PEM CMC Instructions For Use Manual

Rogowski common mode current sensor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
.
ROGOWSKI COMMON
MODE CURRENT SENSOR
INSTRUCTIONS FOR USE
CMC
POWER ELECTRONIC MEASUREMENTS Ltd.
+44 (0)115 946 9657 • info@pemuk.com • www.pemuk.com
This document is copyright © November 2024 Power Electronic Measurements Ltd. and all rights are reserved.
No part may be copied or reproduced in any form without prior written consent.
Nov 2024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CMC and is the answer not in the manual?

Questions and answers

Summary of Contents for PEM CMC

  • Page 1 ROGOWSKI COMMON MODE CURRENT SENSOR INSTRUCTIONS FOR USE POWER ELECTRONIC MEASUREMENTS Ltd. +44 (0)115 946 9657 • info@pemuk.com • www.pemuk.com This document is copyright © November 2024 Power Electronic Measurements Ltd. and all rights are reserved. No part may be copied or reproduced in any form without prior written consent. Nov 2024...

  • Page 2: Table Of Contents

    INTRODUCTION ................3 TECHNICAL SPECIFICATION ............3 STANDARDS AND APPROVALS ............. 5 OVERVIEW: CMC ................6 HANDLING INSTRUCTIONS ............7 SAFETY AND PRE-USE CHECKS ............8 POWER OPTIONS ................. 9 REPLACING THE BATTERIES ............9 SWITCHING ON ................10 OBTAINING THE BEST MEASUREMENT ........11 CLEANING AND DECONTAMINATION .........

  • Page 3: Introduction

    These warnings are identified by the following symbol: The intended use is for the measurement of AC current. PEM accepts no responsibility for any damage resulting from careless use, or failure to observe these instructions.
  • Page 4 Coil Insulation 10kV peak Coil Bend Radius 40mm Absolute di/dt Ratings 70kA/ s (peak) | 1.5kA/ s (rms) µ µ Environmental Indoor use / Altitude up to 2000m Installation Category III, Pollution Degree 2. Max. Rel. Humidity: 80% up to 31 Decreasing Linearly to 50% at 40 Measurement Category Cat III 1000V...

  • Page 5: Standards And Approvals

    STANDARDS AND APPROVALS EMC Approvals EN61326-1:2013 FCC Title 47 (CFR:2010, Part 15b) Safety Approvals EN61010-1:2010+A1:2019 EN61010-2-032:2012 Quality System IS09001:2015 Nov 2024 © November 2024...

  • Page 6: Overview: Cmc

    OVERVIEW: CMC 1. Rogowski Coil (Probe) 2. Probe ‘Free End’ 3. Ferrule 4. Connecting Cable 5. DC Power Socket 6. DC Power Status LED 7. Enclosure 8. BNC Output Socket 9. 4 x AA batteries 10.Status Indicator LED GREEN = ON = Battery LOW 11.Power Button...

  • Page 7: Handling Instructions

    HANDLING INSTRUCTIONS The coil is fully inserted when the user feels the free-end of the coil engage with the internal click-in mechanism inside the ferrule. Visual indication that the coil mechanism is fully inserted is provided by the black coil marker situated near the end of the coil, as shown below.

  • Page 8: Safety And Pre-Use Checks

    When bending the flexible coil around a conductor, avoid tight bends and sharp edges that could damage the coil. The voltage rating is clearly labelled on the coil. For the CMC this is 10kV peak. Never use at voltages greater than this value. The removable silicone sleeve supplied with the coil provides additional mechanical protection.

  • Page 9: Power Options

    POWER OPTIONS The CMC can be powered by an external DC source or by one of two battery options. The battery option is displayed along with the model type on the serial number label and will state either standard non-rechargeable batteries [B] or rechargeable option [R] External Supply The CMC can be powered by an external DC supply.

  • Page 10: Switching On

    4. Re-energise the conductor. 5. Use the push-button to switch ON by pressing and releasing the button, and to turn OFF by depressing the button fully; the LED indicates that the CMC is ON when the LED is GREEN. After switch on the CMC may require a settling period of up to 2 minutes before providing an accurate measurement.

  • Page 11: Obtaining The Best Measurement

    SHADED AREA SENSITIVITY TO EXTERNAL CURRENTS AND VOLTAGES The sensitivity of the CMC to currents that are outside the closed loop of the Rogowski coil is very small, provided that the external currents are less than the current rating of the transducer or that such currents are relatively distant from the coil.

  • Page 12: Cleaning And Decontamination

    In the event of a defect where the transducer has not been misused the CWT should be returned to PEM with all freight charges to be paid by the customer. Correction shall be in the form of repair or replacement.
