setting

    EBOX-EHL Series User Manual 4.2 BIOS COM Setting (RS232/485/422) 1. Press <Del> during boot up, enter BIOS menu, move to <Advanced= for <Super IO Configuration=. 2. Move to <Serial Port 1 Configuration=. ICOP Technology Inc.
  • Page 22 EBOX-EHL Series User Manual 3. Next to Transmission Mode and select COM port Mode. 4. Press <F4= key to save & exit. ICOP Technology Inc.

  • Page 23: At Mode Setting

    EBOX-EHL Series User Manual 4.3 AT Mode Setting (Auto Power On Function) EBOX-EHL Series supports <Auto Power On function=, it’s a function allows system to boot up automatically after power restored. 1. In BIOS Menu, move to <Chipset= and <PCH-IO Configuration=.

  • Page 24: Serial Port Console Redirection

    EBOX-EHL Series User Manual 4.4 Serial Port Console Redirection 1. Move to <Advanced= and <Serial Port Console Redirection= set <Console Redirection= as <Enabled=. 2. Set <Terminal Type= as <VT100+=, press <F4= key to save & exit. Terminal Type Emulation: [ANSI]: Extended ASCII char set;...

  • Page 25: Watchdog Setting

    EBOX-EHL Series User Manual 4.5 Watchdog Setting 1. Move to <Advanced= for <Super IO Configuration=, set <Watchdog reset timer= [Enabled]. 2. After Watch Dog Timer setting completed, press F4 to save and exit. ICOP Technology Inc.

  • Page 26: Pxe Diskless Boot Selection

    EBOX-EHL Series User Manual 4.6 PXE diskless boot Selection 1. Move to <Advanced= for <Network Stack Configuration= and make further setting. 2. Set <Network Stack= Enabled and Ipv4 & Ipv6 PXE Support will appear. Note: Ipv4 & Ipv6 stand for Internet Protocol version 4 & 6, when Network Stack set to Enabled, PXE diskless boot will be created.
  • Page 27 EBOX-EHL Series User Manual Chapter ICOP Technology Inc.

  • Page 28: Chipset Driver

    EBOX-EHL Series User Manual 5. Drivers Installation guide Under Windows 10, the following drivers need to be installed manually. 1. Chipset 2. Graphic 3. Audio 4. LAN 5. IME Please download above drivers from EBOX website. 5.1 Chipset driver: (Intel® Chipset Device Software) 1.

  • Page 29: Graphic Driver

    EBOX-EHL Series User Manual 5.2 Graphic driver: 1. Execute installer.exe and click <Begin installation= to install: 2. A license agreement message will pop out, click Start to install. 3. After installed, click Finish to complete. ICOP Technology Inc.

  • Page 30: Audio Driver

    EBOX-EHL Series User Manual 5.3 Audio driver: 1. Execute Setup.exe and installer will pop out, then click <Next= to install: 2. After installed, select <Yes, I want to restart this computer now= and click Finish to reboot. ICOP Technology Inc.

  • Page 31: Lan Driver

    EBOX-EHL Series User Manual 5.4 LAN driver: 1. Execute Setup.exe and installer will pop out, then click <Install Drivers and Software=. 2. Click <Next=, accept the terms and confirm setup options to install. 3. After installed, click <Finish= to exit the installer.

  • Page 32: Ime Driver

    EBOX-EHL Series User Manual ® 5.5 IME driver: (Intel Management Engine Components) ® The Intel Management Engine (ME), also known as the Intel Manageability Engine, is an autonomous subsystem that has been incorporated in virtually all of Intel's processor chipsets.
  • Page 33 EBOX-EHL Series User Manual Chapter ICOP Technology Inc.

  • Page 34: Internal I/O

    EBOX-EHL Series User Manual 6.1 Internal I/O Front IO Rear I/O ICOP Technology Inc.

  • Page 35: Onboard Connectors Summary

    EBOX-EHL Series User Manual 6.2 Onboard Connectors Summary Summary Table for main Board Description Type of Connections Pin # DDR4 3,200MHz SO-DIMM SO-DIMM slot 260-pin Power DC Jack External DC Jack connector 2-pin USB3.1 (Gen.2) Type-C x2 External USB3.1 Type-C connector 24-pin USB3.1 (Gen.2) Type-A x2...

  • Page 36: Pin Assignments

    EBOX-EHL Series User Manual 6.3 Pin Assignments DC Power Input Pin # Signal Name DC +12V power Adapter Input HDMI 2.0 Pin # Signal Name Pin # Signal Name TMDS_Data2+ TMDS CLK Shield TMDS_Data2_Shield TMDS_CLK- TMDS_Data2- TMDS_Data1+ Reserved TMDS_Data1_Shield TMDS_Data1-...
  • Page 37 EBOX-EHL Series User Manual LAN: RJ45 connector Pin # Signal Name Pin # Signal Name TP0+ TP2- TP0- TP1- TP1+ TP3+ TP2+ TP3- USB 3.1 Type-C connector Pin # Signal Name Pin # Signal Name Pin # Signal Name VBUS...
  • Page 38 EBOX-EHL Series User Manual RS232/485/422 9-pin D-Sub connector Pin # Signal Name Pin # Signal Name DCD/RS422 TX-/RS485 DATA- DSR1 RXD/RS422 TX+/RS485 DATA+ RTS1 TXD1/RS422 RX+ CTS1 DTR1/RS422 RX- GPIO 9-pin D-Sub connector Pin # Signal Name Pin # Signal Name...
  • Page 39 EBOX-EHL Series User Manual Chapter ICOP Technology Inc.

  • Page 40: Storing

    EBOX-EHL Series User Manual 7. Taking Care of EBOX This section provides guidelines on using EBOX-EHL Series – Safe using, Storing and Handling. 7.1 Storing Do not place EBOX in a location that is subject to: ⚫ Heating sources, such as stove, oven, heater, radiator or air duct ⚫...

  • Page 41: Troubleshooting

    EBOX-EHL Series User Manual 7.3 Troubleshooting This section describes the techniques of resolving some basic problems that you encounter when using EBOX. For more troubleshooting guidelines, please contact your nearest dealer for technical support. Troubleshooting EBOX A. EBOX does not start –...
  • Page 42 EBOX-EHL Series User Manual C. <Operating System Not Found= – A message indicating <Operating system not found= appear when unit starts (Windows won’t start) Enter BIOS setup main menu by pressing <DEL> key, be sure that the C: drive is enabled.
  • Page 43 EBOX-EHL Series User Manual Chapter ICOP Technology Inc.

  • Page 44: Terms And Conditions

    Technology Inc. The technical support service does not offer software tutoring or training. Return Merchandise Authorization (RMA) policy If the ICOP staff or dealer determines that a part is defective. Purchaser must call our technical support and obtain an RMA number before attempting to return any part.
