Installer and User Manual
SLIM Wired Controller
17317100009536
IMPORTANT NOTE:
Please read this manual carefully
before installing or operating your
wired remote controller. Make sure to
save this manual for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SLIM 17317100009536 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for innovair SLIM 17317100009536

Summary of Contents for innovair SLIM 17317100009536

  • Page 1 Installer and User Manual SLIM Wired Controller 17317100009536 IMPORTANT NOTE: Please read this manual carefully before installing or operating your wired remote controller. Make sure to save this manual for future reference.
  • Page 3 This manual gives detailed description of the precautions that should be brought to your attention during operation. In order to ensure correct service of the wired controller please read this manual carefully before using the unit. For convenience of future reference, keep this manual after reading it.

  • Page 4: Table Of Contents

    Table of Contents 1. Safety precaution ............1 2. Installation accessory ........... 6 3. Installation method ............8 4. Specification ..............16 5. Feature and function of the wired controller ....17 6. Name on the LCD of the wired controller .....18 7. Name of button on the wired controller ......19 8.

  • Page 5: Safety Precaution

    1. Safety precaution WARNING Please ensure that a qualified distributor or professional installs the unit. Installation by untrained individuals may result in improper installation, which can cause electric shock or fire hazards. Follow this installation manual closely. Improper installation may lead to electric shock or fire. If reinstallation is necessary, it must be carried out by professionals.

  • Page 6: Battery Warning

    1. Safety precaution NOTE Use only the specified cables for wiring. Do not apply any • external force to the terminals, as this may cause wire damage or overheating, leading to a fire hazard. BATTERY WARNING WARNING: Contains coin battery. WARNING INGESTION HAZARD: This product contains a button cell or coin battery.
  • Page 7 1. Safety precaution BATTERY WARNING KEEP OUT OF REACH OF CHILDREN. Swallowing can lead to chemical burns, perforation of soft tissue, and death. Severe burns can occur within 2 hours of ingestion. Seek medical attention immediately. WARNING INGESTION HAZARD: This product contains a button cell or coin battery.
  • Page 8 1. Safety precaution WARNING Remove and immediately recycle or dispose of used batteries according to local regulations and keep away from children. Do NOT dispose of batteries in household trash or incinerate. Even used batteries may cause severe injury or death. Call a local poison control center for treatment information.
  • Page 9 1. Safety precaution Always completely secure the battery compartment. If the battery compartment does not close securely, stop using the product, remove the batteries, and keep them away from children. Battery type: CR2032 Battery nominal voltage: 3.0 V...

  • Page 10: Installation Accessory

    2. Installation accessory Select the installation location Do not install the unit in areas exposed to heavy oil, vapors, or sulfurous gases, as this may cause deformation and lead to system malfunction. Preparation before installation 1. Please confirm that you have supplied all the following parts. Name Qty.
  • Page 11 2. Installation accessory 2. Prepare the following assemblies on the site. Specification Qty.(embeded Remarks Name (only for reference) into wall) Switch box Wiring Tube(Insulating Sleeve and Tightening Screw) Precaution of installing the wire controller 1. This manual provides the installation method of wired controller.

  • Page 12: Installation Method

    3. Installation method 1.Wired remote controller structural dimensions ¾ in (20.6mm) 4 ¾ in (120mm) 1 ¾ in (46mm) Fig 3-1 2 ½ in (60mm) 2.Remove the upper part of wired controller Buckling Back cover Insert a slot screwdriver into the position slots in the lower part of the wired controller (2 places), and remove...
  • Page 13 3. Installation method NOTE: The PCB is mounted in the upper part of the wired controller. Be careful not to damage the board with the slot screwdriver. 3. Fasten the back plate of the wired controller For exposed mounting, fasten the back plate on the wall with the 3 screws (ST3.9*25) and plugs.

  • Page 14: Battery Installation

    3. Installation method NOTE: Place the unit on a flat surface. Be careful not to distort the back plate of the wire controller by overtightening the mounting screws 4. Battery installation Fig 3-5 Please contact professional technical after-sales service if the battery needs to be replaced.
  • Page 15 3. Installation method 5. Wire with the indoor unit 2 ½ in Wiring 60mm hole Model A 2 ½ in Wiring hole 60mm Model B HA HB Fig 3-6...
  • Page 16 3. Installation method Model A Connect the wire from the display panel of the indoor unit to a connecting cable. Then connect the other side of the connecting cable to the control. Mainboard 4-core wire The connective wires group shielded wire(some units) Fig 3-7 Applicable to Light Commercial air conditioner Adaptor board...
  • Page 17 3. Installation method Model B 1 indoor unit Use nippers or similar tools to notch the part for the wiring to pass through. Connect the terminals on the wired controller (HA, HB) to the corresponding terminals on the indoor unit (HA, HB). Note that HA and HB are not polarized.
  • Page 18 3. Installation method The main and secondary wired controllers can be used together to control one unit. Connect the wired controllers to the unit via the HA and HB ports on the controller. There is no polarity between HA and HB. See Fig. 3-10 for reference.
  • Page 19 3. Installation method unit need to be connected to the HA and HB ports at the same time. In group control, there will be no error displayed on the wired controller . SeeFig. 3-11 Indoor Unit 1 Indoor Unit 2 Indoor Unit n (n<=16) HA HB...

