- Page 1 USER MANUAL SUBURBAN 750W...
-
Page 3: Table Of Contents
Contents Welcome to the Mukkpet! ..............03 Product Overview ................05 Specification ..................06 Assembly Guidance ................07 - Package Content ................ 07 - Assembly Steps ................. 08 Pre-ride Check ................... 12 Battery ....................13 - Installation and Movement ............14 - How to Take Care The Battery .......... -
Page 5: Welcome To The Mukkpet
Welcome to the Mukkpet！ Congratulations on your purchase of a new Mukkpet E-bike! Thank you for choosing Mukkpet as your cycling companion! Please read and understand this manual thoroughly before assembling and cycling your e-bike. The assembly video and other useful content about the e-bike can be found in the QR code of this user guide. - Page 6 WARNING Mukkpet E-bike LLC assumes no liability for any harm, injury, or death of the rider. The bike comes 85% assembled and here is the guide that helps you get familiar with your new bike in unboxing. The bike may need ad- justments in this process as shipping can sometimes be bumpy.
-
Page 7: Product Overview
Product Overview Shimano 7 LCD Display Shifter Brake Lever On/Off Switch Throttle Saddle Front Light Rear Rack Seat Post Battery Rear Light Pedal Crankset Wheel Chain Motor Disc Brake... -
Page 8: Specification
Specification Specification Item Model SUBURBAN 750W Product Dimensions 182*68*113 CM Package Dimensions 151*31*81 CM Max Load 330 LBS Package Weight 81.6 LBS E-Bike Weight 62 LBS Max Speed 25 MPH 48V15AH/2A Battery/Charger Input 100-240V 50/60HZ Output 54.6 2.0A Pedal-Assist Mode... -
Page 9: Assembly Guidance
Assembly Guidance Package Content Tool Bag*1 Electric Bike*1 User Manual*1 Tool Kit*1 Zip Tie *5 Charger*1 Front Wheel*1 Fender*2 Display*1 Rear Rack*1 Seat*1 Pedals*2 Please scan the following QR code to watch the assembly video video. https://youtu.be/ho8G_W7d_bE... -
Page 10: Assembly Steps
Assembly Steps Step 1: Handlebar 1. Loosen the four screws on the front of the stem. 2. Hold the handlebar in the middle of the joint, tighten the four screws. 3. Tighten the two screws on the rear of the stem. Step 2: Front Fork 1. - Page 11 Step 3: Fender & Headlight 1. Place the fender and headlight in the right position, then tighten the screw. 2. Tighten the screws on both sides of the fender. Step 4: Rear Rack 1. Put the rear rack in a proper position and tighten four screws to fix it. 2.
- Page 12 Step 5: Seat Post Adjust the seat to a comfortable position according to your height. For safety reasons, we do not recommend that you adjust the seat tube height beyond the safety line. Step 6: Pedals 1. Install the left and right pedals. "L" means to the left pedal and "R"...
- Page 13 3. The battery can be removed or not when charging. NOTICE The SUBURBAN 750W battery does not have a red switch button, and it can be used directly after proper installation.
-
Page 14: Pre-Ride Check
Pre-ride Check 1. Make sure all components are tightened. Adjust the height of the handlebar and the seat post. DO NOT raise it above the safety line. 2. Make sure the brakes can cut off the power supply to the motor, and whether it is sensitive and reliable. -
Page 15: Battery
Battery WARNING Please check the battery condition, key position and power before riding, make sure the battery is locked before riding to prevent the battery from falling off during the riding. 。 Battery Power Button (indicates the power) Key-plug-in Location (lock/unlock the battery) Charging Port WARNING There are 5 of indicators, 3 green light and 2 red... -
Page 16: Installation And Movement
Installation and Movement The correct installation step is to align the battery with the guide rail, push it to the bottom of the guide rail, put it in the appropriate position, and then twist the key to "LOCK" to fix the battery. -
Page 17: How To Take Care The Battery
How to Take Care The Battery NOTICE Check the charger, charger cables, and battery for damage before each charge. The charger shows red during charging, and it would turn green when the battery is fully charged. 1. Always charge in a safe area that is cool, dry, indoors, away from direct sunlight, dirt, or debris, in a clear area away from the potential to trip on the charging cords, or for damage to occur to the bike, battery, or charging equipment while... -
Page 18: Display And Setting
Display and Setting Battery Level Indicator Speed Pedal Assist Level Trip Battery Level Remaining battery power Indicator Speed Realtime speed while riding 0,1,2,3,4,5 Displays the current Pedal Assist Level pedal assisted mode. Shows the distance of a single trip. Trip Data is automatically cleared when the bike is powered off. - Page 19 “+” Button On/Off “-” Button Common Operation How to Do Press and hold the ” for 3 seconds till the “ Turn on/off the bike display is on / off. Press "+" or "-" button to increase or Increase/Decrea decre- ase the PAS Level. se the PAS Level Long press “...
