    INSTRUCTION MANUAL Please save this owners’ manual and read it before each use. This manual will explain how to use the battery tester safely and effectively. Please read and follow these instructions and precautions carefully. Table of Contents 1. Important Safety Instructions 2.
  • Page 3: Important Safety Instructions

    1. IMPORTANT SAFETY INSTRUCTIONS Save these instructions - This manual contains important safety and operating instructions. Keep out of reach of children Do not expose tester to rain or snow. Use of an attachment not recommended or sold by the manufacturer may result in a risk of fire, electric shock, or injury to persons.
  • Page 4: Product Description

    3. PRODUCT DESCRIPTION Pilot Lamp Printer Cover LCD Screen Battery Compartment 1 = Pilot Light on/off 2 = Print Button 3 & 4 = Page up/Page down 5 = Escape/Exit button 6 = Enter button 7 = Battery compartments Battery Tester is designed to test 6 and 12 Volt batteries and 6, 12 or 24 Volt charging systems. It offers quick and accurate assessment of battery condition and starting and charging system performance.
  • Page 5: Preparing Battery To Be Tested

    Below is a chart of the operating range of the tester based on the applicable capacity rating systems: Rating System Testing Capacity 40-2000 CCA 40-2000 CCA 50-2400 CCA 50-2400 CCA 5 -250 AH The tester has a recommended operating ambient temperature range of -20°C to 50°C. 4.
  • Page 6: Tester Configuration

    6. TESTER CONFIGURATION You must be properly connected to a battery (See Battery Tester Operation: Battery Testing, steps 1-3) with internal batteries installed to configure the tester. Upon proper battery connection (with internal batteries installed), the tester will display the Home Screen. The Home Screen shows the battery status by providing the Open Circuit Voltage of the connected battery.
  • Page 7 7.3 Battery Voltage Selection Use the “UP” and “DOWN” buttons to select different battery voltage 7.3.1 menus and the background color of the selected menu will light up for highlighting (default 12V battery); Press “ENTER” button to enter the next interface of the corresponding 7.3.2 menu.
  • Page 8 7.6 Ambient Temperature Selection Use “UP” and “DOWN” buttons to select different temperature, and the 7.6.1 background color of the selected menu will light up for highlighting; Press “ENTER” button to enter the next interface of the corresponding 7.6.2 menu. Press the “ESC”...
  • Page 9 Line 1 – Test Results (Heading) Line 2 – Results (e.g. BAD, PASS, etc.) Line 3 – Battery Type; Line 4 – State of Health (SOH) Percentage; Line 5 – State of Charge (SOC) Percentage; Line 6 – Battery Voltage; Line 7 –...
  • Page 10 7.11.5 The system startup and maintenance result page is displayed 7.11.6 Press "ENTER" button to proceed to the next menu "Charge Test" 7.12 Charging System Test" interface 7.12.1 Operate the vehicle according to the prompt of the interface content, and then press “ENTER”...
  • Page 11 7.12.4 After the end automatically jump into the next interface, ripple test results 7.12.5 Press “ENTER” button to enter the next step; The next interface content is as follows: On-load voltage result: 7.12.6 Press “ENTER” button to enter the next step; According to the above interface content, turn off the vehicle engine and press the "ENTER"...
  • Page 12 7.12.10 Press “ENTER” to display the "Save Result" screen. Press “ENTER” to save and jump to the main menu interface. 7.13 The Settings menu 7.13.1 Press “UP” and “DOWN” buttons to highlight the "Settings" function from the main menu page. 7.13.2 Press the “ENTER”...
  • Page 13 7.13.7 Print Settings; Enter user details. This will be shown at the top of all printed test results. Press “ENTER” or “ESC” to save and return to “Tool Setup”. 7.13.8 License plate setting; Enter customers license plate number. This will be shown on the saved records.
  • Page 14: Maintenance And Care

    To Delete the test record(s), press and hold the “ESC” button for 3 7.14.8 seconds and the delete interface will show up with two options as shown in the picture. Use the “UP” and “DOWN” buttons to highlight the desired option.
  • Page 15: Assembly Drawing

    9. ASSEMBLY DRAWING Part Description QTY. Part Description QTY. Back housing Thermal printer Screw ST3x16 Battery compartment cover Light PCB board Battery connector Thermal paper roll 9V battery (not included) Front housing Output cable Printer cover Screw ST3x8 Main PCB board Cable with clamps Acrylic plate Carry case (not shown)
  • Page 16 10. WARRANTY STATEMENT APPLICABLE ONLY TO PRODUCTS SOLD IN AUSTRALIA Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage.
