- Page 1 OPERATIONS & MAINTENANCE MANUAL EWON GATEWAY Document Reference: A7674-ED Document Revision Issue Description Date Approver Level Initial Issue 27/01/25...
-
Page 2: Table Of Contents
Contents Introduction ........................2 1.1. Prerequisite ..........................2 1.2. Storage ............................2 1.3. Disposal / Scrappage ........................2 Safety Precautions ......................3 2.1. Danger, Warning and Caution key ..................... 3 Overview ..........................4 3.1. Front View ..........................4 3.2. -
Page 3: Introduction
When not in use the unit should be stored in a dry and clean environment, preferably between 5-25°C. 1.3. Disposal / Scrappage Please consider the environment when disposing of all parts, especially waste oil. If in doubt contact DME for further advice. HMS EWON GATEWAY A7674-ED. Revision 0 Page 2... -
Page 4: Safety Precautions
2. Safety Precautions See DME Safety Manual A1678-ED. It’s essential this is read and understood before operating the system. 2.1. Danger, Warning and Caution key DANGER: Indicates a hazard with a HIGH level of risk. Potential for serious injury or death if hazard was to... -
Page 5: Overview
3. Overview 3.1. Front View Number Description Reset button Status LED’s LAN & WAN Ethernet Ports Orange: WAN Port Green: LAN Port USB Slot SD Card Slot 3.1.1. Reset Button To reset the unit back to factory settings, do the following: 1) If the unit is powered, turn off the power. - Page 6 3.1.2. Status LED Label Description Solid Green when Reset button is pressed Solid Green when the unit is powered Flashing Green – Unit if Healthy Orange Pattern – USB/SD Configuration Red Pattern – Attention Required Solid Green - Digital input 1 enabled...
-
Page 7: Top View
3.1.4. USB If using a USB drive it must be formatted to FAT32. 3.2. Top View 3.2.1. Connector Number Description Output Signal 0V Output (Switched) Output Signal Supply 24VDC Input 0V Input signal 1 Input signal 2 HMS EWON GATEWAY A7674-ED. - Page 8 Unit Supply 24VDC Unit Supply 0VDC Unit Earth 3.2.2. Digital Output & Input HMS EWON GATEWAY A7674-ED. Revision 0 Page 7...
-
Page 9: Configure A Replacement
4. Configure a Replacement 4.1. Update the firmware 1) Copy the firmware file to SD card or USB drive and rename the file to Ewon.upkg 2) Power off the unit and insert the SD card or USB drive. 3) Power on the unit, after approximately 15 seconds the “USR” LED will start flashing orange. -
Page 10: Backup
6. Backup 6.1. Using Software 1) Connect your laptop/PC to the unit on the LAN port 1. 2) Open the “eBuddy” software. 3) From the toolbar, select [Backup/Restore]. 5) Don’t select [Include Support Files] 6) Save the backup in an appropriate place on your Laptop/PC 6.2. -
Page 11: Fault Finding
3) From the toolbar, select [Backup/Restore]. 4) Select [Backup] and [Include Support Files], and press [Next] 5) Enter the credentials and press [Next] 6) Choose an appropriate location to save the files. 7) Send the backup file to DME 7.2. LED Status Issue... -
Page 12: No Wan Connection
HMS. Solid Green Flashing This generally indicates a file Try to restore the configuration. Orange not loading correctly during power up. Solid Green None This generally indicates a Try a reset / restore and reflash the normal fault and its possible firmware. - Page 13 7) Press [Finish] to complete the process. 8) If there is a connection issue there are a few things to check: a. Local firewall settings, they should allow: i. Required: *.Talk2m.com:443 (TCP protocol) ii. Recommended: *.Talk2m.com:443 (TCP protocol) and *Talk2m.com:1194 (UDP protocol) b.
-
Page 14: Training
8. Training DME offer training courses to help ensure operators are competent in the use and maintenance of offshore equipment; these can be bespoke to suit the intended audience. Contact us for more information. HMS EWON GATEWAY A7674-ED. Revision 0... -
Page 15: Service & Spare Parts
9. Service & Spare Parts A separate recommended Spares List is provided within the equipment BOM. Ensure DME part number is clearly identified in all correspondence. For spares enquiries please contact Sales@DME-Systems.com or via our website www.dme-systems.com. DME Contact Details For queries or additional information not provided within these manuals please contact us directly as noted below.
