- Page 1 ZEER 7-11-22kW Residential EV Charger Installation & User Manual...
-
Page 2: About The Manual
Once a new document is published, the old document will automatically become invalid. Please go to the official website to obtain the latest version. WECO Company shall not be liable for any losses caused by any wrong operation based on the older documentation or manuals. -
Page 3: Table Of Contents
Table of Contents About the Manual .................................. 2 Overview ..................................2 Version Revision History ............................... 2 1 Safety Instruction ................................4 General security considerations ............................ 4 Safety in installation ..............................4 Safety in electrical connection ............................5 2 EV charger Instruction ................................ 6 3 Pre - installation ................................ -
Page 4: Safety Instruction
General security considerations The safety warnings listed in the manual represent only those known to WECO and WECO assumes no responsibility for violations of general safe operating requirements or safety standards for the design, production and use of the equipment. -
Page 5: Safety In Electrical Connection
During installation, liquids, debris or conductive particles must be prevented from entering the system, which could lead to internal short circuits or system failure. Equipment should be strictly prohibited to be installed under air conditioning outlets, ventilation openings, and machine room outlet windows that are prone to water leakage to prevent liquid from entering the equipment. -
Page 6: Ev Charger Instruction
The EV charger is Versatility，Efficiency，and Accessibility. It is designed to work with your home energy system for your better EV charging experience. Wallbox Model This paragraph defines product models: ZEER 7, ZEER 11, ZEER 22 Naming convention ZEER (Refer to Figure-2-1, using ZEER 7 as an example): ZEER Nominal Power output 7kW ZEER: Series Name... - Page 7 N Conductor for Single phase or three phase PE Conductor for protective earthing system L1 Conductor, Single phase or three phase L2 Conductor for Three phase L3 Conductor for Three phase Specifications Specifications ZEER 7 ZEER 11 ZEER 22 Model AC230V+15%/ AC400V+15%/ AC400V+15%/ Input Voltage...
- Page 8 Charging Connector IEC62196 User Interface Three color Led Light/ APP Ac output Type Type 2 Earth leakage protection Type A+6mA parameters (30mA AC+6mA DC) Case Material ABS+PC material Shell Size 350mm*200mm*120mm Protection Class IP55 Leakage, Over-voltage, Under-voltage, Overload, Grounding, Safety Protection Over-temperature (-30 ℃...
-
Page 9: Emergency Button
Charger Status The LED lighting on the wall box is marked with 3 colors. Different charging states can be fed back through different colors and flashing states, which are as follows. Light-off--Power off No electric input, the charger is out of service. RGB flash--Offline Charger is waiting for network when it is not connected to the EV (electric vehicle). -
Page 10: Pre - Installation
3 Pre - installation Packing list Before unpacking, please check the outer packaging for visible damage, such as holes, cracks, or other signs of possible damage inside. If there is any abnormal packaging or the wallbox model does not match, do not open it and contact your dealer as soon as possible. - Page 11 Inform the person responsible for managing the electrical system of the presence of the solar wallbox and batteries, update the electrical diagrams of the buildings. Installation location Installation Space and Height 500mm 300mm 300mm Keep this minimum distance area free 500mm Recommend install height as 1500mm...
-
Page 12: Installation Instruction
4 Installation Instruction Use EV charger Only Use with Energy Storage System+EV charger... - Page 13 Safety matters for wiring: Must ensure power-off operation before wiring. The installer is well insulated and protected. Prohibit wiring during rain and thunderstorms. No power on until the wiring window is closed. Safety matters for installation: ...
- Page 14 Installation Steps: 1. Loose wallbox base Loose wallbox base M5*4 screws from the back of wallbox 2. Install the wallbox base on a wall Make the holes and fix the wallbox base on the wall with drill and expansion bolt 3.
- Page 15 4. Install waterproof cable gland Install the cable gland from the top or bottom 5. Connect the wallbox base to the Grid Power.
- Page 16 6. Install the CT on L line and connect the CT to the the wallbox base. Fault CT connection cases Case1: Connected to wrong Line Case2: Wrong Orientation Case3: Connected to wrong Line PE line N line L line Grid Grid Grid Note!
- Page 17 7. Install the wallbox cover.
-
Page 18: Commission
5 Commission System power up Prerequisites Before closing the AC switch of EV Charger, it is necessary to measure whether the AC voltage on the grid side of the AC switch is within the range allowed by the EV Charger. Procedure Step 1: Close only the AC switch between the EV Charger and the grid. - Page 19 c. Fill in the account and password and Click “Sign In”. Step 3: Add Plant on Noor APP a. Click “Add Plant”. b. Fill in the Plant info and Click “Save”.
- Page 20 Step 4: Add Device on the Plant and config the WIFI module a. Click “Add Device”. b. Click the “EV Charger”. c. Scan the QR code of WIFI module or manual input WIFI module SN number and Click “Adding” to finish add device.
- Page 21 d. Click “Smart config” to config the WIFI module to homeowner Router step by step. Note：Press the emergency stop button on the side of the device. When you hear a beep and the indicator light is flashing, pulling out the emergency stop button indicates that the device has entered Ble configuration network configuration mode.
- Page 22 Scan the QR code of WIFI module or manual input WIFI module SN number and Click “Adding” to finish add device. Note：Select the parent device on the list for WECO residential energy system in order to combine the WECO ESS...
- Page 23 d. Click “Smart config” to config the WIFI module to homeowner Router step by step. Note：Press the emergency stop button on the side of the device. When you hear a beep and the indicator light is flashing, pulling out the emergency stop button indicates that the device has entered Ble configuration network configuration mode.
- Page 24 Step 5: Modify the EV Charger setting a.Click the icon and “EV Charger Setting” b.Press the EV Charger emergency button. c.Scan the QR code of WIFI module or manual input WIFI module SN number to enter setting page. Note: Access the EV settings by scanning the QR code of the EV charger. After finishing the setting, release the emergency button again Charging Station Setting description Work Mode: Normal: The EV charger is started manually from the inverter...
- Page 25 Start / Stop charging 1. Park the vehicle in a location where the EV charging connector can easily reach the charging socket. 2. Make sure that the LED indicator of the wallbox is in the standby state of blue light. 3.
- Page 26 Note: For households with grid power limitations, set the EV Charger charging power; accordingly, if it is a system parent with WECO inverter and EV charger, set the Local Load Balancing enable and Available Utility power. Stop the charger Click the icon and “Basic Setting”...
- Page 27 Charger information...
-
Page 28: Troubleshooting
6 Troubleshooting Please contact the WECO service team for more support. Case Solution guidance 1. Check the E-stop button. Make sure it is not pressed down. No turn-on after power linked 2. Check that the cables are properly connected. 1. Check if the WiFi password is correct. -
Page 29: Appendix A Abbreviations
Appendix A abbreviations Control Pilot Current Transformer Protective Earth Proximity Pilot Electric vehicle Light Emitting Diode...
