FB-BPC WIRELESS PROBE & CHARGER HUB USER GUIDE

OVERVIEW

The Flame Boss Charger Hub is a device that reads temperature from Flame Boss Wireless Meat Probes and outputs a

temperature sensor signal to your connected device. Plus, it charges the probes so you're always ready to cook! It offers

two-way communication, meaning you can control it and get notifications without hassle. You can also adjust various

settings for convenience, power, and range to suit your needs. This is a guide for easy set-up, use, maintenance, and

troubleshooting.

Figure 1: Interfacing with other devices

Figure 2

PAGE 1

Need help?

Do you have a question about the Charger Hub and is the answer not in the manual?

Page 1 OVERVIEW The Flame Boss Charger Hub is a device that reads temperature from Flame Boss Wireless Meat Probes and outputs a temperature sensor signal to your connected device. Plus, it charges the probes so you’re always ready to cook! It offers two-way communication, meaning you can control it and get notifications without hassle.
Page 2 Figure 4: Probe charging position CONNECTING TO YOUR CONTROLLER Connect the Charger Hub to your Flame Boss device or other controller that uses PT1000 RTD wired probes and 3.5mm plugs) using the included adapter cable. Make the connection from the desired probe port on the Hub to the desired meat probe input on your controller.
Page 3 FB-BPC WIRELESS PROBE & CHARGER HUB USER GUIDE If a probe stops transmitting temperature (due to charge depleted, out of wireless range, charging or damaged probe), the adapter output will correspond to the last probe transmission for up to 2.5 minutes. After this it will register an invalid output, and the channel LED will be OFF.
Page 4 FB-BPC WIRELESS PROBE & CHARGER HUB USER GUIDE Mounting flange For screw or hook mounting USB-C input/charging port Charge the non-removable lithium ion/polymer battery Power button Quick release ~1s = OFF -> ON or ON -> restart; long press 2-3s = ON -> OFF...
