USER MANUAL
CYCRUN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CYCRUN and is the answer not in the manual?

Questions and answers

Summary of Contents for CYCROWN CYCRUN

  • Page 1 USER MANUAL CYCRUN...

  • Page 2: Table Of Contents

    Product Overview In the Box Assembly Instructions Charging Instructions Riding Modes Display and Buttons For Your Safety Battery Maintenance Cleaning Storage End-of-Life Disposal Parameters Warranty Contact Us...

  • Page 3: Product Overview

    1. Product Overview Display Reflector Power Switch Brake Lever Light Switch Twist throttle Turn Horn Switch Signal Switch Seat Front Light Rear Light Front Fender Rear Shock Hydraulic Rear Fender Suspension Fork Battery Tire Motor Crankset Chain Pedal Disc Brake Kickstand...

  • Page 4: In The Box

    2. In the Box Key x 2 Charger x1 Front Fender X1 USER MANUAL Electric Scooter User Manual x1 Battery x1 Tire Pump x1 Bike Frame with Rear Wheel x1 Pedal x2 Front Wheel x1 Kickstand x1 TOOLKIT Dual-Head Open-End Combination Hex Single-Head Angled Hex Wrench x1...

  • Page 5: Assembly Instructions

    ● Do not install the battery or start the computer until the bike is ● If you have any questions or can't find the information you need in fully assembled. the manual, please contact us via email at support@cycrown.com 3.1 Assemble and install the front wheel 1. Find the front wheel.
  • Page 6 3.2 Install the front fender 3.3 Install the kickstand 2. Install the kickstand on the kickstand mount by re-tightening the bolts as shown in the pictures. 1. Remove the bolt pre-installed on the front fork arch with an appropriate hex wrench and an open-ended wrench. 2.
  • Page 7 3.5 Install the handlebar 3.6 Install the front light 3. Attach the clamps to the front light brackets. 90° Remove the handlebar clamp and its bolts. Sit the handlebar in place and put back on the handlebar clamp. Then re-tighten the handlebar clamp bolts.

  • Page 8: Install The Pedals

    (turn the key clockwise to the “lock” position) before carrying or riding the e-bike. 3.9 Remove the battery (For your convenience, the battery is designed by CYCROWN to be removable.) When removing the battery, do not drop or damage the battery.

  • Page 9: Charging Instructions

    Charging Instructions 4.1 Charge the e-bike with the battery on the bike Battery charging port Indicator 1. Power off the e-bike, insert the key, and turn the key counterclockwise to the “open” position. ● Open the rubber cover of the charging port on the right side of the e-bike. ●...

  • Page 10: Battery Safety

    ● After charging, unplug the AC connector before unplugging the DC reduce battery life and performance. connector from the charging port. ● Only use the charger that comes with the CycRun e-bike. If the official charger is lost or damaged, Please contact Customer Service for a replacement.

  • Page 11: Riding Modes

    5. Riding Modes Pedal Turn off the e-bike and the smart display and you can pedal the e-bike like a normal bike. Display Reflector ● Before riding, fully charge the battery and make sure the battery Power Switch key is in the locked position. ●...

  • Page 12: Front View

    Front view Front & Rear Lights/Turn Signals/Horn Buttons Front & Rear Lights Speed Unit Metric: KM/H Imperial: MPH PAS Level S866 Turn Signal AVG MAX SPEED DST Current km/h Horn Speed ASSIST Battery ● Front & rear lights: Press up/down to turn on/off the front & rear Level mile lights.

  • Page 13: What's On The Screen

    3. Communication protocol: UART Displays all data for 1 second after startup. 3.3 Speed section AVG: average speed; MAX: top speed; SPEED: current speed; mph and km/h: speed unit AVG MAX SPEED DST The speed signal comes from the Hall signal in the motor, and is sent to the computer by the controller (the time of km/h...

  • Page 14: Basic Operations

    III. Buttons 2. Walk mode (walk assist) Keep holding to enter the walk assist mode. The bike will move 1. In the power-off state, press and hold to power on the forward at a constant speed of 3 mph. Release and the bike will bike;...
  • Page 15 Customizable parameters: 1. Select between the imperial and metric system P01 means imperial and metric system setting item: 00 for metric and 01 for imperial. Press to enter parameter selecting status. Press to select between 00 and 01. Press to save the setting and return to the selection interface of parameter setting items;...

  • Page 16: For Your Safety

    Attached Table 1: Fault code names and definitions Fault codes of YL-01 and YL-02 protocols Name Fault Name Fault E001 controller fault E004 throttle fault E002 communication fault E005 brake lever fault E003 Hall sensor fault E006 motor phase loss fault 7.
  • Page 17 Check by Bike Mechanics Every 6 Months Bikes require regular maintenance. Take your bike to your local bike shop twice a year for tuning. Critical components should be ● inspected frequently and be repaired and adjusted by an experienced mechanic. Notice Wear an approved helmet and other protective equipment to reduce any possible injury.

  • Page 18: Battery Maintenance

    8. Battery Maintenance A well-maintained battery performs well even after high mileage. Charge the battery after each ride to prevent the battery from draining from a full charge. Batteries perform best when used at room temperature (70°F [22°C]). However, using it at temperatures below 32°F (0°C) will degrade performance.

  • Page 19: Storage

    The substances inside the battery pose a chemical risk to the environ- ment. The end-of-life disposal recommendation for any CYCROWN product is to dispose of the entire device at an e-waste recycling center or through an e-waste recycling center, project or facility.

  • Page 20: Parameters

    12. Parameters Item Parameters Model Name CycRun Net Weight 76.74 LBS / 34.81 KG Product Dimensions 63.8*43.3*26.6 IN / 162*110*67.5 CM Package Dimensions 57*11*35.4IN / 145*28*90CM Max. Incline 11° (rider weighs 220.4 lb / 100kg) Max. Capacity 330 LBS / 150 KG Max.

  • Page 21: Warranty

    If you have issues with riding, maintenance and safety, faults, or failures The following situations are not covered by the warranty with the CYCROWN CycRun electric bike, please contact us. service, and you need to pay the relevant service fees. beware: support@cycrown.com...
  • Page 22 WWW.CYCROWN.COM SUPPORT@CYCROWN.COM...
  • Page 23 成品尺寸：210*140 mm 日期：20240116 材质及工艺： 封面250G, 内页157G 双铜过哑膜 备注：CycRun 说明书 by CycRun...
