Ballenger Motorsports, Inc.
Phone: (804) 915-7201
8052 Elm Drive, Ste G
Fax: (804) 433-3825
Mechanicsville, VA 23111
www.bmotorsports.com
AFR500V3CAN Setup Manual
(Addendum to AFR500V3 Tuning Manual)
Table of Contents
Table of Contents..................................................................................1
1. Addendum Note................................................................................2
2. Introduction...................................................................................... 2
3. New features in the AFR500V3CAN .............................................. 2
4. Kit Contents...................................................................................... 2
5. Functional Description..................................................................... 3
6. Wiring Installation............................................................................ 3
7. Setting & Explanation of Options.................................................... 4
8. AFRCANProgrammer Setup............................................................ 4
9. HPTuners VCM Scanner Setup........................................................ 7
10. HPTuners USB-Serial Setup.........................................................11
10. EFI Live Scan and Tune Setup..................................................... 11
11. Haltech ECU Setup.......................................................................12
12. Motec ECU Setup......................................................................... 13
13. Message Structure.........................................................................13
Ballenger Motorsports AFR500V3CAN Manual Rev1.2
- 1 -
Advertisement
Table of Contents
Related Manuals for Ballenger Motorsports AFR500V3CAN
Summary of Contents for Ballenger Motorsports AFR500V3CAN
-
Page 1: Table Of Contents
(Addendum to AFR500V3 Tuning Manual) Table of Contents Table of Contents..................1 1. Addendum Note................2 2. Introduction..................2 3. New features in the AFR500V3CAN ..........2 4. Kit Contents..................2 5. Functional Description..............3 6. Wiring Installation................3 7. Setting & Explanation of Options............ 4 8. -
Page 2: Addendum Note
CAN Enabled ECUs, OBD2 ECU tuners, aftermarket gauges, dashes, & loggers. 3. New features in the AFR500V3CAN The AFR500V3CAN is a major iteration on the AFR500V2. All features & functions of the original AFR500V2 remain intact with the added improvements below: •... -
Page 3: Functional Description
4 Way DTM connector into a receiving CANbus connector or hub. Then plug the 2 Way DTM connector into the DTM-2P CAN connector coming from the back of the AFR500V3CAN harness. Ballenger Motorsports AFR500V3CAN Manual Rev1.2 - 3 -... -
Page 4: Setting & Explanation Of Options
AFR500V3CAN unit. 7. Setting & Explanation of Options The AFR500V3CAN has an internal 120R terminating resistor that is enabled using a setting in AFRCAN Programmer software. It is on by default for all non-OBD2 configurations. -
Page 5: Afrcanprogrammer Setup
3. Power up the AFR500V3CAN from a 12v power source using the main harness. The AFR500V3CAN will not operate via USB power. 4. Plug in the USB-C cable to the AFR500V3CAN then to your computer’s USB port. 5. For most cases, leaving "Auto Configure Port'' should work and you can go straight to the Configuration Tab. - Page 6 3. CAN address ID: The first box is for changing the CAN ID (Default is 0x500, 11 bit), there are options for displaying the ID in hexadecimal or decimal and 11-bit or 29-bit (Extended ID). Ballenger Motorsports AFR500V3CAN Manual Rev1.2 - 6 -...
-
Page 7: Hptuners Vcm Scanner Setup
Usually the hex ID is followed by ", CAN '' (Note: OBD2 CAN IDs respond as the base ID plus 8 for example IDs 7E0-7E7 respond as 7E8-7EF). Some newer vehicles may need to check the “Extended 29-Bit” in AFR CANProgrammer. Ballenger Motorsports AFR500V3CAN Manual Rev1.2 - 7 -... - Page 8 "Fuel", "Open & Closed Loop", "Oxygen Sensors" and double click on "WB EQ Ratio 1 (SAE)". 4. If “WB EQ Ratio (SAE)” doesn’t show up you may need to click “Repoll For Supported Parameters” from the “Vehicle” menu. Ballenger Motorsports AFR500V3CAN Manual Rev1.2 - 8 -...
- Page 9 6. If you prefer to view AFR you can right click on "WB EQ Ratio 1 (SAE)" and “Units” select the AFR for your fuel type. Note that this may not match the AFR500V3CAN display whose stoichiometric reference is 14.56 (Indolene Clear).
- Page 10 1. Plug in the AFR500C USB programming/serial cable to your computer. 2. Using Section 8 “AFRCAN Programmer Setup” retrieve settings, then change the “Interface” to “Serial AFR” for air-fuel-ratio, or “Serial Lambda” for lambda. Ballenger Motorsports AFR500V3CAN Manual Rev1.2 - 10 -...
- Page 11 "AEM - AFR” for air-fuel-ratio, or AEM - EQ Ratio for lambda. (Note: this must correspond to the “Serial AFR” or “Serial Lambda” Interface setting in AFR CANProgrammer settings.) Ballenger Motorsports AFR500V3CAN Manual Rev1.2 - 11 -...
-
Page 12: Efi Live Scan And Tune Setup
“Auto Detect”. 2. In the “Select Controller” window you can Select “Auto Detect” or right click on the “Right-click to select trans-controller” and select “Ballenger Motorsports AFR500V2 Bank 1” then click “OK”. Ballenger Motorsports AFR500V3CAN Manual Rev1.2 - 12 -... -
Page 13: Haltech Ecu Setup
“Value” column. 12. Haltech ECU Setup 1. With the AFR500V3CAN connected and powered up, turn on the car to power up the ECU and open the Haltech software and connect to the ECU. Ballenger Motorsports AFR500V3CAN Manual Rev1.2 - 13 -... -
Page 14: Motec Ecu Setup
1. From the “Adjust” menu select “General Setup” then “Communication” then “CAN Setup”. 2. Under Parameter “CAN 1 Data” enter “1” for “PLM Receive” 3. Under “CAN 1 Address” enter the decimal address value which by default is 1120 (460h). Ballenger Motorsports AFR500V3CAN Manual Rev1.2 - 14 -... -
Page 15: Message Structure
CAN adapter, and click on the “START” button. 5. For some examples of what the ECM Software can do, see this manual: https://ecm-co.com/download/lambdacan-module-software-co nfiguration-manual/?tmstv=1691775259 14. Message Structure for Default CAN Setting Ballenger Motorsports AFR500V3CAN Manual Rev1.2 - 15 -... - Page 16 *Lambda value is using big/Motorola endianess Ballenger Motorsports AFR500V3CAN Manual Rev1.2 - 16 -...
