Astro Link Instruction
Manual
LEVIL AVIATION
1704 KENNEDY POINT, SUITE 1124
OVIEDO, FL 32765

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Astro Link and is the answer not in the manual?

Questions and answers

Summary of Contents for Levil Aviation Astro Link

  • Page 1 2019 Astro Link Instruction Manual LEVIL AVIATION 1704 KENNEDY POINT, SUITE 1124 OVIEDO, FL 32765...
  • Page 2 Revision Code Number This manual is the property of Levil Aviation. It may not be replicated in whole or in part or otherwise divulged without prior written consent from Levil Aviation. All printed and electronic copies and versions except the one electronically signed inside the Levil Aviation database, are considered unofficial copies and may be used for reference only.
  • Page 3: Amendment Record

    Initial release Warranty Levil Aviation warrants this product to the original purchaser to be free from defects in material and workmanship for one year from the date of the original purchase. The following are not covered: software, damage resulting from accident, neglect, misuse, fire, or flood, improper voltage supply or failure to follow operational guidelines supplied with this product.
  • Page 4 Every pilot should have a safety net when they go flying because no matter how much we hope for the best, it is always good to be prepared for the worst. The Astro Link provides an affordable solution that gives pilots the peace of mind they need to be able to safely overcome any instrument malfunction or related emergency.
  • Page 5: Before Flight

    5 hrs 3. ALIGNMENT  Find a location that will allow your Astro Link to have a clear view of the sky for GPS satellite reception and “line of sight” to ADS-B ground stations and other aircraft around you.
  • Page 6 Document No. Revision Code Number NOTE: DO NOT rely on the Astro Link for attitude & heading if it is not aligned as specified. 4. CONNECTING TO YOUR FAVORITE APP The Astro Link series offers the most compatibility with Apps on both iOS and Android platforms.
  • Page 7 Not charging NOTE: The Astro Link has a charging temperature protection. If the battery is above 40°C (104°F) and the Astro Link is connected to external power, it will continue to operate from external power, but the charging process will be disabled. The charging LED status will be set to OFF.
  • Page 8: Specifications

    Utility App. If the AHRS was able to successfully compensate for errors, you may store this data inside the Astro Link and use this configuration on the next power cycle: AHRS Utility  Device Config  Enable Configuration  Save Mag Data ...
  • Page 9: Environmental Requirements

    Astro Link Manual 12/6/19 Page 8 of 10 Effective Date D-0026 Document No. Revision Code Number  978 MHz UAT ADS-B out  Mode-ES transponders with extended squitter 7.3 WIFI  Android and iOS compatible  Supports up to 10 devices connected simultaneously (UDP broadcast) ...
  • Page 10: Battery Safety Instructions

     Failure to read and follow Battery Safety Instructions may result in fire, personal injury and property damage  The Astro Link will get hot after it’s been running in direct sun; don’t leave the iLevil ON or OFF parked on the ramp in the hot sun; Use caution! ...
  • Page 11: Helpful Tips

     The internal AHRS has a max rate of turn of 500 deg/sec. Most likely you will exceed this limit (or “tumble” it) when playing with the Astro Link in your hands. If this is the case, and the AHRS did not recover, you may “tumble” it again, and set it on a level...
