syscomtec crossXio SCT-IPCX User Manual

Hdmi 2.0/usb av over ip controller
Hide thumbs

Advertisement

Quick Links

Download this manual
SCT-IPCX
HDMI 2.0/USB AV over IP Controller
User Manual
All Rights Reserved
Version: SCT-IPCX _2024 V1.0.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the crossXio SCT-IPCX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for syscomtec crossXio SCT-IPCX

  • Page 1 SCT-IPCX HDMI 2.0/USB AV over IP Controller User Manual All Rights Reserved Version: SCT-IPCX _2024 V1.0.0...
  • Page 3 HDMI 2.0/USB AV over IP Controller Preface Read this user manual carefully before using the product. Pictures shown in this manual are for reference only. Different models and specifications are subject to real product. This manual is only for operation instruction, please contact the local distributor for maintenance assistance.

  • Page 4: Table Of Contents

    HDMI 2.0/USB AV over IP Controller Table of Contents 1. Introduction ....................2 1.1. Overview ....................2 1.2. Features ....................2 1.3. Package Contents ................2 1.4. Specifications ..................3 1.5. Panel Descriptions ................3 2. Installation ...................... 5 3. Customer Service ..................6 3.1.

  • Page 5: Introduction

    HDMI 2.0/USB AV over IP Controller 1. Introduction 1.1. Overview This device is used as an A/V controller for managing and configuring encoders and decoders over IP network. It includes two Ethernet ports and one RS232 port, offering integrated control features—LAN (Web UI & Telnet) and RS232. Additionally, it can work with a third-party controller to control the codecs in the system.

  • Page 6: Specifications

    HDMI 2.0/USB AV over IP Controller 1.4. Specifications Technical 1 x LAN1 (PoE) (10/100/1000 Mbps) I/O Connections 1 x LAN2 (CONTROL) (10/100/1000 Mbps) 1 x RS232 1 x POWER LED 1 x STATUS LED Button 1 x RESET Button LAN (Web GUI & Telnet), RS232 and a third party Control Method controller General...
  • Page 7 HDMI 2.0/USB AV over IP Controller Name Description Recessed down this RESET button for ten or more seconds, and then Button release it, the device will reboot and restore to its default settings. Note: When the default settings are restored, your custom data is lost.

  • Page 8: Installation

    HDMI 2.0/USB AV over IP Controller Name Description configuring and managing the device and decoders through RS232 software or a third party controller. RS232 parameters: Baud Rate: 9 600 bps Data Bits: 8 bits Parity: None Stop Bits: 1 12V: Pins 12V and G are used for providing 12V DC ...

  • Page 9: Customer Service

    HDMI 2.0/USB AV over IP Controller 3. Customer Service The return of a product to our Customer Service implies the full agreement of the terms and conditions hereinafter. There terms and conditions may be changed without prior notice. 3.1. Warranty The limited warranty period of the product is fixed three years.
  • Page 12 HDMI 2.0/USB AV over IP Controller syscomtec Distribution AG Keltenring 11 D-82041 Oberhaching (bei München) Tel.: +49 89 666 109 330 Email: post@syscomtec.com https://www.syscomtec.com...
