Manufacturer information:
WEBER Prüftechnik
Owner: Torsten Weber
Arneburger Straße 121
39590 Tangermünde
Germany
Phone:
+49 (0) 39322 – 717011
Email:
info@weber-prueftechnik.de
Internet:
https://www.light-weight-deflectometer.eu/
Version: 07-EN
Status: May 2020
© 2020 WEBER Prüftechnik
________________________________________________________________________
Page 1 / 36
Manual LWD WEBERconnect
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Weber LWD Weber Connect
Summary of Contents for Weber LWD Weber Connect
- Page 1 Manufacturer information: WEBER Prüftechnik Owner: Torsten Weber Arneburger Straße 121 39590 Tangermünde Germany Phone: +49 (0) 39322 – 717011 Email: info@weber-prueftechnik.de Internet: https://www.light-weight-deflectometer.eu/ Version: 07-EN Status: May 2020 © 2020 WEBER Prüftechnik ________________________________________________________________________ Page 1 / 36 Manual LWD WEBERconnect...
-
Page 2: Table Of Contents
Contents General ......................... 4 Introduction ......................4 Applicable Product Documents ................4 Used Terms ......................4 Liability Limitations ....................4 Copyright ....................... 4 Customer Service ....................5 Safety ........................6 Requirements on the Personnel ................6 Proper Use ......................7 Requirement for the operating site ................. - Page 3 Deleting the last test: ................... 26 Labelling of test data: ..................26 Show tests ......................27 Execution of test ....................28 Evaluation by Handheld ..................30 Interpretation of resuluts ..................30 Display and storing of resoluts ................30 Data transfer to PC-Software ................31 Transport ......................
-
Page 4: General
All data and notes in the operating manual were prepared with consideration to the appli- cable standards and regulations as well as the state-of-the-art engineering. The company Weber Prüftechnik does not assume any liability for damages and malfunc- tions due to the following circumstances: ... -
Page 5: Customer Service
Customer Service WEBER Prüftechnik Owner: Torsten Weber Arneburger Straße 121 39590 Tangermünde Germany Phone: +49 (0) 39322 – 717011 Email: info@weber-prueftechnik.de Internet: https://www.light-weight-deflectometer.eu/ ________________________________________________________________________ Page 5 / 36 Manual LWD WEBERconnect... -
Page 6: Safety
2 Safety Requirements on the Personnel The Light Weight Deflectometer LWD WEBERconnect may only be operated by qualified staff. This operating manual defines qualified personnel as someone who passed a specific training, possesses knowledge and experience and who is also familiar with the relevant regulations that enables the person ... -
Page 7: Proper Use
Proper Use The Light Weight Deflectometer LWD WEBERconnect was developed in accordince to the German test regulation TP BF-StB Part B 8.3 as well as the American standard ASTM E2835-11, to test the soil bearing capacity and the achieved degree of soil compaction in the area of soil construction, traffic route engineering or railway construction by means of a dynamic plate pressure test. -
Page 8: Warnings
Warnings In this manual, all warnings are particularly highlighted compared to the remaining text. The warnings are marked in colours and introduced by a signal word that indicates the degree of danger. An icon specifies the kind of danger. All warnings have to be followed strictly to carry out an accident-free work and to avoid injuries and damages. -
Page 9: General Safety
Only this switched power supply meets the requirements for power sources of limited power (LPS). A replacement switched power adapter can be purchased as an original spare part from the device manufacturer WEBER Prueftechnik. The internal battery inside of the load plate may only be recharged via the charging socket on the handheld otherwise not a safe operation is guaran-teed. -
Page 10: Design And Function
3 Design and Function Overview IIu. 1 Overview 1 Loading Mechanism 2 Handheld 3 Load Plate 4 Switched power supply (not available in Picture) 5 connection cable (not available in Picture) ________________________________________________________________________ Page 10 / 36 Manual LWD WEBERconnect... -
Page 11: Load Plate
Inside the equipment, there are special batteries. Improper replacement of these batteries may cause a risk of explosion! The battery inside the load plate may not be replaced by self! Its replacement and disposal may only be carried out by the manufacturer WEBER Prueftechnik or his authorized service partners. ________________________________________________________________________... -
Page 12: Loading Mechanism
Loading mechanism The loading mechanism serves to apply a defined force on the load plate. It controls also the application time oft he load by means of a spring package. The loading mechanism consists of: Guide rod Falling weight ... -
Page 13: Handheld
Inside the equipment, there are special batteries. Improper replacement of these bat- teries may cause a risk of explosion! The battery inside the handheld may not be replaced by self! Its replacement and disposal may only be carried out by the manufacturer WEBER Prueftechnik or his authorized service partners. ________________________________________________________________________... -
Page 14: Display Touchscreen
3.4.1 Display Touchscreen IIu. 2 start screen Handheld 1 Charge and battery status display 2 Date 3 Time 4 Signal strength to the load plate ________________________________________________________________________ Page 14 / 36 Manual LWD WEBERconnect... -
Page 15: Menu Item Measurement
3.4.2 Menu item Measurement After activation of the menu „Measurement“, the display will change into check mode. Depending of the setting parameters the handheld will guide the examiner automatically through the individual check steps. IIu. 3 Menu item Measurement 3.4.3 Menu item History After activation of the menu „History“, all memorized tests can be displayed in series IIu. -
Page 16: Menu Item Settings
3.4.4 Menu item Settings After activation of the menu „Settings“, a submenu will appear with the following sub items: Display Measurement settings Settings load plate Device info Menu „Display“ The menu „Display“ permits the selection of ditterent languages. The date as well as the clock settings can be adjusted in this menu. - Page 17 Menu “Measurement settings” The memory location can be selected in the menu „Measurement settings“. The results of the test can be saved onto a SD-card or into the internal memory. The SD-card is located in the card slot left-hand side of the handheld. Applying a soft push on the SD-card is enough, to insert or to eject the medium.
