- Page 1 BOW MOUNT PLATE INSTRUCTIONS BOW MOUNT PLATE INSTRUCTIONS INFLATABLE SKIFF...
-
Page 2: Table Of Contents
CONTENTS Parts Listing Note Assembly Boat Installation Trolling Motor Installation Customer Support PARTS LISTING Bow Mount Rails Bow Mount Plate EVA Pad Bow Mount Board Spacers M6 x70mm Screws Washers M6 Acorn Nuts M6 Track Slugs M6 Track Knobs Bow Security Strap... -
Page 3: Note
NOTE To use this kit you must have the Forward Track Mount Board Kit Installed. Review those instructions for installation. Caution: The Bow Mount Plate is intended for Bow Mount Motors and Accessory mounting. IT IS NOT DESIGNED TO BE A STANDING PLATFORM! ASSEMBLY EVA installation (EVA padding installation is optional and you may want to leave this off if you are mounting items to... - Page 4 • Select one of the foam pads and peel back a small section of the backing. Align the pad back on the board and press down on the area where you removed the backing strip. Press down and make sure that it is appropriately aligned.
-
Page 5: Boat Installation
BOAT INSTALLATION Insert the rear track slugs into the Forward Track Mounts and slide forward. (Figure Below) Tighten down the knobs. (Figure Below) - Page 6 Feed the webbing strap through the slot located at the front of the Bow Mount Plate and the D-ring located on the bow of the NS130. Tighten down the strap to secure the front of the Bow Mount Plate. (Figure Below) ! WARNING: This product contains a chemical known to the State of California to cause cancer.
-
Page 7: Trolling Motor Installation
(Figure Below) CUSTOMER SUPPORT If you have questions that are not answered in this manual or troubleshooting is not successful, please contact Newport! Our California based customer service team is standing by to assist you. 8:30 AM - 7:00 PM ET (866) 721-0002 support@newportvessels.com... - Page 8 SHARE YOUR ADVENTURES @newportvessels REV IX17X249 PN 20M1000022...
