TLW VEW K30-2034CCTZ Installation Manual

Pairing Guides
Product Code: K30-2034CCTZ
Instructions to pair the remote with the LED Controller (make sure
everything is installed before starting to program)
1.
Turn on the Lights - Press the PROG button on
the LED controller once to turn on the lights.
2.
Initiate Pairing Mode - Press the PROG button
on the LED controller four times. The lights will
flash twice, indicating that pairing mode is
active.
3.
Position the Remote - Place the remote within
10 cm of the LED controller to ensure a strong
connection during pairing.
4.
Activate the Remote - On the remote, press
the button once (This will turn on the red
LED indicator light.)
5.
Select Zone - Press the
lights to Zone 1. (For additional zones, replace
this step with ,
different zones as desired.)
6.
Finalise Pairing - Then press and hold
button till the red LED flashes and then goes
solid red. Press
indicator light will blink and then flash on the
remote, whilst the LED lights will flash twice
then flash again. Once this has all stopped
the remote is now paired.
7.
Test the Connection - Turn on the lights with
the on the remote and use the colour
wheel to adjust colours, confirming the
connection.
once to assign the
, or to allocate lights to
button once. The red LED
LED Controller
PROG Button
LED Controller