  • Page 20: Specification

    6. Reattach the upper part of the wired controller After adjusting the upper case, secure it in place. Be sure to avoid clamping the wiring during installation. (See Fig. 3-13) All images in this manual are for illustrative purposes only. Your wire controller may differ slightly.

  • Page 21: Feature And Function Of The Wired Controller

    5. Feature and function of the wired controller Feature: LCD display. Malfunction Code Display: The unit can display error codes, which assists in servicing. The 4-way wire layout design features a flat backside, allowing for easier wire placement and installation of the device. Room temperature display.

  • Page 22: Name On The Lcd Of The Wired Controller

    6. Name on the LCD of the wired controller °C / °F display MODE display Temperature display Room temperature display Displays the current mode,including: Relative humidity display Lock display Wireless control feature display Follow me feature display Breeze away display Delay off display Turbo feature display ECO feature display...

  • Page 23: Name Of Button On The Wired Controller

    7. Name of button on the wired controller 1 FAN SPEED button 7 COPY button 2 MODE button 8 POWER button 3 FUNC. button 9 CONFIRM button 4 SWING botton 10 BACK botton 5 ADJUST button 11 DAY OFF/DELAY button 6 TIMER button 12 CHILD LOCK button...

  • Page 24: Preparatory Operation

    8. Preparatory operation Set the current day and time Press the Timer button for 2 seconds or more. The timer display will ash. Press the button “ ” or “ ” to set the date. The selected date will ash. The date setting is complete, and the time setting will be prepared after pressing the Timer button or the CONFIRM button, or if no button is pressed within 10 seconds.

  • Page 25: Operation

    Time scale selection Press the buttons “ ” and “ ” for 2 seconds will alternate the clock time display between the 12h & 24h scale. 9. Operation To start/stop operation Press the Power button. 8 degree heating function When the heating mode temperature is 16℃(60℉)or the set minimum temperature, press the key twice within 1 second to turn on the 8℃...

  • Page 26: To Set The Operation Mode

    9. Operation To set the operation mode Operation mode setting(Heat mode is invalid for cool only type unit) Press this button to select the operation mode: If the indoor unit features both Aux. (Emergency Heating) mode and Heat + Aux. mode, press the button to select the desired operation mode: If the indoor unit has an Aux.
  • Page 27 9. Operation When the mode is selected as emergency heating (or Aux) mode, is displayed, the default fan speed is set to Auto; however, you can adjust the fan speed as needed. Please note that the Sleep, 8-degree heating, Turbo, and Rotation functions are not available in emergency heating mode.

  • Page 28: Room Temperature Setting

    9. Operation Room temperature setting Press the button“ ”or “ ” to set the room temperature. Lower Indoor Setting Temperature Range : 10/16/17~30°C(50/60/62~86°F ) or 20~28°C(68~82°F ). Raise (Model dependent) °C & °F scale selection (on some models) Press the buttons “ ”...

  • Page 29: Child Lock Function

    9. Operation Child lock function Press the buttons “ ” and “ ” for 3 seconds to activate the child lock function and lock all buttons on the wire controller. You can't press the button to operate and receive the remote control signal after the child lock is activate.
  • Page 30 9. Operation Swing function(For the units without vertical swing function ) Use Swing button to adjust the Up-down air ow direction and start the auto swing function. 1.Each time you press this button, the louver swings an angle of 6 degrees. Press this button until the desired direction reaches.
  • Page 31 9. Operation 3. And then use Swing button to adjust the Up-Down air ow direction of the selected louver. Press the FUNC. button to scroll through operation functions as followings: [ ]: Model dependent. If the indoor unit has no this function, it will not display.
  • Page 32 9. Operation Intelligent eye display 1. This function is active in any mode while the power is on. 2. When the indoor unit with a wired controller has the smart eye function, press the function key to select the smart eye icon, then press the OK key to activate the smart eye, which will illuminate the icon.
  • Page 33 9. Operation Humidity setting function 1.When the indoor unit sending wire controller has dual control function of temperature and humidity, in dehumidi cation mode, press the function key to select the RH icon, press the con rm key to enter the humidity control mode, the RH icon ashes, press the up and down keys to adjust the humidity, the setting range is OFF->35%~85%, adjusted with 5% humidity.
  • Page 34 9. Operation GEAR function 1.When the indoor unit sending wire controller has the GEAR function, in the boot cooling mode, press the function key to select the GEAR icon, press the con rm key to enter the GEAR control mode, and rst display the current GEAR status. 50%->75%->OFF can be switched by the up and down keys within 5 seconds.
  • Page 35 9. Operation Rotation & Back-up indication When there are two units, press the button to select the rotating function, and press “Con rm”to turn on or o the rotating function. 1. Press “Con rm” to set the rotating time,then press the button “ ”or “...

