Summary of Contents for Novus NT240
- Page 1 NT240 TIMER PROGRAMMABLE TIMER USER GUIDE V2.0x K...
-
Page 2: Table Of Contents
MODE 9 – DELAYED TRIGGERING AFTER CONTINUOUS INPUT TRIGGERING ..............13 6.1.11 MODE 10 – DELAYED PULSE AFTER CONTINUOUS INPUT TRIGGERING ................13 CUSTOMIZED OPERATION MODE ................................14 6.2.1 MODE 11 – CUSTOMIZED OPERATION MODE ..........................14 SPECIFICATIONS ....................................... 15 IDENTIFICATION ......................................16 WARRANTY ........................................ 17 NOVUS AUTOMATION 2/17... -
Page 3: Safety Alerts
All safety recommendations appearing in this manual must be followed to ensure personal safety and prevent damage to the instrument or system. If the instrument is used in a manner other than that specified in this manual, the device’s safety protections may not be effective. NOVUS AUTOMATION 3/17... -
Page 4: Introduction
INTRODUCTION The NT240 programmable timer is used to monitor the time and trigger the output according to the program previously set by the user. It offers several pre-established operation modes. The only thing required is to define the time intervals to be used. It also allows you to create an operation mode. -
Page 5: Features
On terminals 7 and 8, the timer has an auxiliary voltage source (AUXILIARY SUPPLY OUTPUT) with 12 Vdc ±10 % (50 mA max.). It powers the electronic sensors applied to the device. The (-) terminal is common to the GND terminal of the inputs. This voltage source is not electrically isolated from the Digital Input circuits. NOVUS AUTOMATION 5/17... -
Page 6: Installation
Type of signal common in proximity sensors. It must be connected to the digital input as shown below. The PnP parameter must be set to 0 for NPN sensors and to 1 for PNP sensors. Figure 2 NOVUS AUTOMATION 6/17... - Page 7 PnP = 0. Figure 3 4.2.1.3 DRY CONTACT RELAY OR SWITCH To connect contacts without voltage (Dry Contact), connect them as shown in the figure below and program PnP = 0: Figure 4 NOVUS AUTOMATION 7/17...
-
Page 8: Operation
Allows you to set the time that the output will be triggered when the output deactivation is programmed to “Deactivate after Output 1 Time programmable trigger time”. While the output is being triggered, the LED corresponding to the output will flash and the output relay will remain activated. NOVUS AUTOMATION 8/17... -
Page 9: Configuration Cycle
999.9 s. 9999 s. 99 min 59 s. 9999 min. 99 h 59 min. 9999 h. Allows you to set the programming protection mode. You must set this parameter before removing the protection switch. Prot CONFIGURATION PROTECTION section. NOVUS AUTOMATION 9/17... -
Page 10: Cycle Of Operation Mode Parameters
Indication screen, when the device will be reset, interrupting the timing in progress. Do not change the setting when the device is performing a critical function in the process in which it is installed, as the output may be triggered or switched off at the wrong time. NOVUS AUTOMATION 10/17... -
Page 11: Operation Modes
Out 1 Reset Figure 9 The parameters of the special configuration modes will be automatically programmed: T1S1 T1S2 T1S3 T1S4 T1S5 CONFIGURATION Table 6 key can be used for Reset and Reset/Hold. NOVUS AUTOMATION 11/17... -
Page 12: Mode 3 - Cyclic After Power-Up
6.1.7 MODE 6 – DELAYED TRIGGERING AFTER MOMENTARY INPUT TRIGGERING Start t1.SP t1.SP Out 1 Reset Figure 13 The parameters of the special configuration modes will be automatically programmed: T1S1 T1S2 T1S3 T1S4 T1S5 CONFIGURATION Table 10 key can be used for Reset/Hold. NOVUS AUTOMATION 12/17... -
Page 13: Mode 7 - Delayed Pulse After Momentary Input Triggering
Reset Figure 17 The parameters of the special configuration modes will be automatically programmed: T1S1 T1S2 T1S3 T1S4 T1S5 CONFIGURATION Table 14 key can only be used to hold the timer in progress. NOVUS AUTOMATION 13/17... -
Page 14: Customized Operation Mode
Not all combinations of parameters t1. S 1 to t1. S 5 are valid. Some can cause the timer to behave unpredictably. When configuring a custom operating mode, it is important to test the configuration before incorporating it into the system. NOVUS AUTOMATION 14/17... -
Page 15: Specifications
ELECTRICAL COMPATIBILITY:......................... EN61326-1:1997 and EN61326-1/A1:1998 SAFETY: ............................... EN61010-1:1993 and EN61010-1/A2:1995 CONNECTIONS SUITABLE FOR 6.3 MM PIN TERMINALS. FRONT PANEL: IP65. POLYCARBONATE UL94 V-2. HOUSING: IP20, ABS+PC UL94 V-0. PROGRAMMABLE PWM CYCLE FROM 0.5 TO 100 SECONDS. STARTUP: 3 SECONDS AFTER POWER-UP. NOVUS AUTOMATION 15/17... -
Page 16: Identification
IDENTIFICATION To identify the model, check the name on the label: Example: NT240 - RP - Model NT240 Optional RP (version with OUT1: Pulse and Relay) Power supply Blank (basic version, with power supply from 100 to 240 Vac/dc) 24 V (version with power supply from 12 to 24 Vdc / 24 Vac) -
Page 17: Warranty
WARRANTY Warranty conditions are available on our website www.novusautomation.com/warranty. NOVUS AUTOMATION 17/17...
