Summary of Contents for Topcon Value Line XR-1

Page 1 Value Line Auto Steering Installation Manual...
Page 3: Table Of Contents
Table of Contents Preface ..............iii Introduction .
Page 4 Steering controller setup ............3-7 Calibration .
Page 5: Preface
Microsoft Corporation. The Bluetooth word mark and logos are owned by Bluetooth SIG, Inc. and any use of such marks by Topcon Positioning Systems, Inc. is used under license. Other product and company names mentioned herein may be trademarks of their respective owners.
Page 6: License Agreement
Conditions (including the Software license, warranty and limitation of liability). Technical Documentation and Utility Software Download and open the myTopcon NOW! app on your iOS or Android device or visit the Topcon support website (mytopconnow.topconpositioning.com). Log in to access available manuals, technical and compliance documentation, training material, and utility software to help set up and use your Topcon product.
Page 7: Manual Conventions
Select Finish. Italic Reference to another manual or help document Refer to the Topcon Reference Manual. Notification that one or more steps may be taken to reduce effort, time, and/or expense. Further information to note about system configuration, maintenance, or NOTE setup.
Page 8: Introduction
Introduction Prepare for Installation The Value Line Auto Steer installation procedures are designed to help the system installation go smoothly and will keep the amount of time a machine is away from the work site to a minimum. XC1 / XC1 plus console XW-1 steering wheel Battery XR-1 receiver...
Page 9: System Components
System components XR-1 receiver 1056329-01 GPS receiver/Steering controller XW-1 steering wheel 1066330-01 Electric steering wheel 1069672-01 Console, 7 inch XC1 plus 1069671-01 Console, 10 inch Harness 1067586-01 Value Line All-in-one harness Spline/anti-rotation 1068618-01 Generic spline/anti-rotation adapter kit XR-1 receiver XW-1 electric steering wheel XC1 console XC1 plus console Harness...
Page 10: Optional Components
CL-20 Cloud connectivity device The CL-20 Cloud Connectivity Device adds cloud-based services and NTRIP corrections including Topcon Agriculture Platform (TAP) and TopNET Live. SATEL-TR The SATEL-TR is an external radio modem that receives RTK correction data from an RTK base with a radio transmitter.
Page 11: Machine Inspection
Machine Inspection • Examine the machine to make sure it is in an acceptable condition for field applications • Look for damage that could interfere with the installation and operation of the components Safety The power switch from the electric steering wheel must be in the OFF CAUTION position whenever the vehicle is on a public road.
Page 12: Example Sticker Locations
Example Sticker Locations Figure 1-2: Sticker secured near console P/N: 1074425-01...
Page 13 Figure 1-3: Sticker secured near XW-1 Steering Wheel P/N: 1074425-01...
Page 14: Installation
The mounting bracket kits are available from NOTE NOTE your Topcon dealer. 1. Clean the installation area with a solvent such as methylated spirits. 2. Find the centerline of the tractor roof. Measure the center point of the roof at the front and at the back.
Page 15 4. Install the XR-1 on the centerline and square to the tractor roof. If the XR-1 is not installed exactly on the centerline of the roof, the offset NOTE NOTE can be set in the vehicle configuration process. P/N: 1074425-01...
Page 16: Electric Steering Wheel
XW-1 Electric steering wheel A spline adapter and an anti-rotation bracket are necessary to install the XW-1 electric steering wheel. They are specific to the tractor make/model. A generic kit (1068618-01) is included. Refer to the Value Line Steering Solution Supported Platforms (OD1039 REV A) to find the correct adapters for the installation.
Page 17 If the generic kit does not contain the appropriate spline adapter or anti-rotation brackets, try each spline adapter or anti-rotation bracket in the kit to see if it fits the tractor. If no spline adapter or anti-rotation bracket fits the tractor, contact your Topcon dealer for alternatives.
