  • Page 1 Solo-1 PCI - SOUND CARD Configuration and Hardware USER MANUAL July 1998...

  • Page 2: Table Of Contents

    Solo-1 PCI Sound Card Configuration/Hardware TABLE OF CONTENTS 1. DESCRIPTION................0 1.1. F ..........................0 EATURES 1.2. C ........................0 IGURE 1.3. C ........................0 ONNECTORS 1.3.1. External Connectors:....................0 1.3.2. Internal Connectors:..................... 0 1.3.3. Audio Connectors:......................0 1.3.4. Audio Output Jumper Settings for JP1:.................0 2.

  • Page 3: Description

    Configuration/Hardware 2.DESCRIPTION This is a new audio adapter (single chip solution Solo-1ä) that provides the next generation of PCI audio performance to the PC market. The adapter not only meets the new demands of advanced PC audio applications but also enables the integration of a complete multimedia subsystem on a single adapter.

  • Page 4: Card Figure

    Solo-1 PCI Sound Card Configuration/Hardware 2.2. Card Figure 2.3. Connectors This PCI Sound Card includes up to ten internal connectors, four external Jack Ports, and one external MIDI/ Joystick connector. 2.3.1....External Connectors: J1:......f 3.5mm Phone Jack for LINE IN. J2:......f 3.5mm Phone Jack for MIC IN.
  • Page 5 Solo-1 PCI Sound Card Configuration/Hardware Page - 5...

  • Page 6: Audio Connectors

    Solo-1 PCI Sound Card Configuration/Hardware 2.3.3.......Audio Connectors: 2.3.4. Audio Output Jumper Settings for JP1: Audio Settting SPEAKER OUT with Power Amplifier (Default) LINE OUT without Power Amplifier 3..HARDWARE INSTALLATION 3.1. Handling the PCI Sound Card WARNING: Static electricity can damage your equipment. Do not take the card out of its static protective bag until you are ready to work with it.

  • Page 7: Installing The Pci Sound Card

    Solo-1 PCI Sound Card Configuration/Hardware 3.2. Installing the PCI Sound Card Step 1. Turn off the system and all peripheral devices. Step 2. Disconnect the power cord and all peripheral devices from the system. Step 3. Remove the system cover and identify an unused PCI slot.

  • Page 8: Nstalling The Device Driver For The First Time Under Windows

    Solo-1 PCI Sound Card Configuration/Hardware 4.3. Installing the Device Driver for the first time under Windows 95 OSR2 To install the device driver under Windows_ 95 OSR2, please follow the steps below: After you have installed the PCI Sound Card, restart your Microsoft_ Windows_ 95 OSR2 operating system.

  • Page 9: How To Play Games Under Dos Mode

    Solo-1 PCI Sound Card Configuration/Hardware 4.4. How to Play Games Under DOS Mode If you want to play games under the DOS mode, please specify your drive letter first. Assuming drive C is used please add the following line to your CONFIG.SYS file: DEVICE=C:\ESSOLO.SYS...
