EWIND
Product Introduction
The EW1200 is an new generation high-performance enterprise-level dual-band 1200M router that
supports HW-NAT and 802.11ac technology. It achieves an Internet NAT forwarding speed of up to
900+Mbps. The 5.8G band provides a maximum access rate of 866.7Mbps, while the 2.4G band
provides a maximum access rate of 300Mbps, meeting the demand for high-speed wireless internet
access for up to 64 terminals simultaneously. It features gigabit network interfaces and wireless access
speeds of 300Mbps for 2.4G 802.11b/g/n and 866.7Mbps for 5.8G 802.11a/n/ac. It is plug-and-play
and offers high performance, high gain, high receive sensitivity, high bandwidth, and high access
capacity. It not only provides a wider coverage range, but also delivers higher wireless transmission
performance and stability, making it the ideal choice for high-density environments such as education,
government, enterprise offices, hospitals, and conference halls.
802.11AC WiFi5 1200M Wireless Router
EW1200
2.4G & 5.8G 1200Mbps 802.11AC Indoor
Wireless Router
1: Chipset SF19A2890, 128MB DDR2, 16MB
Flash,,access 64users;
2: Beam Forming Technology;
3: Support PPTP and L2TP VPN;
4: Support Easy Mesh Connect design for big
area Wireless Coverage;12V1A power
adapter;
www.ewindnet.com
EW1200
EWIND
1
Advertisement
Table of Contents
Summary of Contents for Ewind EW1200
- Page 1 Product Introduction The EW1200 is an new generation high-performance enterprise-level dual-band 1200M router that supports HW-NAT and 802.11ac technology. It achieves an Internet NAT forwarding speed of up to 900+Mbps. The 5.8G band provides a maximum access rate of 866.7Mbps, while the 2.4G band provides a maximum access rate of 300Mbps, meeting the demand for high-speed wireless internet access for up to 64 terminals simultaneously.
-
Page 2: Technical Specification
EWIND EW1200 Features 1) Designed based on operator-standard hardware, the anti-electromagnetic interference capability complies with requirements YD/T 968-2010 'Electromagnetic Compatibility Requirements Measurement Methods Telecommunication Terminal Equipment'. The overvoltage and overcurrent protection meets the requirements of YD/T 993-2006 'Technical Requirements and Test Methods... - Page 3 EWIND EW1200 Wireless 2.4G: 300Mbps with 802.11b/g/n MIMO technology Technology 5.8G: 866.7Mbps with 802.11a/n/ac MIMO technology WAN1/LAN3 10/100/1000Mbps adaptive Ethernet ports Device Interfaces DC power interface, compatible with power plugs with an outer diameter of 5.5mm, inner diameter of 2.1mm, and length of 9.5mm or above...
-
Page 4: Software Functions
EWIND EW1200 2.4G: 11b：＜-82±1.5dBm @1Mbps， ＜-76±1.5dBm dBm@11Mbps 11g：＜-82±1.5dBm@6Mbps， ＜-65±1.5dBm @54Mbps 11n 20MHz：＜-82±1.5dBm@MCS0， ＜-64±1.5dBm @MCS7 11n 40MHz：＜-79±1.5dBm @MCS0， ＜-61±1.5dBm @MCS7 11a：＜-82±1.5dBm @6Mbps， Receiver ＜-65±1.5dBm @54Mbps Sensitivity 11n 20MHz：＜-82±1.5dBm@MCS0， ＜-64±1.5dBm @MCS7 11n 40MHz：＜-79±1.5dBm @MCS0， ＜-61±1.5dBm @MCS7 11ac 20MHz：＜-82±1.5dBm @MCS0， ＜-57±1.5dBm @MCS8 11ac 40MHz：＜-79±1.5dBm @MCS0，... - Page 5 EWIND EW1200 -WiFi: Dual frequency in one\2.4G&5G WPS switch\ 2.4G&5G: Status switch\Hide SSID\SSID\Security\ Encryption Mode\Password\ Advanced Settings: Protocol\Channel Bandwidth\ Channel\Tx power -Black and White List: Switch\ Wireless Mode switch (Blacklist\Whitelist) \Blacklist -WPS: 2.4G&5G Switch\PBC -Mesh: Switch\Role (Automatic\Main route\Satellite) \ Add satellite\Fast roaming\ 2.4G&5G Set signal strength threshold...
-
Page 6: Packing List
EWIND EW1200 Product Dimension(mm) Packing List CONTENT UNIT 802.11AC WiFi5 1200M Wireless Router (EW1200) DC 12V/1A power adapter Ethernet cable User manual www.ewindnet.com...