Page 18: Xw-1 Electric Steering Wheel Installation
XW-1 electric steering wheel installation 1. Remove the tractor steering wheel. Remove the nut below the center cover. Refer to the tractor manufacturer’s manual for more information. 2. Pull the steering wheel off the steering spline. Force may be required to remove the steering wheel.
Page 19 5. Attach the anti-rotation bracket to the bottom of the wheel. Use the Value Line Steering Solution Supported Platforms (OD1039 REV A) to select the correct anti-rotation bracket for the tractor. 6. Secure the anti-rotation bracket to the rear of the wheel using the 4x M5 countersunk screws supplied in the kit.
Page 20: Xc1/Xc1 Plus Console
XC1/XC1 plus console Install the XC1/XC1 plus console using the RAM mounting kit. The RAM mounting kit includes: • RAM mount base plate • RAM 4.66-inch double socket bar • RAM U-bolt bracket • M5X14 screws 1. Find an area on a bar or tube in the cab that is within easy reach of the operator and does not obstruct the view from the cab.
Page 21: Value Line Harness
Value Line harness The Value Line all-in-one harness connects the XR-1 GPS receiver, the XW-1 electric steering wheel, and the XC1 or XC1 plus console. The harness connects to the battery to supply power to the components. The harness has a power switch to turn the system on or off. The battery must support 25 A to power the XW-1 electric steering wheel.
Page 22 4. Install the power switch where it can be easily reached but not accidentally activated. 5. Use cable ties to secure the harness. If possible, run the harness under the rubber mat to prevent a trip hazard in the cab. P/N: 1074425-01...
Page 23: Optional Parts
Optional Parts CL-20 The CL-20 is installed in the cab using a bracket or double-sided adhesive. 1. Identify an installation location in the cab. 2. Secure the CL-20 with the double-sided adhesive or the bracket. 3. Use the harness supplied in the kit to connect the CL-20 to the XC1. The XC1 supplies power directly to the CL-20.
Page 24: Satel-Tr
The SATEL-TR is installed on the cab roof. Many swell-latch style receiver brackets can be used to mount the SATEL-TR next to the XR-1. Contact your Topcon dealer for more information. Use the 1073361-01 harness to connect to the XR-1 GPS receiver and the Value Line All-in-one harness.
Page 25: Wi-Fi Adapter
Wi-Fi adapter 1. Insert the Wi-Fi adapter into one of the USB ports on the XC1/XC1 plus. Connect WIFI dongle to rear or side USB port XC-1 / XC-1+ CONSOLE XC-1 / XC-1+ CONSOLE FRONT REAR XC1/XC1 Plus Front 2 XC1/XC1 Plus Back 3 Connect Wi-Fi dongle to rear or side USB port 2.
Page 26: Was Kit
WAS kit A Wheel Angle Sensor (WAS) kit is available. It can improve steering performance. The WAS sensor sends front axle steering position information for the front steering wheel to the control system. Refer to the installation manual included in the WAS kit for more information. XW-1 steering wheel Wheel angle sensor 2-13...
Page 27: Iso-Vt Adapter Harness
The ISO-VT adapter harness connects the Value Line system to the ISOBUS vehicle harnesses. These vehicle harnesses allow an ISOBUS implement to be connected to the tractor and for the ISOBUS UI to be shown on the XC1 or XC1 plus console. Contact your Topcon dealer for more information.
Page 28: Configuration
Configuration Vehicle measurements Vehicle and implement profiles are necessary to use the system. Each profile requires the physical dimensions of the machine to be accurately measured and entered. The recommended tolerance is ±5 cm. Measure and record the dimensions before starting system setup. 1.
Page 29: Implement Measurements
Implement measurements The necessary measurements depend on the implement type. 1. Select to open the Setup screen. 2. Select > (Vehicle > Geometry). 3. Measure and record the required implement dimensions (example below). Swath width Implement working width Working length Length from start to finish of the boom’s working area defines the working area along with the swath width Overlap...