- Page 18 Menu “Setting Load Plate” Four items are available in the menu „Settings Load Plate“: Pairing, calibration, charging mode and system information. The handheld can only be used as display instrument. It is exchangeable between all LWD WEBERconnect testers. The handheld can be connected with any ground sensor / load plate of a LWD WEBERconnect device.
-
Page 19: Function
Function When carrying out a dynamic load plate test with the Light Weight Deflectometer LWD WEBERconnect the load plate will be charged impulsively with a light falling weight by using a defined force. The acceleration, deflection (s) and speed (v) of the load plate depends on the ground that has to be tested. -
Page 20: Commissioning
4 Commissioning Charging the battery For charging the battery of the handheld and the load plate a switched power supply with different globally used adapters as well as a connection cable is included. IIu. 8 Charging the battery 1 connection cable Load Plate - Handheld 2 load plate 3 charging output socket (connection cable) 4 charging input socket (power cord) - Page 21 1. Connect the switched power supply (5) with the proper adapter to your AC power supply network 2. Connect the power cord to the handheld’s charging socket (4), left-hand side (outer) 3. Plug in the connection cable (1) into the right charging socket (3) of the handheld 4.
-
Page 22: Operation
5 Operation Activate Handheld The LWD WEBERconnect can be full operated by the touchscreen of the handheld. Press the ON/OFF button of the handheld Load plate and handheld will connect automatically Start screen appears HINT The maximum distance for the wireless data transmission is aprox. 10 Conducting a measurement The default setting of the LWD WEBERconnect requires prior to any measurement a per- formance of three preload impulses. - Page 23 HINT Based on the settings of the handheld the menu will guide the user automatically through all the test steps. The single results of the three measurement impulses are displayed graphically in a table. IIu. 9 Start screen Handheld 1 Deflection (s) 2 Speed (v) 3 Ev -value...
-
Page 24: Print Out A Test
Touching the table on the display opens further sub menues. IIu. 10 menu Measurement 1 Softkey Print 2 Softkey Show graph 3 Softkey Delete 4 Softkey Edit 5 Softkey Close Menu Print out a test touch the table at the touchscreen ... -
Page 25: Replacing Printer Paper
5.3.1 Replacing printer paper Dimensions of the thermal printer paper: Width: 58mm Diameter: 31mm Length: max.10,5m paper thickness: 55g/m In case of missing thermal paper, the printer signal LED will flash in red. 1. Lift up the flap of the paper tray slightly 2. -
Page 26: Deleting The Last Test
Deleting the last test: Touch the table on the touchscreen sub menu opens Press soft key Delete Last measurement will deleted Labelling of test data: The labelling fields allow to insert comments for each test. 1. Touch the table on the touchscreen ... -
Page 27: Show Tests
Show tests 1. Press the soft key History on the start screen all stored tests will be displayed in the nummeric order 2. Press the arrow FORWARD the next test will appear 3. Press the arrow BACK the previous test will be displayed IIu. -
Page 28: Execution Of Test
Execution of test Prerequisite: The test zone has to carry the entire load plate Weather related loose material on the test zone has to be removed Cavities in the test zone have to be filled with fine-grained sand Execution 1. - Page 29 CAUTION Danger of injury The falling weight can cause injuries or damages on the measurement equipment. The handle always must be used to catch the weight. Do not reach into the equip- ment at any time when the weight is falling down. All preload and measurement impulses will be applied as described above.
-
Page 30: Evaluation By Handheld
6 Evaluation by Handheld Interpretation of resuluts After completing a test the result is displayed below the upper table including correspond- ing test impulses. The Ev value in MN/m² informs about the load bearing capacity and the compaction of the tested ground. At the same time the ratio s/v (deflection/speed) is dis- played without unit. -
Page 31: Data Transfer To Pc-Software
7 Data transfer to PC-Software For storage and documentation the data records of the different tests can be transferred into the PC software. The data records are stored on the SD card and can be transmitted to the computer. The data records from the internal memory of the handheld have to be copied to the SD card first (refer to “Settings Measurement”). -
Page 32: Transport
8 Transport General Information CAUTION Danger of Injuries The falling weight can move uncontrolled without transport lock. The loading mechanism may not be transported without an activated transport lock. For all transports the transport lock must be engaged. ________________________________________________________________________ Page 32 / 36 Manual LWD WEBERconnect... -
Page 33: Malfunction
9 Malfunction Error message Fault Display info Remedy Several beep tones SD card is not SD card missing Install SD card after system start available Switch on ground Several beep tones No wireless connec- Gorund sensor sensor after system start tion to the ground could not be lo- ... -
Page 34: Disposal
10 Disposal Take into account the local regulations for the disposal of material and consumables. Clean correctly the assemblies and components and disassemble the equipment accord- ing to the local labour and environmental regulations. Send disassembled components to recycling: Scrap the metals ... -
Page 35: Attachments
12 Attachments 12.1 Declaration of conformity: ________________________________________________________________________ Page 35 / 36 Manual LWD WEBERconnect... -
Page 36: Original Calibration Certificate
12.2 Original Calibration Certificate: ________________________________________________________________________ Page 36 / 36 Manual LWD WEBERconnect...