-
Page 20: Parameter Setting
Parameter Setting When the display is powered on, long press “+ ” and “ - ” at the same time, then will enter parameter setting mode. In this mode, you can change parameter values according to “ + ” or “ - ”. Short press “... - Page 21 Short press "+" / "-" 0: 3 PAS mode P05: PAS Mode to adjust PAS 1: 5 PAS mode setting mode.
- Page 22 Set Mode Operate Note 0: 16 4: 24 inch inch P06: Wheel Short press "+" / "-" 1: 18 5: 26 inch inch size selection to switch wheel 2: 20 6: 700 inch 7: 28 3: 22 size inch inch P07: Number Short press "+"...
- Page 23 P20~P26: This feature is blank, invalid.
-
Page 24: Error Code Definition
Error Code Definition When an error appears, M6C will notice users by different codes, please refer to the table for different codes: Code ( Decimal ) Signification Current anomaly Turn handle anomaly Motor phase deficiency Motor Hall anomaly Brake anomaly Communication anomaly NOTICE The display has generally been set to a normal state, and it is... -
Page 25: Operating Safety
Operating Safety 1. This E-bike will power off when braking. It ensures the safety of riding. 2. Don’t carry people in the rear seat. The weight limit of the rear seat is 25kg. 3. Don’t ride exceed the speed limit set by the local traffic laws. Comply with the CLASS 1 maximum speed limit: 20MPH. -
Page 26: Faq
Q: What if the battery cannot be charged, and the display shows an abnormal battery power? A: Use a multimeter to test the battery voltage. Check if the charger indicator is normal. (Red light means charging, green light means fully charged) If the battery case is damaged, stop using the battery and contact us. - Page 27 Q: What if the e-bike arrived missing an accessory or broken part? A: Please take a photo and send it to Mukkpet e-bike Support Team by sending e-mail: support@mukkpetbike.com Mukkpet e-bike support team will reply to you soon and send the correct accessory or part replacement.
-
Page 28: Component Maintenance
— Pay attention to frame maintenance. Wipe the bike and keep it dry. —Any merchandise with electrical components is not recommended to be exposed to water and the warranty of the Mukkpet does not cover water damage. So please try not to store or use the bike in wet con- dition. -
Page 29: Brake Maintenance
Brake Maintenance — Check brake pads regularly. — Check the brake disc regularly to prevent deform. — If it is a hydraulic brake, check regularly to see if any oil leakage. — Clean the brake regularly. Motor Maintenance — Do not try to disassemble the motor. —... -
Page 30: Warranty
Warranty The main parts of the warranty provisions. Component Warranty Performance Failure Remark Period Natural sealing off. Front Except Fracture key 1 Year damaged fork parts crack. caused by handleb riders. Internal gear break. Bearing broken. The wheel hub shell cracking. Except 1 Year Motor... - Page 31 Disassemble Display Not working. personally will 1 Year not be replaced.
- Page 32 We will replace any parts deemed to have been damaged during shipping. Shipping damage must be reported to Mukkpet E-bike within 14 days of shipment arrival. This applies to all products in- cluding bikes and accessories. Replacement parts will not be sent until photographic evidence has been provided to Mukkpet E-bike.
-
Page 33: Disclaimer
Damage as a result of an accident is not covered under this warr- anty, and Mukkpet E-bike is not responsible for the repair or replace- ment of damaged bikes or parts. 4. Mukkpet E-bike reserves the right to change its warranty at any time and without notice. - Page 34 Contact us for more owner benefit. E-mail: support@mukkpetbike.com +86 17825804876 WhatsApp:...