Page 30: Gnss Receiver
GNSS receiver 1. Select Setup to open the Setup screen. 2. Select System > GPS > Receiver Correction source 1. Select Setup to open the Setup screen. 2. Select System GPS > > Correction 3. Select the correction source. 4. Select OK. The correction sources in the list change based on the OAF license on the XR-1 GPS receiver.
Page 31: Vehicle Setup
Vehicle setup Create a new vehicle profile for the tractor. 1. Select Vehicle > New 2. Select a new vehicle template by selecting the vehicle button in the middle of the screen. 3. Select VEHICLE NAME and enter a name using the on-screen keyboard. 4.
Page 32: Implement Setup
Implement setup Create a new implement profile for the tractor. 1. Select Implement > New 2. Use the arrows to select an implement type. Rigid Pivoted (tow behind) Front mount Double pivoted (tow between) P/N: 1074425-01...
Page 33 3. Select IMPLEMENT NAME and enter a name using the on-screen keyboard. 4. Select OK. The Implement Geometry screen opens automatically when an implement is created or selected. 5. Select each implement dimension. 6. Enter the recorded implement measurement. 7. If the implement is pivoted and has active steering, make sure active steering is selected. 8.
Page 34: Steering Controller Setup
Steering controller setup 1. Select Vehicle > Steering 2. Select WHEEL ANGLE SENSOR. These alternatives are available: Disabled Steering does not use wheel angle sensor information Enabled Steering uses a wheel angle sensor fitted to the steering axle Virtual Steering uses a virtual wheel angle sensor solution incorporated in the XW-1 electric steering wheel.
Page 35: Calibration
Calibration Steering calibration The console uses satellite information to find the location of the vehicle and control the steering system. The system must be calibrated for the vehicle. 1. Drive the vehicle to a large level area away from personnel and obstacles. The vehicle must be able to drive in complete circles.
Page 36: Wheel Angle Sensor
> Auto Steer Calibration > WHEEL ANGLE SENSOR Topcon recommends a calibration is done even if the screen shows it is not necessary. 2. Drive the vehicle forward at a speed of 2 kph (1.2 mph). The calibration procedure starts.
Page 37: Compass And Vehicle Direction
Compass and vehicle direction The compass and vehicle direction are calibrated when the system is started. 1. Confirm the direction of the vehicle when driving forward. The vehicle direction can be changed manually on the Steering Calibration screen. P/N: 1074425-01...
Page 38: Mounting Bias
Do a mounting bias calibration every 6-12 months at a minimum or if any of the items above change. Topcon recommends a mounting bias calibration is done even if the screen shows it is not necessary. 1. Move the vehicle to a clear area with sufficient space to drive at least 70m (230 ft) and turn at each end.
Page 39 9. Turn the vehicle and drive back to the A point. Maintain the vehicle speed. A blue line on the Calibration Progress starts to move after the Distance To A reaches 50 m. The Calibration Progress will stop at 50%. The system has sufficient data for the first part of the calibration.
Page 40: Regulatory Information And Safety Warnings
1. Read and become familiar with the machine manufacturer’s operator’s manual, including safety information, before installing or using Topcon components. 2. Do not attach Topcon brackets, cables, or hose connections while the machine is running. 3. Do not allow any Topcon components to limit the visibility of the operator.
Page 41: Rf Radiation Hazard Warning
NOTICE Device Quick Start Guide (P/N 1051861-01). EU Product Conformity Hereby, Topcon declares that the XR-1 and CL-20 are in compliance with the essential requirements (radio performance, electromagnetic compatibility and electrical safety) and other relevant provisions described in Directive 2014/53/EU.
Page 42 ISED Canada Statements CAN ICES-3(A)/NMB-3(A) This Value Line System complies with ISED Canada license exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
Page 43 P/N: 1074225-01 FCC Regulatory Information and Safety Warnings...