  • Page 36: Timer Functions

    10. Timer functions WEEKLY timer Use this timer function to set operating times for each day of the week. On timer Use this timer function to start air conditioner operation. The timer operatesand air conditioner operation starts after the time has passed. O timer Use this timer function to stop air conditioner operation.
  • Page 37 10. Timer functions To set the On or Off TIMER Press the Timer button to select the No display Press the Con rm button and the Timer display is ashing. ex.Off timer set at 18:00 Press the button “ ” or “ ”...
  • Page 38 10. Timer functions To set the On and Off TIMER Press the Timer button to select the Press the Con rm button and the Clock display is ashing. Press the button “ ” or “ ” to set the time of On timer, and then press the Con rm button to con rm the setting.

  • Page 39: Weekly Timer Setting

    11. Weekly Timer 1 Weekly timer setting Press the Timer button to select the and then press the Con rm button to con rm. Day of the week setting Press the button “ ” or “ ” to select the day of the week and then press the Con rm button to con rm the setting.
  • Page 40 11. Weekly Timer 1 ex.Tuesday time scale 1 Up to 4 timer settings can be saved for each day of the week. It is conventent if the WEEKLY TIMER is set according to the user’s life style. Off timer setting of timer setting 1 Press the button “...

  • Page 41: Weekly Timer Operation

    11. Weekly Timer 1 WEEKLY timer operation To activate WEEKLY TIMER operation Press the Timer button while is displayed on the LCD. To deactivate WEEKLY TIMER operation Press the Timer button while is disappear from the LCD. To turn off the air conditioner during the weekly timer 1.
  • Page 42 11. Weekly Timer 1 To set the DAY OFF (for a holiday) During the weekly timer, press the Con rm button. Press the button “ ” or “ ” to select the day in this week. Press the Day o button to set the DAY OFF. mark is hidden ex.The DAY OFF is set for Wednesday The DAY OFF can be setted for other days by repeating...

  • Page 43: Delay Function

    11. Weekly Timer 1 DELAY function During the weekly timer, press the FUNC. button , select the delay function and press the Con rm button,display" " " "" " and wait 3 seconds to con rm. When the delay function is activated,the “ ”mark appears.
  • Page 44 11. Weekly Timer 1 Press the Copy button,the letter “CY” will be shown on the LCD. Press the button “ ” or “ ” to select the day to copy to. Press the Copy button to con rm . mark ashes quickly ex.
  • Page 45 11. Weekly Timer 2 Weekly timer setting Press Timer to select the and press Con rm. Day of the week setting Press “ ” or “ ” to select the day of the week and then press CONFIRM. ON timer setting of timer setting 1 Press “...

  • Page 46: Time Setting

    12. Weekly Timer 2 IMPORTANT: Up to 8 scheduled events can be set on one day. Various events can be scheduled in either MODE, TEMPERATURE and FAN speeds. ex.Tuesday time scale 1 Time setting Press “ ” or “ ” to set the time, then press CONFIRM.
  • Page 47 12. Weekly Timer 2 Fan speed setting Press “ ” or “ ” to set the fan speed then press CONFIRM. NOTE: This setting is unavailable in the AUTO, DRY or OFF modes. Different scheduled events can be set by repeating steps 3 through 7.
  • Page 48 12. Weekly Timer 2 WEEKLY timer operation To start Press Timer to select the , and then the timer starts automatically. To cancel Press the Power buttons for 2 seconds to cancel the timer mode. The timer mode can also be canceled by changing the timer mode using Timer.

  • Page 49: Weekly Timer 2

    12. Weekly Timer 2 Press DAY OFF to create an o day. mark is hidden ex.The DAY OFF is set for Wednesday Set the DAY OFF for other days by repeating the steps 2 and 3. Press BACK to revert to the weekly timer. To cancel, follow the same procedures used for setup.
  • Page 50 12. Weekly Timer 2 Press “ ” or “ ” to select the day to copy from. Press COPY, the letters CY appear on the LCD. Press “ ” or “ ” to select the day to copy to. Press COPY to con rm. mark ashes quickly ex.
  • Page 51 12. Weekly Timer 2 Delete the time scale in one day. During the weekly timer setting, press CONFIRM. Press “ ” or “ ” to select the day of the week and then press CONFIRM. Press “ ” or “ ”...

