Atlantik Coda Desk 38408145 Manual

Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
Coda Desk
TM
Item#: 38408145
38408173
38408174
Customer Service:
800-747-2660
Ver. 02 03/28/23

Advertisement

loading
Need help?

Need help?

Do you have a question about the Coda Desk 38408145 and is the answer not in the manual?

Questions and answers

Summary of Contents for Atlantik Coda Desk 38408145

  • Page 1 Coda Desk Item#: 38408145 38408173 38408174 Customer Service: 800-747-2660 Ver. 02 03/28/23...

  • Page 2: Assembly Tips

    Assembly Tips: Become familiar with the instructions and all parts. Make sure that all parts are in the box and in good condition. Assemble the product on an open flat carton or a rug to protect the product and your floor. DOT NOT over-torque cam locks.
  • Page 3 Parts List/ Lista de Piezas x 16 Tools Needed (not included) Herramanientas requeridas (no incluidas) Leg Pads x 16 6mm ( 7/32”) Ø Ø 3mm ( 1/8”) Ø Ø CAM Lock Stickers...
  • Page 4 Combine panels (8), (10) and (9) with screws (E) with Combine los paneles (8), (10) y (9) con los tornillos (E) Phillips screwdriver. usando un destornillador Phillips. Slide panel (11) into bottom channel of pre-assembled Deslice el panel (11) en el canal inferior de los paneles panels of (8), (10) and (9).
  • Page 5 Screw in cam screws (A) into panel (1) using Phillips screwdriver. Place legs brackets (F) onto panel (6) and attach with screws (D) using Phillips screwdriver. Atornille los tornillos de leva (A) en el panel (1) usando un destornillador Phillips. Coloque los soportes de las patas (F) en el panel (6) y fije los tornillos (D) usando un destornillador Phillips.
  • Page 6 Cam Lock Sticker Connect panels (4), (3) and (2) to panel (1) with wood Conecte los paneles (4), (3) y (2) al panel (1) con tacos de madera (C) y tornillos de leva al panel (1). Inserte los dowels (C) and cam screws from panel (1). Insert cam locks (B) into panels (4), (3) and (2) and turn clockwise cierres de leva (B) en los paneles (4), (3) y (2) y gire un one quarter turn to lock in place using Phillips screwdriver.
  • Page 7 Take pre-assembled part from step 6 and attach panel (6) with wood dowels (C) and screws (E) using Phillips screwdriver. Tome la pieza premontada del paso 6 y fije el panel (6) con tacos de madera (C) y tornillos (E) usando un destornillador Phillips.
  • Page 8 Safety Option: Place straps (R) on top back inside edge with washers (Q) and screws (O) using Phillips screwdriver. Opción de seguridad: Coloque las correas (R) en el borde interior de la parte superior trasera con arandelas (Q) y tornillos (O) usando un destornillador Phillips.

This manual is also suitable for:

Coda desk 38408173Coda desk 38408174