  • Page 52: Fault Alarm Handing

    13. Fault alarm handing If the system is not operating correctly, aside from the cases mentioned above or if the indicated malfunctions are evident, please investigate the system using the following procedures. D ISPLAY MALFU N C T ION & PROT EC T ION D EFIN E D IGITAL TU BE Error of communication between wire controler and indoor unit...

  • Page 53: Queries And Settings

    15.Queries and settings When the air conditioning unit is off, Long press “COPY” for 3 seconds , first display P:00, if connected to an indoor unit, display P:00, if connected to multiple indoor units, press “ ”or “ ”to display P:01, P:02, and then press “Con rm”...
  • Page 54 15.Queries and settings Follow me function temperature compensation When the air conditioning unit is o , into the query function of temperature, press“ ”or “ ”to select tF. The compensation temperature Range : -5~5°C. Press “Con rm” into setting state, press“ ”or “...
  • Page 55 15.Queries and settings Set the highest and lowest temperature values When the air conditioning unit is o , into the query function of temperature, press“ ”or “ ”to select tHI or tLo. Press “Con rm” into setting state, press“ ”or “ ”to select the temperature, then press “Con rm”...

  • Page 56: Restore Factory Settings

    15.Queries and settings Two - line controller address selection When the air conditioning unit is o , into the query function of temperature, press“ ”or “ ”to select Adr, the temperature zone will display -- or A, B. Where -- refers to the code setting of the wirecontroller.
  • Page 57 15.Queries and settings The rotating parameter setting will be set to 10 hours (the highest and lowest temperature settings will not be configured). Body temperature compensation will be disabled. The COOL and HEAT/single COOL modes will revert to the standard COOL and HEAT modes. The temperature range will return to the factory default settings.

  • Page 58: Wireless Control Connection

    16.Wireless control connection SAFETY PRECAUTION Read the safety precautions carefully before installing the unit.  Stated below are important safety issues that must be obeyed.  Applicable system: IOS, Android. (Suggest: IOS 9.0 and above, Android 6.0 and above.) NOTE: Due to potential special situations, we would like to clarify the following: Not all Android and iOS systems are compatible with the app.
  • Page 59 Please do not be confused by this discrepancy. NOTE: Innovair will not be liable for any issues and problems caused by Internet, Wireless Router and Smart Devices. Please contact the original provider to get further help.
  • Page 60 16.Wireless control connection DOWNLOAD AND INSTALL APP On an app market (Google Play Store, Apple App Store), search for "NetHome Plus" and nd the NetHome Plus app. Download and install it on your phone, You can also download the app by scanning the QR code below.
  • Page 61 16.Wireless control connection NETWORK CONFIGURATION CAUTION It is essential to forget any other nearby networks and • ensure that your Android or iOS device is only connected to the wireless network you wish to configure. Verify that the wireless network function on your Android •...
  • Page 62 16.Wireless control connection Network configuration by Bluetooth scan Note: Make sure the bluetooth of your mobile device is working. Press “Scan for nearby Press “ + Add Device ” devices”...
  • Page 63 16.Wireless control connection Wait for the smart devices Select home Wireless, to be detected, then click enter the password to add them.
  • Page 64 16.Wireless control connection Please wait while Configuration Success, connecting to the you can modify the default network. name.
  • Page 65 16.Wireless control connection You can choose an Bluetooth network existing name or configuration is successful, customize a new name. now you can see the device in the list.
  • Page 66 16.Wireless control connection NOTE: · Make sure your devices are powered on. · Keep your mobile phone close enough to your device when you are connecting network to your device. · Connect your mobile phone to the wireless network at home, and make sure you know the password of the Wireless Network.
  • Page 67 16.Wireless control connection APP DECLARATION Hereby, we declare that this Smart kit is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. A copy of the full DoC is attached.(European Union products only) CAUTIONS: WirelessNetwork module models: US-SK107，EU-SK107: FCC ID: 2ADQOMDNA21 IC: 12575A-MDNA21 This device complies with Part 15 of the FCC Rules and it contains...
  • Page 68 16.Wireless control connection NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 69 Breezeless function of dip switch. NTOE: This feature is only available under cool mode. This feature is for some models. INDOOR UNIT MAIN BOARD SW2-2 SW2-1 SW2-2 dip switch to be “ON”,turn on the breezeless. SW2-2 dip switch to be “OFF”,turn off the breezeless.
